TownSteel MRX-S-L-04-630 Heavy Duty Anti-Ligature Level Mortise Lockset Grade 1 Entry/Office Keyed ANSI Sectional Lever Trim Satin Stainless Steel

TownSteel

Write a Review
SKU:
MRX-S-L-04-630
$676.20
TownSteel MRX-S-L-04-630 Heavy Duty Anti-Ligature Level Mortise Lockset Grade 1 Entry/Office Keyed ANSI Sectional Lever Trim Satin Stainless Steel
UPC:
810007504674
$676.20

Descriptions

Levered ligature-resistant stainless steel mortise lock optimized for 1-3/4" door thickness. Features 2-3/4" backset, stainless steel turn piece, faceplate and strike.
TypeTitleURL
catalogTownSteel Ligature Resistant Cataloghttps://dvwi9lnoau63q.cloudfront.net/townsteel/catalog/catalog-lig-res.pdf
cut-sheetTownSteel MRX-A Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/townsteel/cut-sheets/cut-sheet-mrxa.pdf
TownSteel MRX-E-L Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/townsteel/cut-sheets/cut-sheet-mrxel.pdf
TownSteel MRX-L Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/townsteel/cut-sheets/cut-sheet-mrxl.pdf
installation-instructionsTownSteel MRX-A Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/townsteel/installation-guides/installation-guide-mrxa.pdf
TownSteel MRX-L Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/townsteel/installation-guides/installation-guide-mrxl.pdf
TownSteel MRX-S-K Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/townsteel/installation-guides/installation-guide-mrxsk.pdf
price-books2024 TownSteel Price Bookhttps://dvwi9lnoau63q.cloudfront.net/townsteel/pricebooks/TOWN_pricebook_1-2024.pdf
sell-sheetTownSteel DRX Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/townsteel/sell-sheets/sell-sheet-drx.pdf
TownSteel MRX-K Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/townsteel/sell-sheets/sell-sheet-mrxk.pdf
templateTownSteel MRX Templatehttps://dvwi9lnoau63q.cloudfront.net/townsteel/installation-guides/installation-guide-template-mrx.pdf
TownSteel MRX-A Templatehttps://dvwi9lnoau63q.cloudfront.net/townsteel/installation-guides/installation-guide-template-mrxa.pdf

Specifications

Brand:
TownSteel
Lever/Knob/Pull:
Lever
Latch Throw (in):
3/4"
Selling Quantity:
1
Bore Hole Diameter (in):
86 Prep
Specifications Bullet 13:
ANSI A156.13, Grade 1, UL Listed
Keyway:
C Keyway
Electronic:
No
Can Be Keyed:
Yes
Specifications Bullet 7:
4" Rose Dimension
Door Range (Thickness):
1-3/4" - 1-3/4"
Minimum Door Thickness (in):
1-3/4"
Backset (in):
2-3/4"
Specifications Bullet 10:
3/4" Dead Latch
Specifications Bullet 1:
Grade 1 Ligature Resistant Entrance Function Mortise Lockset
Specifications Bullet 8:
1-1/8" X 8" Faceplate Dimension
Finish Description:
Satin Stainless Steel
Base Material:
Stainless Steel
Door Handing:
Non-handed
Specifications Bullet 3:
Mortise Conventional C Keyway
Series:
TownSteel Ligature Resistant Mortise Locks
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 6:
2-15/16" Projection
Finish:
630/US32D
Specifications Bullet 4:
2-3/4" Backset
Function:
Entrance
Commercial/Residential:
Commercial
Grade:
Grade 1
Specifications Bullet 9:
6-5/8" x 4-1/2" Pocket Dimension
Certification:
ANSI A156.13, Grade 1, UL Listed
Specifications Bullet 2:
L Lever
Product Warranty:
5 Year Warranty
UPC:
810007504674
Lever/Knob/Pull Design:
L
Rose/Escutcheon:
Rose
Specifications Bullet 12:
Includes Metal/Wood Screws
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Rose/Escutcheon Design:
Not Applicable
Screw Pack:
Metal/Wood Screws
Latch Description:
Dead Latch
Specifications Bullet 11:
For Doors 1-3/4" Thick
Projection (in):
2-15/16"
Cylinder Type:
Mortise Conventional
Specifications Bullet 14:
5 Year Warranty
Strike Description:
ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon Dimensions (in):
4"
Pocket Dimensions:
6-5/8" x 4-1/2"
UOM:
1
Manufacturer:
TownSteel
Armor Front Dimensions:
1-1/4" x 8"
ADA:
Yes
Strike Number:
CNF
Uid:
TOW200MRXSL04630
Url Title:
tow200mrxsl04630
Title:
MRX-S-L-04-630 TownSteel Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-28T06:51:40+00:00
Last Pricing:
2023-02-16T00:00:00+00:00
Msrp:
885
Avg Lead Time:
27
Popularity:
9
Limited Warranty:
5 Years
Accessible:
Yes
Unit Of Measure:
Each

Warranty Information

5 Year Warranty
