Kaba Simplex LR1021M-05-41 Pushbutton Cylindrical Lever Lock Combination Entry Function with Key Override 2-3/4 Backset 1/2 Throw Latch Medeco/Yale/ASSA/Abloy LFIC Prep Less Core Antique Brass Finish Right Hand/Right Hand Reverse

Kaba Simplex

Write a Review
SKU:
LR1021M-05-41
$621.41
Kaba Simplex LR1021M-05-41 Pushbutton Cylindrical Lever Lock Combination Entry Function with Key Override 2-3/4 Backset 1/2 Throw Latch Medeco/Yale/ASSA/Abloy LFIC Prep Less Core Antique Brass Finish Right Hand/Right Hand Reverse
UPC:
840067622926
$621.41

Descriptions

Simplex mechanical pushbutton locks offer a convenient way to control access between public and private areas. There are no keys or cards to manage, no computers to program, no batteries to replace, and combinations can be changed in seconds without removing the lock from the door.
TypeTitleURL
catalogSimplex Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/dormakaba/guides/KABA_catalog_simplex.pdf
price-book2024 Simplex Parts Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex-parts_1-2024.pdf
2024 Simplex Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex_1-2024.pdf
videoSimplex 1000 / L1000 - How to Reset Unknown Combination - New Style Chamberhttps://youtu.be/J4avWH1mlEc

Specifications

Brand:
Kaba Simplex
Specifications Bullet 7:
Single Access Code
Minimum Stile (in):
5"
Specifications Bullet 15:
3 Year Warranty
Box Width (in):
10-1/2"
Specifications Bullet 6:
Entrance Function
Country of Origin:
Mexico
Latch Description:
Dead Latch
Electronic:
No
Keyway:
Less Core
Specifications Bullet 1:
Grade 1 Cylindrical Single Access Code Pushbutton Lockset
Projection (in):
3-13/16"
Specifications Bullet 8:
5" Minimum Stile
Certification:
BMHA Certified Grade 1, UL Listed
Lever/Knob/Pull Design:
ADA
Grade:
Grade 1
Specifications Bullet 13:
For Doors 1-3/8" - 2-1/4" Thick
Product Warranty:
3 Year Warranty
Strike Description:
ASA Strike
Lever/Knob/Pull:
Lever
Specifications Bullet 2:
ADA Lever
Function:
Entrance
Backset (in):
2-3/4"
Specifications Bullet 14:
BMHA Certified Grade 1, UL Listed
Specifications Bullet 4:
2-3/4" Backset
Finish Description:
Satin Brass Blackened Satin Relieved Clear Coated
Specifications Bullet 10:
3-1/8" x 8-7/8" Escutcheon Dimension
Latch Dimensions:
1-1/8" x 2-1/4"
Latch Throw (in):
1/2"
Minimum Door Thickness (in):
1-3/8"
Specifications Bullet 9:
3-13/16" Projection
Door Handing:
Right Hand
Rose/Escutcheon:
Escutcheon
Specifications Bullet 12:
1/2" Latch Throw
Cylinder Type:
Medeco LFIC Housing
Specifications Bullet 11:
1-1/8" x 2-1/4" Dead Latch
Finish:
609/US5
Specifications Bullet 3:
Medeco LFIC Housing Less Core
UOM:
1
Maximum Door Thickness (in):
2-1/4"
Product Height (in):
7-3/8"
Door Range (Thickness):
1-3/8" - 2-1/4"
User Codes:
1
Strike Dimensions:
1-1/4" x 4-7/8"
Can Be Keyed:
Yes
UPC:
840067622926
Rose/Escutcheon Dimensions (in):
3-1/8" x 8-7/8"
Includes Cylinder(s)?:
No
Technology:
Single Access Code
Selling Quantity:
1
ADA:
Yes
Latch Bore Diameter (in):
1"
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Product Width (in):
3-1/8"
Manufacturer:
Kaba Simplex
Box Height (in):
8"
Commercial/Residential:
Commercial
Parent Manufacturer:
DormaKaba
Bore Hole Diameter (in):
2-1/8"
Type:
Mechanical Pushbutton
Base Material:
Brass
Series:
1000 Series
Box Depth (in):
11"
Box Weight (lbs):
10.5 lbs

Warranty Information

3 Year Warranty
