Sargent 8271-24V LE1E BSP Grade 1 Fail Secure 24V Electric Mortise Lock E - Lever LE1 - Escutcheon Conventional Cylinder Black Suede Powder Coat

Sargent

Write a Review
SKU:
8271-24V LE1E BSP
$1,241.00
Sargent 8271-24V LE1E BSP Grade 1 Fail Secure 24V Electric Mortise Lock E - Lever LE1 - Escutcheon Conventional Cylinder Black Suede Powder Coat
$1,241.00

Descriptions

8270 Series Electrified Lever Mortise Locks

Designed and constructed with high quality components to provide maximum security.

 The Sargent electrified 8270 series locks represent over a century of innovation and experience in manufacturing hardware and are the industry’s benchmark for mortise locks: Strong - Durable - Flexible – Innovative and Secure.

  • For Doors 1-3⁄4" (44mm) thick standard. For doors over 1-3⁄4" (44mm), specify door thickness and panels (if any)
  • Backset 2-3⁄4" (70mm) only
  • Case 12 gauge heavy duty wrought steel, zinc dichromate plated. Thickness 7/64" (3mm) (.109")
  • Outside Front Plate Brass, bronze or stainless steel. 8" (203mm) x 1-1⁄4" (31mm), ANSI Standard A115.1. Adjustable at any angle from flat to beveled 1⁄8" (3mm) in 2" (51mm)
  • Springs High carbon steel
  • Hubs for Knobs Sintered iron copper infiltrated
  • Hubs for Levers Cold forged steel
  • Hubs for Institutional Stainless steel (3- prefix)
  • Latchbolt Stainless steel 3⁄4" (19mm) projection one-piece, anti-friction reversible latch
  • Auxiliary Deadlatch Stainless steel, non-handed
  • Deadbolt One-piece hardened stainless steel, with 1" (25mm) projection
  • Hand Specify hand on order; easily field reversible (if no hand is specified RH will be provided)
  • Strike Brass, bronze or stainless steel; ANSI Standard A115.1; curved lip, non-handed (strike box optional)
  • Keys Two, nickel silver (control key or emergency key must be ordered when required)
  • Cylinder Brass, size #41 (1-1/8") standard (except for Freewheeling, size #46 (1-3/4")). Available with SARGENT Signature, V-10, XC and KESO Security Systems
  • Masterkeying Can be masterkeyed or grand masterkeyed. Construction keying available. LA standard keyway.
  • Finishes 3, 4, 9, 10, 10B, 10BL,15, 20D, 26, 26D, 32, 32D Special finishes are available. (Contact factory for details)
  • Classroom Security 38, 39, 40, 41 Functions (All mortise trim designs available except KE/LE 3 & 4 and PT trim or FE trim with 41 function)
  • Stile 4-1/2" (114mm) minimum stile for 7800/8200, 4-3/4" (121mm) minimum stile for electrical function locks
  • Door Prep ANSI A115.1 modified per template (see template for 7800/8200 lockbody & trim)
  • Warranty 10 year limited warranty, 2 year limited warranty on electrified locks

Product Specs

  • Vendor
    ASSA Abloy
  • Manufacturer
    Sargent
  • SKU
    8271-24V LE1E BSP
  • UID
    SAR827124VLE1EBSP
  • Grade
    Grade 1
  • Unit of Measure
    Each
  • Origin
    USA
  • BAA Qualified
    Yes
  • Limited Warranty
    2 Years
  • Fire Rating
    2 Hours {B}

Finish

  • Finish
  • Finish Description
    Black Suede Powder Coat
  • Finish Family
    —

Technical Specs

  • Handing
    Field Reversible
  • Door Thickness
    1-3/4"
  • Std. Strike Type
    ASA
  • Std. Strike Height
    4-7/8"
  • Std. Strike Width
    1-1/4"
  • Screws
    Combination
  • Power
    Hard Wired
  • Cylinder Type
    Conventional Cylinder
  • # Pins
    6
  • Keying
    Keyed Different
  • # of Keys
    2
  • Operating Voltage
    12VDC/24VDC
  • Key(s)
    Cut
  • Std. Latch Type
    Dead Latch (Guarded)
  • Std. Keyway
    LA
  • Bolt Projection
    3/4"
  • Lock Face Size
    8" X 1-1/4"
  • Std. Strike Number
    82-0110
  • AMP Draw
    500mA Peak, 15mA Holding
  • Function
    71-Electrical Fail Secure
  • Rose/Escutcheon Design
    LE1 - Escutcheon
  • Side Locked
    Outside
  • Latch Backset Dim
    2-3/4 In.
  • Lever/Knob Design
    E Lever

Dimensions

  • Pack Qty
    1
  • Pack Length
    9.25"
  • Ship Weight
    6.1 lbs.
  • Pack Width
    5.63"
  • Pack Height
    4.38"
  • Pack Volume
    227.64 in³

Specifications

Brand:
Sargent

Warranty Information

2 Years
