Schlage L9453J 17A 626 Entrance Mortise Lock with Deadbolt 17A Design FSIC Prep Less Core Satin Chrome

Schlage

Write a Review
SKU:
L9453J 17A 626
$862.60
UPC:
840067649121
$862.60

Descriptions

Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogL Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_L_Series_Catalog_102899.pdf
data-sheetSchlage L Indicator Data Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/datasheets/Schlage_L_Series_Mechanical_Indicator_Data_Sheet_110453.pdf
installation-instructionsL Series Mounting Plate Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108302.pdf
L400 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108267.pdf
L9000 Indicator Handing Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/111375.pdf
L9000 Indicator Lever w/ Escutcheon Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110669.pdf
L9000 Indicator Lever w/ Sectional Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110670.pdf
L9000 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108367.pdf
L9000 Knob Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108380.pdf
Video: L9050 Mortise Lock Installationhttps://youtu.be/U6fUoLLH7Kw
parts-listSchlage L Series Parts Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/SCH_parts-diagram_L-series.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
service-manualSchlage L Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106500.pdf

Specifications

Brand:
Schlage
Latch Dimensions:
1-1/4" x 8"
Commercial Residential:
Commercial
Certification:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Specifications Bullet 4:
A Rose
Finish:
626/US26D
Armor Front Dimensions:
1-1/4" x 8"
Specifications Bullet 5:
2-3/4" Backset
Specifications Bullet 7:
3" Projection
Manufacturer:
Schlage
Grade:
Grade 1
Specifications Bullet 2:
17 Lever
Specifications Bullet 14:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Can Be Keyed:
Yes
Specifications Bullet 1:
Grade 1 Entrance with Deadbolt Function Mortise Lockset
Specifications Bullet 10:
3/4" Dead Latch
Selling Quantity:
1
Door Handing:
Non-handed
Door Range (Thickness):
1-3/4" - 1-3/4"
Fire Rated:
3 Hours {A}
Latch Throw (in):
3/4"
Specifications Bullet 3:
Mortise LFIC Housing Less Core
Finish Description:
Satin Chrome
Base Material:
Brass or Bronze
ADA:
Yes
Latch Description:
Dead Latch
Backset (in):
2-3/4"
Includes Cylinder(s)?:
No
Series:
L9000 Series Mortise Lock
Rose/Escutcheon Dimensions (in):
2-1/8"
Keyway:
Less Core
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 8:
2-1/8" Rose Dimension
Function:
Entrance with Deadbolt
Cylinder Type:
Mortise LFIC Housing
Interior/Exterior:
Interior/Exterior
Electronic:
No
Lever/Knob/Pull Design:
17
Specifications Bullet 9:
1" Deadbolt Throw
Country Of Origin:
Mexico
Specifications Bullet 12:
6-5/8" X 4-1/2" Pocket Dimension
Deadbolt Throw (in):
1"
Rose/Escutcheon Design:
A
Lever/Knob/Pull:
Lever
Rose/Escutcheon:
Rose
Parent Manufacturer:
Allegion
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 13:
For Doors 1-3/4" Thick
Specifications Bullet 15:
10 Year Warranty
Specifications Bullet 11:
1-1/8" x 8" Faceplate Dimension
Pocket Dimensions:
6-5/8" X 4-1/2"
Projection (in):
3"
Strike Dimensions:
1-1/4" x 4-7/8"
UPC:
840067649121
UOM:
1
Strike Description:
ASA Strike
Product Warranty:
10 Year Warranty
Minimum Door Thickness (in):
1-3/4"
Strike Number:
10-072
Uid:
SCH100L9453J17A626
Url Title:
l9453j-17a-626
Title:
L9453J 17A 626 Schlage Lock Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-28T06:30:19+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
1254
Popularity:
8
Pack Weight:
6.3
Pack Length:
10.375
Pack Width:
5.375
Pack Height:
5.625
Pack Volume:
313.6816406
Baa Qualified:
Yes
Limited Warranty:
3 Years
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
6
Vendor:
Allegion
Assembly Item:
1

Warranty Information

10 Year Warranty
