Corbin Russwin DL2212 626 Grade 2 Double Cylinder Deadbolt Conventional Cylinder Satin Chrome Finish Non-Handed

Corbin Russwin

Write a Review
SKU:
DL2212 626
$190.25
Corbin Russwin DL2212 626 Grade 2 Double Cylinder Deadbolt Conventional Cylinder Satin Chrome Finish Non-Handed
UPC:
840067638095
$190.25

Descriptions

Corbin Russwin is pleased to introduce the DL2200 and DL3200 cylindrical deadlocks. These easy to install deadlocks feature a solid steel deadbolt - with a hardened, free spinning, steel pin insert - and a 1" throw. Ideal for a variety of applications, the DL2200 is certified to 156.5 Grade 2 standards and the DL3200 is certified to 156.5 Grade 1 standards. Features Solid steel Deadbolt with a hardened, free spinning, steel pin insert and a 1" throw 1-3/4" door thickness standard; additional door thicknesses offered.
TypeTitleURL
catalogAlarm Lock Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/ALA112U-Alarm-Lock-2019.pdf
Padlocks and Deadlocks Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/45012.pdf
installation-instructionsDL2200/DL3200 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM331.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf

Specifications

Brand:
Corbin Russwin
Base Material:
Brass or Bronze
Parent Manufacturer:
Assa Abloy
Series:
DL2200 Series Cylindrical Deadlocks
Backset (in):
2-3/4"
Manufacturer:
Corbin Russwin
Box Depth (in):
7-7/8"
Bore Hole Diameter (in):
2-1/8"
Box Height (in):
4"
Box Weight (lbs):
1.8 lbs
Box Width (in):
4"
Certification:
ANSI A156.5, Grade 2, UL Listed
Country of Origin:
Mexico
Cylinder Type:
Conventional
Can Be Keyed:
Yes
Commercial/Residential:
Commercial
Finish:
626/US26D
Door Range (Thickness):
1-3/4" - 1-3/4"
Electronic:
No
Door Handing:
Non-handed
Deadbolt Throw (in):
1"
Interior/Exterior:
Interior/Exterior
Finish Description:
Satin Chrome
Includes Cylinder(s)?:
Yes
Function:
Double Cylinder
Grade:
Grade 2
Latch Number:
781F538
Latch Bore Diameter (in):
1"
Latch Dimensions:
1-1/8" x 2-1/4"
Latch Description:
Square Corner
Keyway:
L4 Keyway
Specifications Bullet 1:
Grade 2 Double Cylinder Deadbolt
Specifications Bullet 3:
2-3/4" Backset
Specifications Bullet 4:
1-1/8" x 2-3/4" Rectangle Strike
Specifications Bullet 2:
Conventional L4 Keyway
Specifications Bullet 5:
For Doors 1-3/4" Thick
Specifications Bullet 7:
1-1/8" x 2-1/4" Latch Dimension
Specifications Bullet 9:
ANSI A156.5, Grade 2, UL Listed
Specifications Bullet 10:
1 Year Warranty
Specifications Bullet 8:
2-1/8" Bore Hole Diameter
Specifications Bullet 6:
1" Deadbolt Throw
Maximum Door Thickness (in):
1-3/4"
Minimum Door Thickness (in):
1-3/4"
Product Warranty:
1 Year Warranty
Number of Keys:
2
Number of Pins:
6
UOM:
1
Strike Number:
781F568
Strike Description:
Rectangle Strike
Selling Quantity:
1
Strike Dimensions:
1-1/8" x 2-3/4"
UPC:
840067638095
Uid:
COR300DL2212626
Url Title:
dl2212-626
Title:
DL2212 626 Corbin Russwin Deadlock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Deadbolts
Last Modified:
2023-02-26T06:18:56+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
182
Avg Lead Time:
42
Popularity:
3
Pack Weight:
1.8
Pack Length:
7.875
Pack Width:
4
Pack Height:
4
Pack Volume:
126
Limited Warranty:
1 Year
Fire Rated:
3 Hours {A}
Unit Of Measure:
Each

Warranty Information

1 Year Warranty
