  • Sargent 28-11G05 OL 26D Grade 1 Entrance/Office Cylindrical Lock L Lever O Rose Conventional Cylinder Satin Chrome Finish Non-handed

Sargent 28-11G05 OL 26D Grade 1 Entrance/Office Cylindrical Lock L Lever O Rose Conventional Cylinder Satin Chrome Finish Non-handed

Sargent

Write a Review
SKU:
28-11G05 OL 26D
$623.25
Sargent 28-11G05 OL 26D Grade 1 Entrance/Office Cylindrical Lock L Lever O Rose Conventional Cylinder Satin Chrome Finish Non-handed
$623.25

Descriptions

The SARGENT 11 Line sets a higher standard for Grade 1 bored-in locks. The unique T-Zone construction provides unequalled strength and durability for the most demanding applications such as schools and hospitals. This is accomplished by true interlocking between the lockbody and the latch far exceeding the 156.2 Series 4000 Grade 1 standards like no other lock can.
TypeTitleURL
brochure/sales-materialSargent Bored Lock Brochurehttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/SAR_Tzone_Generic_Brochure.pdf
catalog11 Line Bored Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Bored_Lock_11_Line_T-Zone_Catalog.pdf
design-guideT-Zone Lever Design Guidehttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.14-B.pdf
installation-instructions 11 Line with High Security Lever Attachment (SL- option) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7668A_5.09.pdf
11 Line Classroom Security Function Operating Instructions Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7497A_T-Zone_11G38_Function_11-24-08.pdf
11 Line Cylinders & Levers for Arrow, Best, Falcon Interchangeable Core Cylinders Installation & Removal Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7471B.pdf
11 Line Hotel Function (11U50) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7608B_T_Zone_11G50_Cylinder_11-19-08.pdf
11 Line Installation Instructions (all functions except Hotel)https://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7469L.pdf
11 Line Lever Pull Trim (93, 94, 94-2 functions) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7470A_T-Zone_Lever_Pull_Trim_Instructions_10102007.pdf
30-Option Lever to Accept Schlage Fixed Core Cylinder Tailpiece Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7476.pdf
SF Prefix Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A8009A.pdf
Spacer for YC-Cylinder Option Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A8225A.pdf
Video: 11 Line Cylindrical Lock Cam Orientationhttps://youtu.be/7J2s_chMS8c
Video: 11 Line Cylindrical Lock Disassemblyhttps://youtu.be/US5NIDE4fJo
Video: 11 Line Cylindrical Lock Latch Set Installationhttps://youtu.be/BxOnyOzFr1Y
Video: 11 Line Cylindrical Lock Lever Installationhttps://youtu.be/g4c21d2qQi0
Video: 11 Line Cylindrical Lock Rose Installationhttps://youtu.be/UYQ8atoixz8
Video: 11 Line Cylindrical Lock Sleeve Installationhttps://youtu.be/uFiGxPZfSDI
Video: 11 Line Lock Classroom Function Lever Installationhttps://youtu.be/t4JD_MHI_vc
Video: 11 Line Lock Privacy/Bathroom Function Lever Installationhttps://youtu.be/wOyXH0pQfk0
Video: 11 Line T-Zone Lock Installationhttps://youtu.be/gSYM8RIwIfQ
parts-listT-Zone Lever Lockset 11U93 Single Lever Pull Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.10-C.pdf
T-Zone Lever Lockset 11G04 Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.1-B.pdf
T-Zone Lever Lockset 11G05/24/44/54 & 11U65 Functions Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.2-D.pdf
T-Zone Lever Lockset 11G13 Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.3-B.pdf
T-Zone Lever Lockset 11G15-3 Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.5-B.pdf
T-Zone Lever Lockset 11G16/30/38 Functions Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.6-C.pdf
T-Zone Lever Lockset 11G17 Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.7-B.pdf
T-Zone Lever Lockset 11G37 Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.8-C.pdf
T-Zone Lever Lockset 11G50 Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.9-C.pdf
T-Zone Lever Lockset 11U15 Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.4-B.pdf
T-Zone Lever Lockset 11U94 Double Lever Pull Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.11-C.pdf
T-Zone Lever Lockset 11U94-2 Double Lever Pull Function Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.12-C.pdf
T-Zone Lever Lockset Latch Assemblies Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.18-C.pdf
T-Zone Lever Lockset Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.0-B.pdf
T-Zone Lever Lockset Rose Assembly Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.15-B.pdf
T-Zone Lever Lockset Standard & 31-Prefix Sleeve Assembly Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/11.16-C.pdf
parts-manual11-Line Parts Manualhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/SARGENT_11_Line_Bored_Lock_Parts_Manual-2.pdf
sell-sheet11 Line - Education Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/SAR_Tzone_SellSheet_Education.90757A.9_15.pdf
11 Line - Healthcare Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/SAR_Tzone_SellSheet_Healthcare.90731.9_15.pdf
Hurricane Resistant Bored Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/Windstorm_Bored.pdf

Specifications

Brand:
Sargent
Series:
11-Line T-Zone Bored Lever Locks
Manufacturer:
Sargent
Base Material:
Brass, Bronze
Bore Hole Diameter (in):
2-1/8"
Commercial Residential:
Commercial
Country Of Origin:
United States
Cylinder Type:
Conventional Cylinder
Finish:
626/US26D
Finish Description:
Satin Chrome
Fire Rated:
3 Hours {A}
Function:
05-Entrance or Office
Grade:
Grade 1
Latch Number:
11-2106
Lever/Knob/Pull:
Lever
Lever/Knob/Pull Design:
L Lever
Maximum Door Thickness (in):
2"
Number of Keys:
2
Rose/Escutcheon:
Rose
Rose/Escutcheon Design:
O Rose
Rose/Escutcheon Dimensions (in):
2-3/4"
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Number:
808
Sub-Type:
Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Uid:
SAR1002811G05OL26D
Url Title:
28-11g05-ol-26d
Title:
Sargent 28-11G05 OL 26D Cylindrical Lock
Sub Type:
Cylindrical Lock
Last Modified:
2023-09-27T07:34:37+00:00
Last Pricing:
2024-03-01T00:00:00+00:00
Msrp:
986
Finish Family:
Matte Silver
Popularity:
5
Pack Weight:
4.2
Pack Length:
8.25
Pack Width:
7.125
Pack Height:
4.25
Pack Volume:
249.8203125
Ul Listing:
ANSI A156.2, Series 4000, Grade 1, UL Listed
Ansi Code:
F81
Baa Qualified:
Yes
Limited Warranty:
10 Year
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
10
Vendor:
Assa Abloy
