Corbin Russwin CL3362 NZD 626 CL6 Grade 1 Communicating Cylindrical Lock Newport Lever LFIC 6-Pin Less Core Satin Chrome Finish Non-handed

Corbin Russwin

Write a Review
SKU:
CL3362 NZD 626 CL6
$639.69
Corbin Russwin CL3362 NZD 626 CL6 Grade 1 Communicating Cylindrical Lock Newport Lever LFIC 6-Pin Less Core Satin Chrome Finish Non-handed
UPC:
840067631300
$639.69

Descriptions

The CL3300 series is a Grade 1 cylindrical lockset manufactured with the highest quality materials to ensure strength, durability and quiet operation. Available in all standard architectural finishes and four lever designs, the CL3300 series subtly complements any high-use commercial, industrial and institutional application.
TypeTitleURL
catalogCL3300 Series Cylindrical Lock Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/Corbin_Russwin_CL3300_Series_Cylindrical_Lock_Catalog.pdf
installation-instructionsCL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
literatureCL3300 Series Cylindrical Lock - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/corbin/literature/124.1_ASSA_ABLOY_mrEPD_Corbin_Russwin_CL3300_Series_Lock.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf

Specifications

Brand:
Corbin Russwin
Finish Description:
Satin Chrome
Specifications Bullet 7:
2-13/16" Projection
Certification:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Cylinder Type:
LFIC Housing
Base Material:
Brass, Bronze
Specifications Bullet 4:
2-3/4" Backset
Finish:
626/US26D
Grade:
Grade 1
Specifications Bullet 2:
Newport Lever
Lever/Knob/Pull Design:
Newport
Projection (in):
2-13/16"
Box Depth (in):
10"
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Country Of Origin:
United States
Rose/Escutcheon:
Rose
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Box Height (in):
4-1/2"
Door Range (Thickness):
1-3/4" - 2"
Box Weight (lbs):
4.8 lbs
Specifications Bullet 1:
Grade 1 Communicating Function Cylindrical Lockset
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Number:
217L13
Latch Number:
586F17
ADA:
Yes
Latch Description:
Dead Latch
Electronic:
No
Includes Cylinder(s)?:
No
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Door Handing:
Non-handed
Commercial Residential:
Commercial
Latch Throw (in):
1/2"
Rose/Escutcheon Design:
D
Can Be Keyed:
Yes
Bore Hole Diameter (in):
2-1/8"
Specifications Bullet 8:
3-1/2" D Rose
Latch Dimensions:
1-1/8" x 2-1/4"
UPC:
840067631300
Minimum Door Thickness (in):
1-3/4"
UOM:
1
Rose/Escutcheon Dimensions (in):
3-1/2"
Keyway:
Less Core
Function:
Communicating
Specifications Bullet 3:
LFIC Housing Less Core
Fire Rated:
3 Hours {A}
Backset (in):
2-3/4"
Specifications Bullet 12:
7 Year Limited Warranty
Series:
CL3300 Series Grade 1 Cylindrical Lever Locks
Latch Bore Diameter (in):
1"
Lever/Knob/Pull:
Lever
Parent Manufacturer:
Assa Abloy
Product Warranty:
7 Year Limited Warranty
Box Width (in):
7-1/2"
Maximum Door Thickness (in):
2"
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Strike Description:
ASA Strike
Selling Quantity:
1
Specifications Bullet 9:
For Doors 1-3/4" - 2" Thick
Manufacturer:
Corbin Russwin

Warranty Information

7 Year Limited Warranty
