Kaba Simplex 5067SWL-26D-41 Mortise Combination Lever Lock with Deadbolt and Lockout Schlage FSIC Prep Less Core Satin Chrome

Kaba Simplex

Write a Review
SKU:
5067SWL-26D-41
$666.53
Kaba Simplex 5067SWL-26D-41 Mortise Combination Lever Lock with Deadbolt and Lockout Schlage FSIC Prep Less Core Satin Chrome
UPC:
840067622117
$666.53

Descriptions

Simplex mechanical pushbutton locks offer a convenient way to control access between public and private areas. There are no keys or cards to manage, no computers to program, no batteries to replace, and combinations can be changed in seconds without removing the lock from the door.
TypeTitleURL
catalogSimplex Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/dormakaba/guides/KABA_catalog_simplex.pdf
installation-instructionsKaba Simplex Mechanical Pushbutton Lock - 5000 Series Exit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/dormakaba/installation_instructions/simplex-5000-exit-installation-instructions-pkg3054.pdf
Kaba Simplex Mechanical Pushbutton Lock - 5000 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/dormakaba/installation_instructions/simplex-5000-installation-instructions-pkg2842.pdf
price-book2024 Simplex Parts Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex-parts_1-2024.pdf
2024 Simplex Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex_1-2024.pdf
specsCSI Specifications for Simplex 5000 Series Mechanical Pushbutton Lockshttps://dvwi9lnoau63q.cloudfront.net/dormakaba/specifications/simplex-5000-csi-specifications.pdf
Technical Specifications for Simplex 5000 Series Mechanical Pushbutton Lockshttps://dvwi9lnoau63q.cloudfront.net/dormakaba/specifications/simplex-5000-specifications-kaa1052.pdf
videoSimplex 5000 - How to Change the Combination (Exterior Combination Change)https://youtu.be/L7XEw1k0mvw
Simplex 5000 - How to change the combination (interior Combination Change)https://youtu.be/gGDQurhuYWk
Simplex 5000 - How to Reset an Unknown Combinationhttps://youtu.be/bIogwFE_tec

Specifications

Brand:
Kaba Simplex
Country of Origin:
Mexico
Box Height (in):
1-1/8"
Latch Throw (in):
3/4"
Specifications Bullet 1:
Grade 1 Mortise PIN Access Pushbutton Lockset
Box Width (in):
4-3/4"
Lever/Knob/Pull Design:
(WL) Winston
Specifications Bullet 5:
Entrance with Deadbolt Function
Backset (in):
2-3/4"
Door Handing:
Non-handed
Rose/Escutcheon:
Escutcheon
Keyway:
Less Schlage Core
Specifications Bullet 8:
For Doors 1-3/4" - 2-1/4" Thick
Finish:
626/US26D
Parent Manufacturer:
DormaKaba
Door Range (Thickness):
1-3/4" - 2-1/4"
Latch Dimensions:
1-1/4" x 8"
Audit Trails:
Not Applicable
Electronic:
No
Cylinder Type:
Mortise LFIC Housing
Commercial/Residential:
Commercial
Grade:
Grade 1
Product Warranty:
3 Year Warranty
Base Material:
Brass or Bronze
Finish Description:
Satin Chrome
Specifications Bullet 3:
Mortise LFIC Housing Less Schlage Core
Latch Description:
Dead Latch
Specifications Bullet 7:
3-3/8" x 8-7/8" Escutcheon Dimension
ADA:
Yes
Series:
Simplex 5000 Series
Manufacturer:
DormaKaba
Can Be Keyed:
Yes
Specifications Bullet 6:
3-1/8" Projection
Function:
Entrance with Deadbolt
Box Weight (lbs):
9 lbs
Lever/Knob/Pull:
Lever
Certification:
BHMA Grade 1, UL Listed, A Label
Interior/Exterior:
Interior/Exterior
Deadbolt Throw (in):
1"
Box Depth (in):
11-3/4"
Includes Cylinder(s)?:
No
Strike Description:
ASA Strike
Specifications Bullet 2:
(WL) Winston Lever
Specifications Bullet 10:
3 Year Warranty
Pocket Dimensions:
6-5/8" x 4-1/2"
Projection (in):
3-1/8"
UOM:
1
Product Width (in):
3-3/8"
Specifications Bullet 9:
BHMA Grade 1, UL Listed, A Label
Rose/Escutcheon Dimensions (in):
3-3/8" x 8-7/8"
Strike Dimensions:
1-1/4" x 4-7/8"
Technology:
PIN Access
Product Height (in):
8-7/8"
Specifications Bullet 4:
Single Access Code
Maximum Door Thickness (in):
2-1/4"
Minimum Door Thickness (in):
1-3/4"
UPC:
840067622117
Selling Quantity:
1
User Codes:
1
Trademark Term:
Simplex
Type:
Mechanical Pushbutton
Uid:
SIM1005067SWL26D41
Url Title:
5067swl-26d-41
Title:
5067SWL-26D-41 DormaKaba Pushbutton Lock
Type:
Integrated and Pushbutton
Sub Type:
Mortise Locks with Keypad Trim
Last Modified:
2023-02-28T05:10:01+00:00
Last Pricing:
2022-09-30T00:00:00+00:00
Msrp:
837
Avg Lead Time:
98
Popularity:
6
Pack Weight:
11
Pack Length:
12
Pack Width:
10.25
Pack Height:
5
Unit Of Measure:
Each

Warranty Information

3 Year Warranty
