  • Von Duprin 9847EO-F 3 26D LBR Grade 1 Concealed Vertical Rod Exit Bar Wide Stile Pushpad 36 Fire-rated Device 80 to 100 Door Height Exit Only Less Bottom Rod Less Dogging Satin Chrome Finish Field Reversible

Von Duprin 9847EO-F 3 26D LBR Grade 1 Concealed Vertical Rod Exit Bar Wide Stile Pushpad 36 Fire-rated Device 80 to 100 Door Height Exit Only Less Bottom Rod Less Dogging Satin Chrome Finish Field Reversible

Von Duprin

Write a Review
SKU:
9847EO-F 3 26D LBR
$2,467.48
Von Duprin 9847EO-F 3 26D LBR Grade 1 Concealed Vertical Rod Exit Bar Wide Stile Pushpad 36 Fire-rated Device 80 to 100 Door Height Exit Only Less Bottom Rod Less Dogging Satin Chrome Finish Field Reversible
$2,467.48

Descriptions

9847/9947 Concealed vertical rod device for use on single or double metal doors, UL listed for panic exit hardware. The 9847 device has a smooth mechanism case and the 9947 device has a grooved case.
TypeTitleURL
brochure/sales-materialVon Duprin Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/vonduprin/miscellaneous/ALLEGION_finish-chart.pdf
catalogVon Duprin 98/99 Series Cataloghttps://dvwi9lnoau63q.cloudfront.net/vonduprin/catalogs/Von_Duprin_98.99_Series_Catalog_106590.pdf
data-sheetChexit (CX) Data Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/Von_Duprin_Chexit_Data_Sheet_110102.pdf
QEL Data Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/106586.pdf
installation-instructionsCX98/9947WDC Installations Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/109254.pdf
QEL 98/99 Baseplate Conversion Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/110746.pdf
QEL Conversion Kit for 98/99 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/110745.pdf
Von Duprin 33/35 and 98/99 ALK Alarm Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/107710.pdf
Von Duprin 33/35 and 98/99 End Cap Retrofit Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/109265.pdf
Von Duprin LD Cover Plate for 33/35 & 98/99 Exit Devices Installation Instructionhttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/109279.pdf
Von Duprin Pneumatic Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/107614.pdf
miscellaneousQuiet Electric Latch FAQhttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/110624.pdf
price-book2024 Von Duprin Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/vonduprin/pricebooks/VON_pricebook_3-2024.pdf
sell-sheetQEL Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/103226.pdf
Von Duprin Exit Alarm Kit Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/105255.pdf
service-manual98/9947 Service Manualhttps://dvwi9lnoau63q.cloudfront.net/vonduprin/common-part-manuals/105675.pdf
template98/9947F and 98/9948F Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/templates/VD_98_9947-F_98_9948-F_Concealed_Vertical_Rod_Template.pdf
CX98/9947 and CX98/9948 Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/templates/VD_CX98_9947-F_CX98_9948-F_Concealed_Vertical_Rod_Template.pdf
EL, SS, CX9847WDC/9947WDC Series Device Hinge Stile Preparation Wood Door Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/wood-templates/108937.pdf

Specifications

Brand:
Von Duprin
Specifications Bullet 7:
For Doors 1-3/4" - 2-1/8" Thick
Finish Description:
Satin Chrome
Door Width Maximum (in):
48"
Certification:
ANSI A156.3-2014, Grade 1
Latch Description:
Top Latchbolt
Function:
Exit Only
Latch Throw (in):
5/8"
Dogging Type:
Not Applicable
Finish:
626/US26D
Cylinder Type:
Keyless
Specifications Bullet 2:
(LBR) Less Bottom Rod
Fire Rated:
Yes {Variable}
Specifications Bullet 4:
2-3/4" Backset
Center Case Dimensions:
8" x 2-3/4" x 2-3/8"
Parent Manufacturer:
Allegion
Keyway:
Not Applicable
Door Height (in):
84"
End Cap Material:
Cast Zinc
Specifications Bullet 10:
5/8" Top Latchbolt
Specifications Bullet 12:
Includes Machine Screws
Specifications Bullet 1:
Fire Rated Concealed Vertical Rod Exit Device, Exit Only
Door Material:
Metal/Wood
Country Of Origin:
USA
Option 1:
(LBR) Less Bottom Rod
Base Material:
Brass Bronze
UOM:
1
Minimum Stile (in):
3-3/4"
Includes Cylinder(s)?:
No
Specifications Bullet 6:
For Doors 34" - 48" Wide
Electronic:
No
Specifications Bullet 3:
3-3/4" Minimum Stile
Specifications Bullet 11:
Cast Zinc End Cap
Door Range (Thickness):
1-3/4" - 2-1/8"
Door Handing:
Non-handed
Manufacturer:
Von Duprin
Dogging Option:
No
Product Warranty:
3 Year Warranty
Door Width Minimum (in):
34"
Specifications Bullet 13:
ANSI A156.3-2014, Grade 1
Commercial Residential:
Commercial
Strike Number:
338/385A
Specifications Bullet 8:
For Metal/Wood Doors
Maximum Door Thickness (in):
2-1/8"
Specifications Bullet 9:
3-13/16" Full Extension
Strike Description:
Solid Catch Strike
Type:
Exit Devices
Screw Pack:
Machine Screws
Specifications Bullet 14:
3 Year Warranty
Minimum Door Thickness (in):
1-3/4"
Selling Quantity:
1
Backset (in):
2-3/4"
Specifications Bullet 5:
8" x 2-3/4" x 2-3/8" Center Case Dimension
Grade:
Grade 1
Projection (in):
3-13/16"
Series:
98 Series
Product Width (in):
48"

Warranty Information

3 Year Warranty
