Corbin Russwin CL3810 AZD 612 Grade 2 Passage or Closet Cylindrical Lock Armstrong Lever Satin Bronze Clear Coated Finish Non-handed

Corbin Russwin

Write a Review
SKU:
CL3810 AZD 612
$210.49
Corbin Russwin CL3810 AZD 612 Grade 2 Passage or Closet Cylindrical Lock Armstrong Lever Satin Bronze Clear Coated Finish Non-handed
UPC:
840067632420
$210.49

Descriptions

TypeTitleURL
catalogCL3800 Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/Corbin_Russwin_CL3800_Series_Cylindrical_Lock_Catalog.pdf
installation-instructionsCL3800 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM249.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf
sell-sheetCL3800 Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/corbin/sell-sheets/CL3800_Series_Sell_Sheet.pdf
templateCL3800 Series Templatehttps://dvwi9lnoau63q.cloudfront.net/corbin/templates/CL3800_Series_Template.pdf
CL3850 & CL3870 Dummy Trim Templatehttps://dvwi9lnoau63q.cloudfront.net/corbin/templates/Corbin_Russwin_CL3350_and_CL3370_Series_Trim_Template.pdf
SC Series Curved Lip Box Strike Templatehttps://dvwi9lnoau63q.cloudfront.net/corbin/templates/Corbin_Russwin_SC_Series_Curved_Strike_Template.pdf
SF114 & SFR114 Full Lip Strike Templatehttps://dvwi9lnoau63q.cloudfront.net/corbin/templates/Corbin_Russwin_CK4700_Series_SF114_and_SFR114_Strike_Template.pdf
SR118 Rabbeted Front & Strike Templatehttps://dvwi9lnoau63q.cloudfront.net/corbin/templates/Corbin_Russwin_SR118_Option_Template.pdf

Specifications

Brand:
Corbin Russwin
ADA:
Yes
Lever/Knob/Pull:
Lever
Box Depth (in):
10"
Box Width (in):
7-1/2"
Specifications Bullet 6:
2-13/16" Projection
Parent Manufacturer:
Assa Abloy
Commercial Residential:
Commercial
Door Handing:
Non-handed
Cylinder Type:
Keyless
Backset (in):
2-3/4"
Latch Throw (in):
1/2"
Specifications Bullet 2:
Armstrong Lever
Specifications Bullet 1:
Grade 2 Passage Function Cylindrical Lockset
Grade:
Grade 2
Function:
Passage
Bore Hole Diameter (in):
2-1/8"
Specifications Bullet 4:
1-1/8" x 2-1/4" Spring Latch
Specifications Bullet 7:
3-1/2" D Rose
Series:
CL3800 Series Grade 2 Cylindrical Lever Locks
Box Weight (lbs):
4.1 lbs
Latch Description:
Spring Latch
Specifications Bullet 8:
For Doors 1-3/8" - 1-7/8" Thick
Latch Bore Diameter (in):
1"
Finish:
612/US10
Keyway:
Not Applicable
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Box Height (in):
4-1/2"
Door Range (Thickness):
1-3/8" - 1-7/8"
Electronic:
No
Latch Dimensions:
1-1/8" x 2-1/4"
Certification:
ANSI A156.2, Series 4000, Grade 2, A117.1, UL Listed
Finish Description:
Satin Bronze Clear Coated
Specifications Bullet 9:
2-1/8" Bore Hole Diameter
Rose/Escutcheon:
Rose
Base Material:
Bronze
Fire Rated:
3 Hours {A}
Lever/Knob/Pull Design:
Armstrong
Rose/Escutcheon Design:
D
Can Be Keyed:
No
Specifications Bullet 10:
ANSI A156.2, Series 4000, Grade 2, A117.1, UL Listed
Maximum Door Thickness (in):
1-7/8"
Includes Cylinder(s)?:
No
Projection (in):
2-13/16"
Specifications Bullet 11:
7 Year Limited Warranty
Latch Number:
600F09
Country Of Origin:
USA
Minimum Door Thickness (in):
1-3/8"
Specifications Bullet 3:
2-3/4" Backset
Product Warranty:
7 Year Limited Warranty
Strike Number:
217L13
Selling Quantity:
1
Rose/Escutcheon Dimensions (in):
3-1/2"
Strike Description:
ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
UPC:
840067632420
Manufacturer:
Corbin Russwin
UOM:
1

Warranty Information

7 Year Limited Warranty
