  • Sargent 41 RL 32D 1-1/8 Mortise Cylinder RL Keyway Satin Stainless Steel

Sargent 41 RL 32D 1-1/8 Mortise Cylinder RL Keyway Satin Stainless Steel

Sargent

Write a Review
SKU:
41 RL 32D
$0.00
Sargent 41 RL 32D 1-1/8 Mortise Cylinder RL Keyway Satin Stainless Steel
$0.00

Descriptions

Sargent mortise cylinders are made from solid brass and have a brass, bronze or stainless steel face cap avaialable in all architechtural finishes. They are furnished standard with number 97 rosette and compression spring. Optional collars and spacers are available and ordered separately. Sargent mortise cylinders are available in lengths ranging from 1-1/8" through 3", minimum length for 7-Pin is 1-1/4". They are provided standard with Sargent offset cam number 13-0664, other cams are available.
TypeTitleURL
catalogSargent Cylinders and Components Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SAR_Cylinders_and_Components_Catalog.pdf

Specifications

Brand:
Sargent
Includes:
Trim (Installation) Ring
Specifications Bullet 2:
Conventional 6-pin RL Keyway 1-Bitted
Finish Description:
Satin Stainless Steel
Country Of Origin:
USA
CAM Number:
13-0664
Diameter (in):
1-5/32" Cylinder Diameter
Specifications Bullet 5:
1-5/32" Cylinder Diameter
Keyway:
RL Keyway
Specifications Bullet 3:
Includes Trim (Installation) Ring, 2 Keys
Specifications Bullet 1:
1-1/8" Mortise Cylinder
Door Range (Thickness):
-
Cylinder Type:
Conventional
Finish:
630/US32D
Number of Pins:
6-pin
Dimensions:
1-1/8"
Manufacturer:
Sargent
Specifications Bullet 4:
Includes 13-0664 Standard Offset CAM
Number of Keys:
2
CAM Description:
Standard Offset
Base Material:
Stainless Steel
Keying Detail:
1-Bitted
Parent Manufacturer:
Assa Abloy
Uid:
SAR10041RL32D
Url Title:
41-rl-32d
Title:
41 RL 32D Sargent Mortise Cylinder
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Cylinder
Series:
Mortise Cylinders
Last Modified:
2024-08-13T13:12:57+00:00
Last Pricing:
2024-03-01T00:00:00+00:00
Msrp:
125
Avg Lead Time:
17
Popularity:
3
Pack Weight:
0.525
Pack Length:
4.125
Pack Width:
2.375
Pack Height:
1.875
Pack Volume:
18.36914063
Baa Qualified:
Yes
Unit Of Measure:
Each
Assembly Item:
1
