Arrow D63 26D Deadbolt Cylinder x Blank Plate Satin Chrome

Arrow

Write a Review
SKU:
D63 26D
$96.21
Arrow D63 26D Deadbolt Cylinder x Blank Plate Satin Chrome
UPC:
840067636831
$96.21

Descriptions

Arrow D Series deadlocks are engineered to perform under themost extreme conditions where security is critical. Our Grade 1 extra heavy duty deadlock surpasses the demands of industrial, institutional and commercial applications.
TypeTitleURL
catalog2014 Arrow Full Line Cataloghttps://dvwi9lnoau63q.cloudfront.net/arrow/catalog/ARR_catalog_2014.pdf
D800, DB600 Technical Cataloghttps://dvwi9lnoau63q.cloudfront.net/arrow/catalogs/d800-db600-5-16-lo-pdf.pdf
cut-sheetD Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/DSeries.pdf
Management Control Deadbolt Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/MgmtControl.pdf
instructionsD Series Instructions - IChttps://dvwi9lnoau63q.cloudfront.net/arrow/instructions/D_IC_Install_Inst.pdf
price-book2023 Arrow Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/arrow/pricebooks/ARR_pricebook_4-2023.pdf
2024 Arrow Price Book (effective 3.1.2024)https://dvwi9lnoau63q.cloudfront.net/arrow/pricebooks/ARR_pricebook_3-2024.pdf

Specifications

Brand:
Arrow
Certification:
ANSI A156.5, Grade 1, UL Listed
Specifications Bullet 1:
Grade 1 Cylinder Deadbolt
Latch Dimensions:
1-1/8" x 2-1/4"
Finish Description:
Satin Chrome
Door Handing:
Non-handed
Electronic:
No
Strike Description:
Rectangle Strike
Latch Number:
144
Specifications Bullet 4:
1-1/8" x 2-3/4" Rectangle Strike
Finish:
626/US26D
Minimum Door Thickness (in):
1-3/8"
Cylinder Type:
Conventional
Grade:
Grade 1
Function:
Cylinder
Specifications Bullet 2:
Conventional A Keyway
Latch Description:
Square Corner
Interior/Exterior:
Interior/Exterior
Box Height (in):
2-3/4"
Specifications Bullet 7:
1-1/8" x 2-1/4" Latch Dimension
Specifications Bullet 3:
2-3/4" Backset
Includes Cylinder(s)?:
Yes
Specifications Bullet 8:
2-1/8" Bore Hole Diameter
Latch Bore Diameter (in):
1"
Specifications Bullet 6:
1" Deadbolt Throw
Base Material:
Brass Bronze
Specifications Bullet 5:
For Doors 1-3/8" - 1-3/4" Thick
Strike Dimensions:
1-1/8" x 2-3/4"
Keyway:
A Keyway
Maximum Door Thickness (in):
1-3/4"
Can Be Keyed:
Yes
Deadbolt Throw (in):
1"
Box Depth (in):
4"
Country of Origin:
Mexico
UOM:
1
Manufacturer:
Arrow
Specifications Bullet 9:
ANSI A156.5, Grade 1, UL Listed
Number of Keys:
2
UPC:
840067636831
Door Range (Thickness):
1-3/8" - 1-3/4"
Selling Quantity:
1
Strike Number:
346
Number of Pins:
6
Product Warranty:
1 Year Warranty
Series:
Arrow D Series Deadbolts
Bore Hole Diameter (in):
2-1/8"
Parent Manufacturer:
Assa Abloy
Specifications Bullet 10:
1 Year Warranty
Box Weight (lbs):
2 lbs
Box Width (in):
3-3/4"
Backset (in):
2-3/4"
Commercial/Residential:
Commercial
Uid:
ARR100D6326D
Url Title:
d63-26d
Title:
D63 26D Arrow Lock Deadlock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Deadbolts
Last Modified:
2023-02-28T05:41:48+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
138
Avg Lead Time:
33
Popularity:
8
Unit Of Measure:
Each

Warranty Information

1 Year Warranty
