Schlage L9010 LATA 643E Grade 1 Passage Latch Mortise Lock Latitude Lever A Rose Aged Bronze Finish Field Reversible

Schlage

Write a Review
SKU:
L9010 LATA 643E
$718.14
$718.14

Descriptions

Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogL Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_L_Series_Catalog_102899.pdf
data-sheetSchlage L Indicator Data Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/datasheets/Schlage_L_Series_Mechanical_Indicator_Data_Sheet_110453.pdf
installation-instructionsL Series Mounting Plate Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108302.pdf
L400 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108267.pdf
L9000 Indicator Handing Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/111375.pdf
L9000 Indicator Lever w/ Escutcheon Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110669.pdf
L9000 Indicator Lever w/ Sectional Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110670.pdf
L9000 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108367.pdf
L9000 Knob Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108380.pdf
Video: L9050 Mortise Lock Installationhttps://youtu.be/U6fUoLLH7Kw
parts-listSchlage L Series Parts Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/SCH_parts-diagram_L-series.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
service-manualSchlage L Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106500.pdf

Specifications

Brand:
Schlage
Base Material:
Steel
Certification:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Backset (in):
2-3/4"
Manufacturer:
Schlage
Commercial Residential:
Commercial
Can Be Keyed:
No
ADA:
Yes
Series:
L9000 Series Mortise Lock
Armor Front Dimensions:
1-1/4" x 8"
Parent Manufacturer:
Allegion
Door Handing:
Non-handed
Function:
Passage
Door Range (Thickness):
1-3/4" - 1-3/4"
Country Of Origin:
Mexico
Finish Description:
Aged Bronze
Electronic:
No
Finish:
643E/US11E
Fire Rated:
3 Hours {A}
Deadbolt Throw (in):
Not Applicable
Cylinder Type:
Keyless
Lever/Knob/Pull Design:
Latitude
Specifications Bullet 1:
Grade 1 Passage Function Mortise Lockset
Latch Dimensions:
1-1/4" x 8"
Latch Throw (in):
3/4"
Keyway:
Not Applicable
Grade:
Grade 1
Lever/Knob/Pull:
Lever
Latch Description:
Spring Latch
Includes Cylinder(s)?:
No
Specifications Bullet 2:
Latitude Lever
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 9:
1-1/8" x 8" Faceplate Dimension
Specifications Bullet 6:
2-9/16" Projection
Specifications Bullet 11:
For Doors 1-3/4" Thick
Specifications Bullet 7:
2-1/8" Rose Dimension
Specifications Bullet 10:
6-5/8" X 4-1/2" Pocket Dimension
Specifications Bullet 8:
3/4" Spring Latch
Specifications Bullet 12:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Specifications Bullet 3:
A Rose
Minimum Door Thickness (in):
1-3/4"
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 13:
10 Year Warranty
Product Warranty:
10 Year Warranty
Pocket Dimensions:
6-5/8" X 4-1/2"
Rose/Escutcheon Design:
A
Rose/Escutcheon:
Rose
Projection (in):
2-9/16"
Rose/Escutcheon Dimensions (in):
2-1/8"
Selling Quantity:
1
UOM:
1
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Description:
ASA Strike
Strike Number:
10-072
Uid:
SCH100L9010LATA643E
Url Title:
l9010-lat-a-643e
Title:
L9010 LATA 643E Schlage Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-28T05:25:42+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
959
Avg Lead Time:
58
Finish Family:
Dark Bronze
Popularity:
6
Pack Weight:
6.3
Pack Length:
10.375
Pack Width:
5.375
Pack Height:
5.625
Pack Volume:
313.6816406
Ul Listing:
UL Listed
Ansi Code:
A156.13-2017 Series 1000, Grade 1
Baa Qualified:
Yes
Limited Warranty:
3 Years
Unit Of Measure:
Each
Unit Of Measure 2:
CASE
Unit Of Measure 2 Qty:
6
Vendor:
Allegion
Assembly Item:
1

Warranty Information

10 Year Warranty
