Schlage ND80BDEU SPA 626 RX Grade 1 Electrified Cylindrical Lock Storeroom Function 12-24 VDC Fail Secure 2-3/4 Backset Request to Exit Sparta Lever SFIC Prep Satin Chrome Finish

Schlage

Write a Review
SKU:
ND80BDEU SPA 626 RX
$805.05
Schlage ND80BDEU SPA 626 RX Grade 1 Electrified Cylindrical Lock Storeroom Function 12-24 VDC Fail Secure 2-3/4 Backset Request to Exit Sparta Lever SFIC Prep Satin Chrome Finish
UPC:
840067605523
$805.05

Descriptions

ND Series locks are available for electrically locking and unlocking controls for high security and fire safety applications.They are UL Listed and rated for both fire and electrical single-point locking on labeled doors. RX feature is available on ND10, ND12, ND80 and ND96 families. Switch is ready to be used in a normally open or normally closed application.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf

Specifications

Brand:
Schlage
Lever/Knob/Pull Design:
Sparta
Specifications Bullet 2:
Sparta Lever
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Number:
10-025
Country Of Origin:
Mexico
Commercial Residential:
Commercial
Can Be Keyed:
Yes
Specifications Bullet 8:
3-7/16" Rose Dimension
Manufacturer:
Schlage
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Specifications Bullet 11:
For Doors 1-5/8" - 2-1/8" Thick
Finish:
626/US26D
Lever/Knob/Pull:
Lever
Minimum Door Thickness (in):
1-5/8"
Door Handing:
Non-handed
Base Material:
Brass or Bronze
Latch Dimensions:
1-1/8" x 2-1/4"
Specifications Bullet 1:
Grade 1 Electrified Electronically Unlocked Storeroom Function Cylindrical Lockset
Latch Number:
13-247
Latch Throw (in):
1/2"
Box Height (in):
4-3/4"
Includes Cylinder(s)?:
No
Specifications Bullet 14:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Projection (in):
3-1/2"
Fire Rated:
Yes
Rose/Escutcheon Dimensions (in):
3-7/16"
Function:
Electronically Unlocked Storeroom
Specifications Bullet 12:
2-1/8" Bore Hole Diameter
ADA:
Yes
Box Depth (in):
9-1/2"
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Finish Description:
Satin Chrome
Specifications Bullet 4:
2-3/4" Backset
Bore Hole Diameter (in):
2-1/8"
Keyway:
Less Core
Specifications Bullet 7:
3-1/2" Projection
Latch Description:
Dead Latch
Box Weight (lbs):
5 lbs
Specifications Bullet 9:
1/2" Latch Throw
Strike Description:
ASA Strike
Latch Bore Diameter (in):
1"
Specifications Bullet 6:
12/24 VDC Voltage Fail Secure
Specifications Bullet 15:
1 Year Warranty
Grade:
Grade 1
Specifications Bullet 3:
SFIC Housing Less Core
Cylinder Type:
SFIC Housing
Box Width (in):
8-1/4"
Parent Manufacturer:
Allegion
Backset (in):
2-3/4"
Door Range (Thickness):
1-5/8" - 2-1/8"
FS/FSE Mode:
Fail Secure
Specifications Bullet 13:
Includes Wood/Metal Screws
Maximum Door Thickness (in):
2-1/8"
Electronic:
Yes
Screw Pack:
Wood/Metal Screws
UPC:
840067605523
Series:
ND Series
Specifications Bullet 10:
1-1/8" x 2-1/4" Dead Latch
Rose/Escutcheon:
Rose
Voltage:
12/24 VDC Voltage
Product Warranty:
1 Year Warranty
UOM:
1
Uid:
SCH100ND80BDEUSPA626RX
Url Title:
nd80bdeu-spa-626-rx
Title:
ND80BDEU SPA 626 RX Schlage Lock Electric Cylindrical Lock
Type:
Electric Locks
Sub Type:
Electric Cylindrical Lock
Series:
ND Series Electrified Lever Locks
Last Modified:
2021-06-24T12:52:07+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
1160.4
Avg Lead Time:
128
Popularity:
9
Pack Weight:
5
Baa Qualified:
Yes
Limited Warranty:
1 Year
Vendor:
Allegion

Warranty Information

1 Year Warranty
