Trine 3234WLC-26D 3000 Series Electric Strike 12/24VAC/DC Fail Secure3-3/4 x 1-1/4 Satin Chrome

Trine

Write a Review
SKU:
3234WLC-26D
$176.40
Trine 3234WLC-26D 3000 Series Electric Strike 12/24VAC/DC Fail Secure3-3/4 x 1-1/4 Satin Chrome
$176.40

Specifications

Brand:
Trine
Manufacturer:
Trine
Certification:
ANSI A156.31, Grade 1
Grade:
Grade 1
Dynamic Impact Strength:
70 foot-pounds
Electronic:
Yes
Application:
For Locksets having 5/8" Throw
Current:
715~743mA @ 12V, 397~378mA @24 VAC/VDC Current
Box Width (in):
1-1/8"
Frame Material:
Wood
Box Height (in):
2-3/4"
Specifications Bullet 11:
1 Year Warranty
Country of Origin:
United States
Commercial Residential:
Commercial
Fire Rated:
Yes
Base Material:
Brass or Bronze
Door Range (Thickness):
-
Box Depth (in):
1"
Finish:
626/US26D
Selling Quantity:
1
Finish Description:
Satin Chromium Plated
Includes:
334 Faceplate
Specifications Bullet 3:
(Regulated) Regulated Input
Door Handing:
Non-handed
Interior/Exterior:
Interior/Exterior
Specifications Bullet 4:
Includes 334 Faceplate
FS/FSE Mode:
Fail Secure
Dimensions:
1-1/8" x 2-3/4"
Specifications Bullet 1:
12/24 VAC/VDC Voltage Electric Strike
Series:
3000 Series Electric Strikes
Parent Manufacturer:
Not Applicable
Latch Throw (in):
5/8"
Specifications Bullet 7:
Fail Secure
Specifications Bullet 2:
For Locksets having 5/8" Throw
Product Warranty:
1 Year Warranty
Specifications Bullet 6:
715~743mA @ 12V, 397~378mA @24 VAC/VDC Current
Specifications Bullet 8:
1-1/8" x 2-3/4" Unit Dimension
Specifications Bullet 5:
1500 lbs Static Holding Strength
Static Holding Strength (lbs):
1500
Specifications Bullet 12:
Accepts 5/8" Latch Throw
Specifications Bullet 10:
ANSI A156.31, Grade 1
Specifications Bullet 9:
Accepts 5/8" Latch Throw
Resistance (Olm):
13 Ohms @ 12 VAC/DC
UOM:
1
Option 1:
(Regulated) Regulated Input
Voltage:
12/24 VAC/VDC Voltage
Uid:
TRI1003234WLC26D
Url Title:
3234wlc-26d
Title:
3234WLC-26D Trine Electric Strike
Type:
Electric Strikes, Bolts, Magnets
Sub Type:
Electric Strikes
Last Modified:
2023-02-28T05:07:36+00:00
Last Pricing:
2022-06-15T00:00:00+00:00
Msrp:
239
Avg Lead Time:
3
Finish Family:
Matte Silver
Popularity:
3
Limited Warranty:
1 Year
Unit Of Measure:
Each
Vendor:
Trine Access Technology
Assembly Item:
1

Warranty Information

1 Year Warranty
