Sargent 56-8504F 32D Grade 1 Rim Exit Device Narrow Stile Pushpad 36 Device Night Latch Function Electric Latch Retraction Less Dogging Satin Stainless Steel Finish Field Reversible

Sargent

Write a Review
SKU:
56-8504F 32D
$2,574.54
$2,574.54

Descriptions

The Sargent 80 Series exit devices are ideal for environments that require strong and durable security solutions that will last the life of the building. Available in rim, mortise, surface vertical and concealed vertical rod configurations, these exit devices easily exceed ANSI/BHMA Grade 1 requirements for cycle and strength. With modular construction and few moving parts, the 80 Series devices are maintenance-free and provide unsurpassed security for any facility. Plus, options are available for unique applications including delayed egress, alarmed exit and electric latch retraction making these exit devices the go-to product in your building.
TypeTitleURL
brochure/sales-material80 Series Brochurehttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/90788_80_Series_Exit_Device_Brochure_FINAL.pdf
catalog80 Series Exit Device Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SAR_catalog_80-series_9-2022.pdf
installation-instructions16- 816 Cylinder Dogging Kit (80 Series Exit Device) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6848.pdf
43-Flush End Cap Rail Cutting Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7581B.pdf
55-Signal Switch for 80 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6808C.pdf
565 & 665 Metal End Cap Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6924B.pdf
57-Delayed Action 80 Series Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6810F_Sargent_57_Prefix_Instructions_5-5-2009.pdf
57-Delayed Egress for 80 Series Exit Devices to ElectroLynx Connector System Installationhttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7743E.pdf
59-Electroguard Delayed Egress for 80 Series Exit Devices Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7690G.pdf
8500 Series Narrow Design Rim Type Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6699N.pdf
AL- Alarmed Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7224C.pdf
Electric Dogging for 80 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6835C_58-12-58-Electric_Dogging_11-24-08.pdf
Mounting 80 Series Exit Device with Glass Bead Shim Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6710B.pdf
Video: 8500/8800 Exit Device Latchbolt Monitoring Adjustment Installationhttps://youtu.be/CCmqUVzyTgQ
literature80 Series Exit Device Environmental Product Declarationhttps://dvwi9lnoau63q.cloudfront.net/sargent/literature/130.1_ASSA_ABLOY_mrEPD_Sargent80SeriesMechanicalExit.pdf
80 Series Mechanical Panic Exit Device - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/sargent/literature/131.1_ASSA_ABLOY_mrEPD_SargentPanicExit80Series.pdf
Basic Fundamentals - Exit Deviceshttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/web_90691_SAR_Exits_Tech_lo.pdf
parts-list816 Cylinder Dogging Kit Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/80-9-D.pdf
parts-manual80 Series Parts Manualhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/80_Series_Parts_Manual.pdf
sell-sheet56-Electric Latch Retraction Exit Device Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/90625_SAR_56_Sell_lo.pdf
Windstorm Solutions - Exit Deviceshttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/90737_Windstorm_Exits.pdf

Specifications

Brand:
Sargent
Fire Rated:
No
Center Case Dimensions:
8-3/8" x 2-5/8"
Specifications Bullet 5:
600mA Retraction, 250mA Holding Current
Includes Cylinder(s)?:
No
End Cap Material:
Steel
Can Be Keyed:
No
Door Height (in):
Not Applicable
Specifications Bullet 2:
Less Cylinder
Cylinder Type:
Less Cylinder
Grade:
Grade 1
Certification:
ANSI A156.3, Grade 1, UL Listed
Latch Throw (in):
3/4"
Specifications Bullet 12:
Includes Metal/Wood Screws
Function:
Night Latch
Specifications Bullet 14:
5 Year Warranty
Country Of Origin:
USA
Current:
600mA Retraction, 250mA Holding Current
Dogging Type:
Electronic Dogging
Specifications Bullet 1:
Electrified Surface Exit Device
Door Width Minimum (in):
33"
Specifications Bullet 4:
24 VDC Voltage
Specifications Bullet 8:
3" Projection
Specifications Bullet 3:
(56) Remote Latch Retraction
Door Range (Thickness):
1-3/4" - 2-1/4"
Electronic:
Yes
Specifications Bullet 7:
4-1/2" Minimum Stile
Door Width Maximum (in):
36"
Specifications Bullet 11:
Electronic Dogging
Finish Description:
Satin Stainless Steel
Maximum Door Thickness (in):
2-1/4"
Finish:
630/US32D
Specifications Bullet 6:
For Doors 33" - 36" Wide
Dogging Option:
Yes
Commercial Residential:
Commercial
Door Handing:
Right Hand Reverse
Latch Description:
Solid Throw
Product Width (in):
36"
Specifications Bullet 13:
ANSI A156.3, Grade 1, UL Listed
Keyway:
Not Applicable
Option 1:
(56) Remote Latch Retraction
Selling Quantity:
1
Specifications Bullet 9:
For Doors 1-3/4" - 2-1/4" Thick
Minimum Door Thickness (in):
1-3/4"
Door Material:
Metal/Wood
Product Warranty:
5 Year Warranty
Minimum Stile (in):
4-1/2"
Series:
8500 Series Narrow Rim Exit Devices
Strike Number:
649
Projection (in):
3"
UOM:
1
Manufacturer:
Sargent
Specifications Bullet 10:
3/4" Latch Throw
Screw Pack:
Metal/Wood Screws
Type:
Surface Exit Device
Parent Manufacturer:
Assa Abloy
Base Material:
Stainless Steel
Voltage:
24 VDC Voltage

Warranty Information

5 Year Warranty
