Descriptions
The Falcon W101S LAT 622 is a versatile and reliable commercial lock designed to meet the demanding needs of government, military, retail, industrial, and multi-family applications. Crafted with precision and built for durability, this lock features a robust construction that ensures long-lasting performance in high-traffic environments. The lock's classic design seamlessly integrates with most door trims, thanks to its compatibility with standard and interchangeable core cylinders, including SFIC products from various manufacturers.
Constructed with high-quality materials, the Falcon W Series lock mechanism is built from brass or cold-formed steel, zinc plated, and dichromated for rust resistance. Stainless steel springs enhance durability, making the lock suitable for exterior and interior use. The lock chassis is secured to the door with sturdy screws passing through a steel rose insert, ensuring a firm and secure fit. The lock is non-handed, allowing flexible installation on either side of the door, making it a versatile choice for various door configurations.
Equipped with a 6-pin pin tumbler cylinder, the Falcon W101S LAT 622 provides reliable security and easy re-keying options. The cylinder housings and plugs are machined from solid brass, ensuring durability and precision. The lock is compatible with standard 6-pin cylinders from Falcon, Schlage, Corbin-Russwin, Yale, and Sargent, offering flexibility in master keying and keyway options. The standard keyway is *G,* with optional *A* keyway and Schlage *C* keyway, which includes master key capabilities. This makes the Falcon W Series ideal for facilities requiring scalable master key systems.
The lock features a heavy wrought brass or bronze rose, installed over steel rose inserts that are through-bolted for added security. The lever handles are pressure-cast zinc, finished to match the metal trim, providing a sleek appearance. The stainless steel latch with a 1/2 inch bolt projection ensures secure latching and is UL listed for 3-hour door assemblies. The latch fronts are self-adjusting to accommodate both beveled and flat doors, and the strike is a 4-7/8 inch by 1-1/4 inch ANSI strike with a curved lip to meet standard door frame preparations.
Designed to meet or exceed industry standards, the Falcon W101S LAT 622 lock complies with ANSI/BHMA A156.2, Series 4000, Grade 2 specifications. It is also UL listed with a 3-hour A label, making it suitable for high-security applications. Whether you need a dependable lock for a commercial building or multi-family complex, the Falcon W101S LAT 622 offers a perfect balance of security, durability, and ease of installation, backed by the trusted Allegion brand from Mexico.
Features: * Heavy wrought brass or bronze roses installed over steel inserts for secure mounting * Compatible with standard 6-pin cylinders from Falcon, Schlage, Corbin-Russwin, Yale, and Sargent * Removable cylinders with master keying options and interchangeable core compatibility * Durable construction with brass or cold-formed steel mechanisms and stainless steel springs * UL listed for 3-hour fire-rated door assemblies and meets ANSI/BHMA Grade 2 standards * Non-handed design allows flexible installation on either side of the door * Includes a 1/2 inch stainless steel latch with self-adjusting front for beveled or flat doors * Heavy wrought brass or bronze roses with through-bolted steel inserts for added security * Finished in 622/US19 for corrosion resistance and aesthetic appeal
