Schlage ND40S TLR 605 Grade 1 Bath/Bedroom Privacy Lock Tubular Lever Non-Keyed Bright Brass Finish Non-Handed

Schlage

Write a Review
SKU:
ND40S TLR 605
$484.88
$484.88

Descriptions

Walter Schlage invented the cylindrical lock in 1920. Since then, the Schlage Lock Company has consistently delivered innovation and continuous improvement. In that tradition, The ND Series Cylindrical Lockset is a proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application. The Schlage ND Series Locksets are commonly used in Healthcare, Education, Government, Office, Retail, and other commercial applications. The ND Series has been certified Grade 1; exceeding 3-million operating cycles without failure. This provides confidence that the lock will last within any type of facility. Finally, Schlage has incorporated wire-wireless capabilities that meet the access control and security needs of every facility owner.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Locks & Latches Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Allegion_2014_Commercial_Product_Catalogue_ND_Series_0114.pdf
ND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
installation-guideSchlage ND-Series Standard Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDSeriesStandInstallInstructionslocksmanafter8-15-2012.pdf
Schlage ND-Series Standard Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDStandInstallInstructionslocksmanubefore8-15-2012.pdf
installation-instructionsND Series Electrified Functions Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108353.PDF
ND Series Electrified Functions Installation Instructions (solenoid, mfg before 3-14-2016)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/111248.pdf
ND Series Hollow Metal Door Spacer Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/107544.pdf
ND170 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108996.pdf
ND170 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106121.pdf
ND25 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108995.pdf
ND25 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106122.pdf
Video: ND Series Lock Installationhttps://youtu.be/U6fUoLLH7Kw
keyway-diagramEverest 29 S Keyway Family Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/S-Family_Open_Keyway_Diagram.pdf
Everest Keyways Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Everest_Keyways.pdf
Observe Keyways for Classic Conventional Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Convetional_Observe_Keyways.pdf
Observe Keyways for Classic Primus XP Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Primus_Observe_Keyways.pdf
miscellaneousND Series Locks & Latches Warrantyhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/Schlage_ND_Series_Commercial_Warranty_December_2013.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
sell-sheetSchlage ND Series Electrified Cylindrical Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/Schlage_ND_Series_Data_Sheet_110875.pdf
Schlage ND Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106486NDsellsheet.pdf
service-manualSchlage ND Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/2021_Schlage_ND_Series_Service_Manual.pdf
templateND Series Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/Schlage_ND_Series_Template.pdf

Specifications

Brand:
Schlage
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Latch Description:
Spring Latch
Finish Description:
Bright Brass
Base Material:
Brass
Box Height (in):
4-3/4"
Specifications Bullet 3:
2-3/4" Backset
Function:
Privacy
Box Width (in):
8-1/4"
Bore Hole Diameter (in):
2-1/8"
Grade:
Grade 1
Interior/Exterior:
Interior/Exterior
Cylinder Type:
Keyless
Commercial Residential:
Commercial
Lever/Knob/Pull Design:
Tubular
Specifications Bullet 1:
Grade 1 Privacy Function Cylindrical Lockset
Fire Rated:
3 Hours {A}
Country Of Origin:
Mexico
Rose/Escutcheon Dimensions (in):
3-7/16"
Specifications Bullet 6:
3" Projection
Latch Number:
13-248
Door Handing:
Non-handed
Can Be Keyed:
No
Finish:
605/US3
Box Weight (lbs):
5 lbs
Box Depth (in):
9-1/2"
ADA:
Yes
Backset (in):
2-3/4"
Lever/Knob/Pull:
Lever
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Latch Dimensions:
1-1/8" X 2-1/4"
Door Range (Thickness):
1-5/8" - 2-1/8"
Latch Throw (in):
1/2"
Minimum Door Thickness (in):
1-5/8"
Rose/Escutcheon:
Rose
Specifications Bullet 4:
1-1/8" X 2-1/4" Spring Latch
Electronic:
No
Specifications Bullet 7:
3-7/16" Rose
Specifications Bullet 2:
Tubular Lever
Includes Cylinder(s)?:
No
Number of Pins:
6
Specifications Bullet 11:
10 Year Warranty
Specifications Bullet 9:
2-1/8" Bore Hole Diameter
Specifications Bullet 8:
For Doors 1-5/8" - 2-1/8" Thick
Maximum Door Thickness (in):
2-1/8"
Specifications Bullet 10:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Strike Number:
10-025
Number of Keys:
2
Series:
ND Series Lever Locks
UOM:
1
Rose/Escutcheon Design:
Not Applicable
Strike Description:
ASA Strike
Keyway:
Not Applicable
Selling Quantity:
1
Projection (in):
3"
Product Warranty:
10 Year Warranty
Strike Dimensions:
1-1/4" x 4-7/8"
Manufacturer:
Schlage
Parent Manufacturer:
Allegion

Warranty Information

10 Year Warranty
