Yale MO5408LN ICLC 626 Grade 1 Classroom Cylindrical Lock Monroe Lever LFIC 6-Pin Less Core Satin Chrome Finish Non-handed

ACCENTRA (formerly Yale Commercial)

Write a Review
SKU:
MO5408LN ICLC 626
$522.75
Yale MO5408LN ICLC 626 Grade 1 Classroom Cylindrical Lock Monroe Lever LFIC 6-Pin Less Core Satin Chrome Finish Non-handed
$522.75

Descriptions

Designed for industrial, commercial and institutional use, the Yale 5400LN Series heavy duty cylindrical lockset offers no compromises when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear resistant chassis plates, heavy duty lever return springs and through bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.
TypeTitleURL
catalog5400LN Series Grade 1 Cylindrical Lever Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/yale/catalogs/Yale_5400LN_Series_Cylindrical_Lever_Lock_Catalog.pdf
installation-instructions5400LN Series Grade 1 Cylindrical Lever Lockset Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/yale/installationinstructions/80-9150-0056-01001-135400LNlever.pdf
Electrified Wiring and Request to Exit (REX) Instructions 5490LN/5491LNhttps://dvwi9lnoau63q.cloudfront.net/yale/installationinstructions/80-9470-0011-00008-125490LNWiring.pdf
videoReplacing Push Button on a Yale 5400 Series Cylindrical Lockhttps://youtu.be/ikn7gr2aK4Y

Specifications

Brand:
ACCENTRA (formerly Yale Commercial)
Manufacturer:
Yale
Parent Manufacturer:
Assa Abloy
Backset (in):
2-3/4"
ADA:
Yes
Series:
5400LN Grade 1 Cylindrical Lever Locks
Commercial Residential:
Commercial
Bore Hole Diameter (in):
2-1/8"
Certification:
ANSI A156.2, Grade 1, UL Listed
Can Be Keyed:
Yes
Base Material:
Brass, Bronze
Door Range (Thickness):
1-3/4" - 2"
Door Handing:
Non-handed
Electronic:
No
Finish:
626/US26D
Cylinder Type:
LFIC Housing
Grade:
Grade 1
Fire Rated:
3 Hours {A}
Finish Description:
Satin Chrome
Includes Cylinder(s)?:
No
Function:
Classroom
Latch Bore Diameter (in):
1"
Latch Description:
Dead Latch
Latch Dimensions:
1-1/8" x 2-1/4"
Latch Number:
694
Keyway:
Less Core
Lever/Knob/Pull Design:
Monroe
Specifications Bullet 2:
Monroe Lever
Latch Throw (in):
1/2"
Specifications Bullet 1:
Grade 1 Classroom Function Cylindrical Lockset
Lever/Knob/Pull:
Lever
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 7:
3-1/8" Projection
Specifications Bullet 3:
LFIC Housing Less Core
Specifications Bullet 8:
3-1/2" Rose
Specifications Bullet 9:
For Doors 1-3/4" - 2" Thick
Specifications Bullet 12:
7 Year Warranty
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Specifications Bullet 11:
ANSI A156.2, Grade 1, UL Listed
Product Warranty:
7 Year Warranty
Projection (in):
3-1/8"
Minimum Door Thickness (in):
1-3/4"
Maximum Door Thickness (in):
2"
Rose/Escutcheon:
Rose
Rose/Escutcheon Dimensions (in):
3-1/2"
Strike Description:
ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon Design:
Not Applicable
Selling Quantity:
1
UOM:
1
Strike Number:
497
Uid:
YAL200MO5408LN1210LC626
Url Title:
mo5408ln-1210-lc-626
Title:
Yale MO5408LN ICLC 626 Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2022-12-17T05:20:29+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
743
Avg Lead Time:
22
Finish Family:
Matte Silver
Popularity:
5
Pack Weight:
5
Pack Length:
10
Pack Width:
7.5
Pack Height:
4
Pack Volume:
300
Ul Listing:
ANSI A156.2, Series 4000, Grade 1, UL Listed
Ansi Code:
F84
Country Of Origin:
United States
Limited Warranty:
7 Year Warranty
Unit Of Measure:
Each
Vendor:
ASSA ABLOY

Warranty Information

7 Year Warranty
