Corbin Russwin CL3350 NZD 626 Grade 1 Half Dummy Trim Cylindrical Lock Newport Lever Non-Keyed Satin Chrome Finish Non-handed

Corbin Russwin

Write a Review
SKU:
CL3350 NZD 626
$172.56
Corbin Russwin CL3350 NZD 626 Grade 1 Half Dummy Trim Cylindrical Lock Newport Lever Non-Keyed Satin Chrome Finish Non-handed
UPC:
840067630464
$172.56

Descriptions

The CL3300 series is a Grade 1 cylindrical lockset manufactured with the highest quality materials to ensure strength, durability and quiet operation. Available in all standard architectural finishes and four lever designs, the CL3300 series subtly complements any high-use commercial, industrial and institutional application.
TypeTitleURL
catalogCL3300 Series Cylindrical Lock Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/Corbin_Russwin_CL3300_Series_Cylindrical_Lock_Catalog.pdf
installation-instructionsCL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
literatureCL3300 Series Cylindrical Lock - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/corbin/literature/124.1_ASSA_ABLOY_mrEPD_Corbin_Russwin_CL3300_Series_Lock.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf

Specifications

Brand:
Corbin Russwin
Grade:
Grade 1
Commercial Residential:
Commercial
Backset (in):
Not Applicable
Latch Number:
Not Applicable
Door Range (Thickness):
1-3/4" - 2"
Electronic:
No
Latch Bore Diameter (in):
Not Applicable
Latch Dimensions:
Not Applicable
Latch Throw (in):
Not Applicable
Cylinder Type:
Keyless
Rose/Escutcheon Design:
D
Door Handing:
Non-handed
Lever/Knob/Pull:
Lever
Fire Rated:
3 Hours {A}
Keyway:
Not Applicable
Specifications Bullet 4:
3-1/2" D Rose
Specifications Bullet 2:
Newport Lever
Box Weight (lbs):
4.8 lbs
Certification:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Finish Description:
Satin Chrome
Specifications Bullet 1:
Grade 1 Dummy Function Cylindrical Lockset
Strike Dimensions:
Not Applicable
Box Height (in):
4-1/2"
Function:
Dummy
Rose/Escutcheon Dimensions (in):
3-1/2"
Parent Manufacturer:
Assa Abloy
Specifications Bullet 3:
2-13/16" Projection
Specifications Bullet 5:
For Doors 1-3/4" - 2" Thick
Country Of Origin:
United States
Latch Description:
Not Applicable
Specifications Bullet 7:
7 Year Limited Warranty
Lever/Knob/Pull Design:
Newport
Product Warranty:
7 Year Limited Warranty
Finish:
626/US26D
UOM:
1
Can Be Keyed:
No
Projection (in):
2-13/16"
Rose/Escutcheon:
Rose
Strike Description:
Not Applicable
Box Width (in):
7-1/2"
Selling Quantity:
1
Minimum Door Thickness (in):
1-3/4"
UPC:
840067630464
Series:
CL3300 Series Grade 1 Cylindrical Lever Locks
Maximum Door Thickness (in):
2"
Strike Number:
Not Applicable
Includes Cylinder(s)?:
No
Manufacturer:
Corbin Russwin
Bore Hole Diameter (in):
Not Applicable
Specifications Bullet 6:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
ADA:
Yes
Base Material:
Brass Bronze
Box Depth (in):
10"
Uid:
COR300CL3350NZD626
Url Title:
cl3350-nzd-626
Title:
Corbin Russwin CL3350 NZD 626 Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-28T05:35:22+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
255
Avg Lead Time:
20
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
7
Pack Length:
10
Pack Width:
8
Pack Height:
4.5
Pack Volume:
360
Ul Listing:
ANSI A156.2, Series 4000, Grade 1, UL Listed
Limited Warranty:
7 Year Warranty
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
6
Base Material:
Brass, Bronze
Vendor:
ASSA ABLOY
Assembly Item:
1

Warranty Information

7 Year Limited Warranty
