Sargent 28-7U15 LL 03 Grade 2 Passage Cylindrical Lock L Lever Non-Keyed Bright Brass Finish Non-handed

Sargent

Write a Review
SKU:
28-7U15 LL 03
$199.11
Sargent 28-7U15 LL 03 Grade 2 Passage Cylindrical Lock L Lever Non-Keyed Bright Brass Finish Non-handed
$199.11

Descriptions

A key-in-lever lock designed for standard duty commercial interior and exterior applications in public buildings, medical offices, hotels/motels and government facilities. Exceeds ANSI/BHMA A156.2 standards for cycling and durability.
TypeTitleURL
brochure/sales-materialSargent Bored Lock Brochurehttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/SAR_Tzone_Generic_Brochure.pdf
catalog7 Line Bored Lever Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Bored_Lock_7_Line_Catalog.pdf
installation-instructions7 & 10 Line Bored Locks (30- prefix) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6838D_low_res.pdf
7 & 10 Line Levers w/ Sargent Removable Core (63-) or Arrow, Best & Falcon Interchangeable Core Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6847.pdf
7 Line Cylindrical Lock Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7240D.pdf
SF Prefix Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A8009A.pdf
parts-list7-Line Lever Lock Body (Manufactured after 1/2005) Illustrated Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/7.2-B.pdf
7-Line Lever Lock Functions (Standard Lock Body) Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/SARGENT_7_Line_Parts_Manual.pdf
sell-sheetHurricane Resistant Bored Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/Windstorm_Bored.pdf
template7 Line Bored Lever Locks Templatehttps://dvwi9lnoau63q.cloudfront.net/sargent/templates/SARGENT_Bored_Lock_7_Line_All_Functions_Template.pdf

Specifications

Brand:
Sargent
Series:
7-Line Bored Lever Locks
Manufacturer:
Sargent
Base Material:
Brass
Bore Hole Diameter (in):
2-1/8"
Commercial Residential:
Commercial
Country Of Origin:
United States
Cylinder Type:
Non-Keyed
Finish:
605/US3
Finish Description:
Bright Brass
Fire Rated:
3 Hours {A}
Function:
15-Passage
Grade:
Grade 2
Latch Number:
194493
Lever/Knob/Pull:
Lever
Lever/Knob/Pull Design:
L Lever
Maximum Door Thickness (in):
1-3/4"
Rose/Escutcheon:
Rose
Rose/Escutcheon Design:
3-3/8" Rose Diameter
Rose/Escutcheon Dimensions (in):
3-3/8"
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Number:
808
Sub-Type:
Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Uid:
SAR100287U15LL3
Url Title:
28-7u15-ll-3
Title:
28-7U15 LL 3
Sub Type:
Cylindrical Lock
Last Modified:
2024-07-11T05:01:31+00:00
Last Pricing:
2024-03-01T00:00:00+00:00
Msrp:
315
Avg Lead Time:
32
Finish Family:
Polished Brass
Popularity:
9
Pack Weight:
3.6
Pack Length:
8.25
Pack Width:
6.875
Pack Height:
4.25
Pack Volume:
241.0546875
Ul Listing:
ANSI A156.2, Series 4000, Grade 2, UL Listed
Ansi Code:
F75
Baa Qualified:
Yes
Limited Warranty:
5 Year Warranty
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
10
Vendor:
Assa Abloy
