  • BEST 7KC27AB16DS3606 Grade 2 Entry Cylindrical Lock 16 Lever SFIC Less Core Satin Brass Finish Non-handed

BEST 7KC27AB16DS3606 Grade 2 Entry Cylindrical Lock 16 Lever SFIC Less Core Satin Brass Finish Non-handed

BEST

Write a Review
SKU:
7KC27AB16DS3606
$314.87
BEST 7KC27AB16DS3606 Grade 2 Entry Cylindrical Lock 16 Lever SFIC Less Core Satin Brass Finish Non-handed
$314.87

Descriptions

7KC Listed by Underwriters Laboratories for use on 3 hour, A label single swinging doors (4' x 8' ). Certification- This product is listed in BHMA Directory of Certified Locks and Latches as conforming to ANSI A156.3, Grade 2. California Administrative Code Title 19 and 24. Illinois Accessibility Standard.
TypeTitleURL
catalogCylindrical Locks - 7KC Series Cataloghttps://dvwi9lnoau63q.cloudfront.net/best/catalogs/BEST_7KC_Catalog_BA-0026_050319_WEB.pdf
installation-instructionsCylindrical Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/best/installation/T80919_-_Correction__to_Cylindrical_Installation_Instructions.pdf
Installation Instructions for 72KC-75KC Cylindrical Lockshttps://dvwi9lnoau63q.cloudfront.net/best/installation/T80622b_-_Installation_Instructions_for_72KC-75KC_Cylindrical_Locks.pdf
Installation Instructions for 72KC-75KC Key-in-Knob Cylindershttps://dvwi9lnoau63q.cloudfront.net/best/installation/T81146b_-_Installation_Instructions_for_72KC-75KC_Key-in-Knob_Cylinders.pdf
Installation Instructions for 7K Cylindrical Lockshttps://dvwi9lnoau63q.cloudfront.net/best/installation/T56062_-_Installation_Instructions_for_7K_Cylindrical_Locks.pdf
Installation Instructions for 7K Dummy Trimshttps://dvwi9lnoau63q.cloudfront.net/best/installation/T56151_-_Installation_Instructions_for_7K_Dummy_Trim.pdf
Installation Instructions for 7KC 1DT 9K 1DT 2DT Dummy Trim Assemblieshttps://dvwi9lnoau63q.cloudfront.net/best/installation/T56076b_-_Installation_Instructions_for_7KC_1DT_9K_1DT_2DT_Dummy_Trim_Assemblies.pdf
sell-sheet7KC Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/best/sell-sheets/BEST_7KC_Sell_Sheet_WEB_1.pdf
service-manual7KC Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/best/service-manuals/T80621b_-_7KC_Series_Service_Manual.pdf

Specifications

Brand:
BEST
Manufacturer:
BEST
ADA:
Yes
Parent Manufacturer:
DormaKaba
Series:
7KC Series Grade 2 Cylindrical Lever Locks
Backset (in):
2-3/8"
Can Be Keyed:
Yes
Commercial Residential:
Commercial
Base Material:
Brass
Certification:
ANSI A156.2, Series 4000, Grade 2, ANSI A117.1 Section 404.2.6 (ADA)
Bore Hole Diameter (in):
2-1/8"
Door Handing:
Non-handed
Electronic:
No
Country Of Origin:
Taiwan
Cylinder Type:
SFIC Housing
Door Range (Thickness):
1-3/8" - 2"
Finish:
606/US4
Grade:
Grade 2
Finish Description:
Satin Brass
Fire Rated:
3 Hours {A}
Function:
Entrance
Includes Cylinder(s)?:
No
Latch Description:
Dead Latch
Latch Bore Diameter (in):
1"
Latch Dimensions:
1-1/8" x 2-1/4"
Keyway:
Less Core
Latch Number:
L3
Lever/Knob/Pull:
Lever
Specifications Bullet 1:
Grade 2 Entrance Function Cylindrical Lockset
Latch Throw (in):
1/2"
Lever/Knob/Pull Design:
16
Specifications Bullet 4:
2-3/8" Backset
Specifications Bullet 2:
16 Lever
Specifications Bullet 3:
SFIC Housing Less Core
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 2, ANSI A117.1 Section 404.2.6 (ADA)
Specifications Bullet 7:
2-1/2" Projection
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Specifications Bullet 8:
3-1/2" D Rose
Specifications Bullet 9:
For Doors 1-3/8" - 2" Thick
Maximum Door Thickness (in):
2"
Minimum Door Thickness (in):
1-3/8"
Projection (in):
2-1/2"
Product Warranty:
3 Year Warranty
Specifications Bullet 12:
3 Year Warranty
Rose/Escutcheon Design:
D
Rose/Escutcheon:
Rose
Strike Description:
ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon Dimensions (in):
3-1/2"
UOM:
1
Strike Number:
S3
Uid:
BES1007KC27AB16DS3606
Url Title:
7kc27ab16ds3606
Title:
BEST 7KC27AB16DS3606 Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-26T05:32:52+00:00
Last Pricing:
2022-09-30T00:00:00+00:00
Msrp:
421
Avg Lead Time:
13
Finish Family:
Matte Brass
Popularity:
9
Pack Weight:
3.6
Pack Length:
8.25
Pack Width:
6.625
Pack Height:
4
Pack Volume:
218.625
Ul Listing:
BHMA A156.2, Series 4000, Grade 2, UL Listed
Ansi Code:
F109
Limited Warranty:
3 Year Warranty
Accessible:
Yes
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
9
Vendor:
DormaKaba
Assembly Item:
1

Warranty Information

3 Year Warranty
