E-Plex 5000 Mortise Lock with Deadbolt, Winston Lever, 100 Access Codes, 3,000 Audit Events, Medeco/Yale/ASSA/Abloy LFIC Prep, Less Core, Satin Chrome
The DormaKaba E5067MWL-626-41 E-Plex 5000 Mortise Lock offers a robust and secure solution for commercial applications requiring reliable access control. Engineered with durability in mind, this heavy-duty cylindrical lockset features solid cast housings and levers, ensuring long-lasting performance even in high-traffic environments. Its versatile construction is suitable for both indoor and outdoor use, making it ideal for a wide range of commercial entrances.
Designed for flexibility, the E-Plex 5000 features a non-handed, pre-assembled mortise and cylindrical lock mechanism that can be easily adapted for left or right-hand doors in the field. It comes with a Winston lever handle that combines aesthetic appeal with ergonomic comfort. The lock supports up to 100 access codes and logs up to 3,000 audit events, providing comprehensive security management for facilities that require detailed access tracking.
This model is prepared for integration with multiple lock core systems, including Medeco, Yale, ASSA, and Abloy LFIC, offering versatile keying options to match existing security infrastructure. The satin chrome finish not only enhances its sleek appearance but also provides corrosion resistance, ensuring the lock maintains its aesthetic appeal over time. The lock is compatible with various backsets, including 2 1/8 inch and 2 3/8 inch cylindrical options, as well as a 2 3/4 inch mortise backset, accommodating different door configurations.
The E5067MWL-626-41 features a 1/2-inch latch for cylindrical models and a 3/4-inch latch for mortise units, with optional deadbolt configurations for added security. Its construction supports heavy-duty usage, making it an excellent choice for commercial entrances that demand high reliability and security. Whether installed on interior access points or exterior doors, this lock offers a perfect combination of strength, versatility, and advanced access control features, ensuring your facility remains secure while providing convenient access for authorized personnel.
Features:
* Heavy-duty cylindrical lockset with solid cast housings and levers for durability
* Pre-assembled, non-handed design for easy field installation and door handing flexibility
* Supports up to 100 access codes and logs 3,000 audit events for comprehensive security management
* Compatible with Medeco, Yale, ASSA, and Abloy LFIC core systems for versatile keying options
* Satin chrome finish provides corrosion resistance and a sleek appearance
* Backset options include 2 1/8 inch, 2 3/8 inch cylindrical, and 2 3/4 inch mortise configurations
* Optional deadbolt and latch sizes support various security needs and door types
* Suitable for both commercial interior and exterior applications with high traffic demands
