Schlage ND80BDEU ATH 625 RX Grade 1 Electrified Cylindrical Lock Storeroom Function 12-24 VDC Fail Secure 2-3/4 Backset Request to Exit Athens Lever SFIC Prep Bright Chrome Finish

Schlage

Write a Review
SKU:
ND80BDEU ATH 625 RX
$812.98
Schlage ND80BDEU ATH 625 RX Grade 1 Electrified Cylindrical Lock Storeroom Function 12-24 VDC Fail Secure 2-3/4 Backset Request to Exit Athens Lever SFIC Prep Bright Chrome Finish
UPC:
840067616246
$812.98

Descriptions

ND Series locks are available for electrically locking and unlocking controls for high security and fire safety applications.They are UL Listed and rated for both fire and electrical single-point locking on labeled doors. RX feature is available on ND10, ND12, ND80 and ND96 families. Switch is ready to be used in a normally open or normally closed application.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf

Specifications

Brand:
Schlage
Specifications Bullet 3:
Athens Lever
Latch Dimensions:
1-1/8" x 2-1/4"
Can Be Keyed:
Yes
Box Depth (in):
9-1/2"
Specifications Bullet 4:
SFIC Housing Less Core
Keyway:
Less Core
UOM:
1
Strike Dimensions:
1-1/4" x 4-7/8"
Minimum Door Thickness (in):
1-5/8"
Manufacturer:
Schlage
Fire Rated:
Yes
Voltage:
12/24 VDC Voltage
Lever/Knob/Pull Design:
Athens
Box Weight (lbs):
5 lbs
Maximum Door Thickness (in):
2-1/8"
Door Range (Thickness):
1-5/8" - 2-1/8"
Specifications Bullet 5:
2-3/4" Backset
Door Handing:
Non-handed
Commercial Residential:
Commercial
Includes Cylinder(s)?:
No
Specifications Bullet 7:
12/24 VDC Voltage Fail Secure
Country Of Origin:
Mexico
Latch Description:
Dead Latch
Specifications Bullet 16:
1 Year Warranty
UPC:
840067616246
Bore Hole Diameter (in):
2-1/8"
Latch Number:
13-247
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Specifications Bullet 10:
1/2" Latch Throw
Lever/Knob/Pull:
Lever
Finish Description:
Bright Chrome
Latch Bore Diameter (in):
1"
Grade:
Grade 1
Box Width (in):
8-1/4"
Specifications Bullet 2:
Request to Exit
Electronic:
Yes
Function:
Electronically Unlocked Storeroom
Option 1:
Request to Exit
Specifications Bullet 11:
1-1/8" x 2-1/4" Dead Latch
FS/FSE Mode:
Fail Secure
Rose/Escutcheon Dimensions (in):
3-7/16"
Projection (in):
3-5/16"
Backset (in):
2-3/4"
Series:
ND Series Electrified Lever Locks
ADA:
Yes
Box Height (in):
4-3/4"
Finish:
625/US26
Cylinder Type:
SFIC Housing
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Selling Quantity:
1
Base Material:
Brass Bronze
Rose/Escutcheon:
Rose
Specifications Bullet 8:
3-5/16" Projection
Parent Manufacturer:
Allegion
Screw Pack:
Wood/Metal Screws
Product Warranty:
1 Year Warranty
Specifications Bullet 12:
For Doors 1-5/8" - 2-1/8" Thick
Strike Description:
ASA Strike
Specifications Bullet 1:
Grade 1 Electrified Electronically Unlocked Storeroom Function Cylindrical Lockset
Specifications Bullet 14:
Includes Wood/Metal Screws
Specifications Bullet 15:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Strike Number:
10-025
Latch Throw (in):
1/2"
Specifications Bullet 9:
3-7/16" Rose Dimension
Specifications Bullet 13:
2-1/8" Bore Hole Diameter
Uid:
SCH100ND80BDEUATH625RX
Url Title:
nd80bdeu-ath-625-rx
Title:
ND80BDEU ATH 625 RX Schlage Lock Electric Cylindrical Lock
Type:
Electric Locks
Sub Type:
Electric Cylindrical Lock
Last Modified:
2021-04-08T06:45:50+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
1172.4
Avg Lead Time:
170
Popularity:
9
Pack Weight:
5
Baa Qualified:
Yes
Limited Warranty:
1 Year
Base Material:
Brass or Bronze
Vendor:
Allegion

Warranty Information

1 Year Warranty
