  • Corbin Russwin CL3393 PZD 626 LC Grade 1 Service Station Cylindrical Lock Princeton Lever Conventional Less Cylinder Satin Chrome Finish Non-handed

Corbin Russwin CL3393 PZD 626 LC Grade 1 Service Station Cylindrical Lock Princeton Lever Conventional Less Cylinder Satin Chrome Finish Non-handed

Corbin Russwin

Write a Review
SKU:
CL3393 PZD 626 LC
$606.00
Corbin Russwin CL3393 PZD 626 LC Grade 1 Service Station Cylindrical Lock Princeton Lever Conventional Less Cylinder Satin Chrome Finish Non-handed
UPC:
840067631768
$606.00

Descriptions

The CL3300 series is a Grade 1 cylindrical lockset manufactured with the highest quality materials to ensure strength, durability and quiet operation. Available in all standard architectural finishes and four lever designs, the CL3300 series subtly complements any high-use commercial, industrial and institutional application.
TypeTitleURL
catalogCL3300 Series Cylindrical Lock Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/Corbin_Russwin_CL3300_Series_Cylindrical_Lock_Catalog.pdf
installation-instructionsCL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
literatureCL3300 Series Cylindrical Lock - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/corbin/literature/124.1_ASSA_ABLOY_mrEPD_Corbin_Russwin_CL3300_Series_Lock.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf

Specifications

Brand:
Corbin Russwin
Parent Manufacturer:
Assa Abloy
Country Of Origin:
United States
Latch Dimensions:
1-1/8" x 2-1/4"
Manufacturer:
Corbin Russwin
Lever/Knob/Pull:
Lever
Door Handing:
Non-handed
Finish Description:
Satin Chrome
Selling Quantity:
1
Commercial Residential:
Commercial
Grade:
Grade 1
Bore Hole Diameter (in):
2-1/8"
Keyway:
Less Core
Box Depth (in):
10"
Function:
Service Station
Specifications Bullet 1:
Grade 1 Service Station Function Cylindrical Lockset
Latch Throw (in):
1/2"
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 7:
2-13/16" Projection
Can Be Keyed:
Yes
Box Weight (lbs):
4.8 lbs
Latch Number:
586F18
Cylinder Type:
Conventional
Door Range (Thickness):
1-3/4" - 2"
Finish:
626/US26D
Latch Bore Diameter (in):
1"
UPC:
840067631768
ADA:
Yes
Fire Rated:
3 Hours {A}
Box Height (in):
4-1/2"
Electronic:
No
Certification:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Box Width (in):
7-1/2"
Specifications Bullet 3:
Conventional Less Core
Maximum Door Thickness (in):
2"
Specifications Bullet 9:
For Doors 1-3/4" - 2" Thick
Specifications Bullet 2:
Princeton Lever
Projection (in):
2-13/16"
Includes Cylinder(s)?:
No
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Product Warranty:
7 Year Limited Warranty
Base Material:
Brass, Bronze
Rose/Escutcheon:
Rose
Specifications Bullet 8:
3-1/2" D Rose
Latch Description:
Dead Latch
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Minimum Door Thickness (in):
1-3/4"
Strike Number:
217L13
Lever/Knob/Pull Design:
Princeton
Backset (in):
2-3/4"
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Rose/Escutcheon Design:
D
Rose/Escutcheon Dimensions (in):
3-1/2"
Specifications Bullet 12:
7 Year Limited Warranty
Strike Dimensions:
1-1/4" x 4-7/8"
Series:
CL3300 Series
Strike Description:
ASA Strike
UOM:
1
Uid:
COR300CL3393PZD626LC
Url Title:
cl3393-pzd-626-lc
Title:
Corbin Russwin CL3393 PZD 626 LC Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Series:
CL3300 Series Grade 1 Cylindrical Lever Locks
Last Modified:
2023-02-13T09:49:45+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
810
Finish Family:
Matte Silver
Popularity:
8
Pack Weight:
7
Pack Length:
10
Pack Width:
8
Pack Height:
4.5
Pack Volume:
360
Ul Listing:
ANSI A156.2, Series 4000, Grade 1, UL Listed
Ansi Code:
F92
Limited Warranty:
7 Year Warranty
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
6
Vendor:
ASSA ABLOY
Assembly Item:
1

Warranty Information

7 Year Limited Warranty
