Schlage L9010 06A 626 Grade 1 Passage Latch Mortise Lock 06 Lever A Rose Satin Chrome Finish Field Reversible

Schlage

Write a Review
SKU:
L9010 06A 626
$651.58
UPC:
810007502120
$651.58

Descriptions

Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogL Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_L_Series_Catalog_102899.pdf
data-sheetSchlage L Indicator Data Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/datasheets/Schlage_L_Series_Mechanical_Indicator_Data_Sheet_110453.pdf
installation-instructionsL Series Mounting Plate Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108302.pdf
L400 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108267.pdf
L9000 Indicator Handing Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/111375.pdf
L9000 Indicator Lever w/ Escutcheon Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110669.pdf
L9000 Indicator Lever w/ Sectional Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110670.pdf
L9000 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108367.pdf
L9000 Knob Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108380.pdf
Video: L9050 Mortise Lock Installationhttps://youtu.be/U6fUoLLH7Kw
parts-listSchlage L Series Parts Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/SCH_parts-diagram_L-series.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
service-manualSchlage L Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106500.pdf

Specifications

Brand:
Schlage
Finish Description:
Satin Chrome
Specifications Bullet 10:
6-5/8" X 4-1/2" Pocket Dimension
Specifications Bullet 13:
10 Year Warranty
Deadbolt Throw (in):
Not Applicable
Electronic:
No
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 3:
A Rose
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Keyway:
Not Applicable
Specifications Bullet 6:
2-1/2" Projection
Specifications Bullet 1:
Grade 1 Passage Function Mortise Lockset
Door Handing:
Non-handed
Cylinder Type:
Keyless
Interior/Exterior:
Interior/Exterior
Lever/Knob/Pull Design:
6
Latch Dimensions:
1-1/4" x 8"
Lever/Knob/Pull:
Lever
Latch Throw (in):
3/4"
Specifications Bullet 2:
06 Lever
Backset (in):
2-3/4"
UPC:
810007502120
Specifications Bullet 9:
1-1/8" x 8" Faceplate Dimension
Includes Cylinder(s)?:
No
Specifications Bullet 8:
3/4" Spring Latch
Finish:
626/US26D
Door Range (Thickness):
1-3/4" - 1-3/4"
Grade:
Grade 1
Latch Description:
Spring Latch
Selling Quantity:
1
Projection (in):
2-1/2"
Series:
L9000 Series Mortise Lock
Can Be Keyed:
No
Pocket Dimensions:
6-5/8" X 4-1/2"
Maximum Door Thickness (in):
1-3/4"
Function:
Passage
Specifications Bullet 11:
For Doors 1-3/4" Thick
Certification:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Base Material:
Brass Bronze
Specifications Bullet 12:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Fire Rated:
3 Hours {A}
Minimum Door Thickness (in):
1-3/4"
Rose/Escutcheon Dimensions (in):
2-1/8"
Product Warranty:
10 Year Warranty
Specifications Bullet 7:
2-1/8" Rose Dimension
Country Of Origin:
Mexico
UOM:
1
Rose/Escutcheon:
Rose
Rose/Escutcheon Design:
A
Strike Number:
10-072
Strike Description:
ASA Strike
Manufacturer:
Schlage
ADA:
Yes
Armor Front Dimensions:
1-1/4" x 8"
Commercial/Residential:
Commercial
Parent Manufacturer:
Allegion
Strike Dimensions:
1-1/4" x 4-7/8"

Warranty Information

10 Year Warranty
