Schlage ND53PD ATH 613 Grade 1 Entrance Lock Athens Lever Standard Cylinder Oil Rubbed Bronze Finish Non-Handed

Schlage

Write a Review
SKU:
ND53PD ATH 613
$584.10
$584.10

Descriptions

Walter Schlage invented the cylindrical lock in 1920. Since then, the Schlage Lock Company has consistently delivered innovation and continuous improvement. In that tradition, The ND Series Cylindrical Lockset is a proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application. The Schlage ND Series Locksets are commonly used in Healthcare, Education, Government, Office, Retail, and other commercial applications. The ND Series has been certified Grade 1; exceeding 3-million operating cycles without failure. This provides confidence that the lock will last within any type of facility. Finally, Schlage has incorporated wire-wireless capabilities that meet the access control and security needs of every facility owner.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Locks & Latches Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Allegion_2014_Commercial_Product_Catalogue_ND_Series_0114.pdf
ND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
installation-guideSchlage ND-Series Standard Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDSeriesStandInstallInstructionslocksmanafter8-15-2012.pdf
Schlage ND-Series Standard Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDStandInstallInstructionslocksmanubefore8-15-2012.pdf
installation-instructionsND Series Electrified Functions Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108353.PDF
ND Series Electrified Functions Installation Instructions (solenoid, mfg before 3-14-2016)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/111248.pdf
ND Series Hollow Metal Door Spacer Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/107544.pdf
ND170 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108996.pdf
ND170 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106121.pdf
ND25 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108995.pdf
ND25 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106122.pdf
Video: ND Series Lock Installationhttps://youtu.be/U6fUoLLH7Kw
keyway-diagramEverest 29 S Keyway Family Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/S-Family_Open_Keyway_Diagram.pdf
Everest Keyways Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Everest_Keyways.pdf
Observe Keyways for Classic Conventional Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Convetional_Observe_Keyways.pdf
Observe Keyways for Classic Primus XP Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Primus_Observe_Keyways.pdf
miscellaneousND Series Locks & Latches Warrantyhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/Schlage_ND_Series_Commercial_Warranty_December_2013.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
sell-sheetSchlage ND Series Electrified Cylindrical Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/Schlage_ND_Series_Data_Sheet_110875.pdf
Schlage ND Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106486NDsellsheet.pdf
service-manualSchlage ND Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/2021_Schlage_ND_Series_Service_Manual.pdf
templateND Series Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/Schlage_ND_Series_Template.pdf

Specifications

Brand:
Schlage
Box Depth (in):
9-1/2"
Finish Description:
Oil Rubbed Bronze
ADA:
Yes
Fire Rated:
3 Hours {A}
Includes Cylinder(s)?:
Yes
Box Weight (lbs):
5 lbs
Specifications Bullet 2:
Athens Lever
Finish:
613/US10B
Latch Throw (in):
1/2"
Base Material:
Bronze
Specifications Bullet 4:
2-3/4" Backset
Rose/Escutcheon:
Rose
Specifications Bullet 5:
1-1/8" X 2-1/4" Dead Latch
Specifications Bullet 1:
Grade 1 Entrance Function Cylindrical Lockset
Keyway:
C Keyway
Door Handing:
Non-handed
Commercial Residential:
Commercial
Bore Hole Diameter (in):
2-1/8"
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Product Warranty:
10 Year Warranty
Strike Number:
10-025
Maximum Door Thickness (in):
2-1/8"
Latch Dimensions:
1-1/8" X 2-1/4"
Latch Number:
13-247
Cylinder Type:
Conventional
Can Be Keyed:
Yes
Box Width (in):
8-1/4"
Grade:
Grade 1
Specifications Bullet 11:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Function:
Entrance
Specifications Bullet 3:
Conventional C Keyway
Box Height (in):
4-3/4"
Specifications Bullet 7:
3-5/16" Projection
Latch Description:
Dead Latch
Door Range (Thickness):
1-5/8" - 2-1/8"
Electronic:
No
Country Of Origin:
Mexico
Manufacturer:
Schlage
Strike Description:
ASA Strike
Projection (in):
3-5/16"
Rose/Escutcheon Dimensions (in):
3-7/16"
Lever/Knob/Pull Design:
Athens
Minimum Door Thickness (in):
1-5/8"
Backset (in):
2-3/4"
Rose/Escutcheon Design:
Not Applicable
Series:
ND Series Lever Locks
Specifications Bullet 9:
For Doors 1-5/8" - 2-1/8" Thick
Parent Manufacturer:
Allegion
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Lever/Knob/Pull:
Lever
UOM:
1
Specifications Bullet 12:
10 Year Warranty
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
Specifications Bullet 8:
3-7/16" Rose
Uid:
SCH100ND53PDATH613
Url Title:
nd53pd-ath-613
Title:
ND53PD ATH 613 Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-28T06:52:01+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
850
Avg Lead Time:
28
Finish Family:
Dark Bronze
Popularity:
3
Pack Weight:
5
Pack Length:
9.5
Pack Width:
8.25
Pack Height:
4.75
Pack Volume:
372.28125
Ul Listing:
UL/cUL Listed
Ansi Code:
ANSI A156.2 Series 4000, Grade 1
Baa Qualified:
Yes
Limited Warranty:
10 Years
Accessible:
Yes
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
6
Vendor:
Allegion

Warranty Information

10 Year Warranty
