Schlage L9453B 07A 626 Entrance Mortise Lock with Deadbolt 07A Design SFIC Prep Less Core Satin Chrome

Schlage

Write a Review
SKU:
L9453B 07A 626
$849.37
UPC:
840067648674
$849.37

Descriptions

Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogL Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_L_Series_Catalog_102899.pdf
data-sheetSchlage L Indicator Data Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/datasheets/Schlage_L_Series_Mechanical_Indicator_Data_Sheet_110453.pdf
installation-instructionsL Series Mounting Plate Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108302.pdf
L400 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108267.pdf
L9000 Indicator Handing Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/111375.pdf
L9000 Indicator Lever w/ Escutcheon Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110669.pdf
L9000 Indicator Lever w/ Sectional Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110670.pdf
L9000 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108367.pdf
L9000 Knob Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108380.pdf
Video: L9050 Mortise Lock Installationhttps://youtu.be/U6fUoLLH7Kw
parts-listSchlage L Series Parts Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/SCH_parts-diagram_L-series.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
service-manualSchlage L Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106500.pdf

Specifications

Brand:
Schlage
Can Be Keyed:
Yes
Specifications Bullet 9:
1" Deadbolt Throw
Base Material:
Brass or Bronze
Maximum Door Thickness (in):
1-3/4"
Cylinder Type:
Mortise SFIC Housing
Lever/Knob/Pull Design:
7
Specifications Bullet 14:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Specifications Bullet 11:
1-1/8" x 8" Faceplate Dimension
Keyway:
Less Core
Grade:
Grade 1
Commercial Residential:
Commercial
Function:
Entrance with Deadbolt
Interior/Exterior:
Interior/Exterior
Country Of Origin:
Mexico
Includes Cylinder(s)?:
No
Specifications Bullet 2:
07 Lever
Specifications Bullet 10:
3/4" Dead Latch
ADA:
Yes
Latch Throw (in):
3/4"
Finish:
626/US26D
Minimum Door Thickness (in):
1-3/4"
Specifications Bullet 12:
6-5/8" X 4-1/2" Pocket Dimension
Door Range (Thickness):
1-3/4" - 1-3/4"
Deadbolt Throw (in):
1"
Specifications Bullet 5:
2-3/4" Backset
Specifications Bullet 7:
2-7/8" Projection
Fire Rated:
3 Hours {A}
Door Handing:
Non-handed
Specifications Bullet 8:
2-1/8" Rose Dimension
Electronic:
No
Lever/Knob/Pull:
Lever
Backset (in):
2-3/4"
Specifications Bullet 3:
Mortise SFIC Housing Less Core
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon:
Rose
Latch Description:
Dead Latch
Projection (in):
2-7/8"
Finish Description:
Satin Chrome
Latch Dimensions:
1-1/4" x 8"
Specifications Bullet 4:
A Rose
Armor Front Dimensions:
1-1/4" x 8"
Strike Number:
10-072
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Selling Quantity:
1
UPC:
840067648674
Parent Manufacturer:
Allegion
Rose/Escutcheon Design:
A
Specifications Bullet 1:
Grade 1 Entrance with Deadbolt Function Mortise Lockset
Rose/Escutcheon Dimensions (in):
2-1/8"
Product Warranty:
10 Year Warranty
Strike Description:
ASA Strike
Specifications Bullet 13:
For Doors 1-3/4" Thick
Series:
L Series
UOM:
1
Specifications Bullet 15:
10 Year Warranty
Manufacturer:
Schlage
Certification:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Pocket Dimensions:
6-5/8" X 4-1/2"

Warranty Information

10 Year Warranty
