Corbin Russwin CL3357 NZD 626 CL6 Grade 1 Storeroom/Closet Cylindrical Lock Newport Lever LFIC 6-Pin Less Core Satin Chrome Finish Non-handed

Corbin Russwin

Write a Review
SKU:
CL3357 NZD 626 CL6
$556.88
Corbin Russwin CL3357 NZD 626 CL6 Grade 1 Storeroom/Closet Cylindrical Lock Newport Lever LFIC 6-Pin Less Core Satin Chrome Finish Non-handed
UPC:
840067630914
$556.88

Descriptions

The CL3300 series is a Grade 1 cylindrical lockset manufactured with the highest quality materials to ensure strength, durability and quiet operation. Available in all standard architectural finishes and four lever designs, the CL3300 series subtly complements any high-use commercial, industrial and institutional application.
TypeTitleURL
catalogCL3300 Series Cylindrical Lock Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/Corbin_Russwin_CL3300_Series_Cylindrical_Lock_Catalog.pdf
installation-instructionsCL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
literatureCL3300 Series Cylindrical Lock - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/corbin/literature/124.1_ASSA_ABLOY_mrEPD_Corbin_Russwin_CL3300_Series_Lock.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf

Specifications

Brand:
Corbin Russwin
Includes Cylinder(s)?:
No
Latch Bore Diameter (in):
1"
Specifications Bullet 1:
Grade 1 Storeroom Function Cylindrical Lockset
Parent Manufacturer:
Assa Abloy
Box Width (in):
7-1/2"
Finish:
626/US26D
Box Height (in):
4-1/2"
Latch Dimensions:
1-1/8" x 2-1/4"
Door Range (Thickness):
1-3/4" - 2"
Maximum Door Thickness (in):
2"
Cylinder Type:
LFIC Housing
UOM:
1
Specifications Bullet 7:
2-13/16" Projection
Box Depth (in):
10"
Fire Rated:
3 Hours {A}
Can Be Keyed:
Yes
Specifications Bullet 2:
Newport Lever
Bore Hole Diameter (in):
2-1/8"
Lever/Knob/Pull:
Lever
Rose/Escutcheon Design:
D
Country Of Origin:
United States
Box Weight (lbs):
4.8 lbs
Lever/Knob/Pull Design:
Newport
Latch Number:
586F17
Base Material:
Brass, Bronze
Grade:
Grade 1
Latch Throw (in):
1/2"
Minimum Door Thickness (in):
1-3/4"
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Latch Description:
Dead Latch
Strike Dimensions:
1-1/4" x 4-7/8"
Certification:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Commercial Residential:
Commercial
Specifications Bullet 8:
3-1/2" D Rose
Keyway:
Less Core
Door Handing:
Non-handed
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 12:
7 Year Limited Warranty
Function:
Storeroom
Electronic:
No
Specifications Bullet 3:
LFIC Housing Less Core
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Specifications Bullet 4:
2-3/4" Backset
Finish Description:
Satin Chrome
ADA:
Yes
Strike Description:
ASA Strike
Product Warranty:
7 Year Limited Warranty
UPC:
840067630914
Specifications Bullet 9:
For Doors 1-3/4" - 2" Thick
Rose/Escutcheon Dimensions (in):
3-1/2"
Rose/Escutcheon:
Rose
Projection (in):
2-13/16"
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Selling Quantity:
1
Manufacturer:
Corbin Russwin
Series:
CL3300 Series
Strike Number:
217L13
Backset (in):
2-3/4"

Warranty Information

7 Year Limited Warranty
