Schlage ND80JDEL ATH 613 Grade 1 Electrified Cylindrical Lock Storeroom Function 12-24 VDC Fail Safe 2-3/4 Backset Athens Lever LFIC Prep Oil Rubbed Bronze Finish

Schlage

Write a Review
SKU:
ND80JDEL ATH 613
$0.00
Schlage ND80JDEL ATH 613 Grade 1 Electrified Cylindrical Lock Storeroom Function 12-24 VDC Fail Safe 2-3/4 Backset Athens Lever LFIC Prep Oil Rubbed Bronze Finish
UPC:
840067616475
$0.00

Descriptions

ND Series locks are available for electrically locking and unlocking controls for high security and fire safety applications.They are UL Listed and rated for both fire and electrical single-point locking on labeled doors. RX feature is available on ND10, ND12, ND80 and ND96 families. Switch is ready to be used in a normally open or normally closed application.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf

Specifications

Brand:
Schlage
ADA:
Yes
Projection (in):
3-5/16"
Latch Throw (in):
1/2"
Commercial Residential:
Commercial
Latch Dimensions:
1-1/8" x 2-1/4"
Specifications Bullet 13:
Includes Wood/Metal Screws
Specifications Bullet 3:
LFIC Housing Less Core
Specifications Bullet 7:
3-5/16" Projection
Box Depth (in):
9-1/2"
Includes Cylinder(s)?:
No
Function:
Electronically Locked Storeroom
Box Height (in):
4-3/4"
Minimum Door Thickness (in):
1-5/8"
Door Range (Thickness):
1-5/8" - 2-1/8"
Manufacturer:
Schlage
Rose/Escutcheon:
Rose
Selling Quantity:
1
Backset (in):
2-3/4"
Box Width (in):
8-1/4"
Specifications Bullet 8:
3-7/16" Rose Dimension
Specifications Bullet 4:
2-3/4" Backset
Box Weight (lbs):
5 lbs
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 10:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 15:
1 Year Warranty
Latch Bore Diameter (in):
1"
Specifications Bullet 2:
Athens Lever
Lever/Knob/Pull:
Lever
Finish:
613/US10B
Finish Description:
Dark Oxidized Satin Bronze Oil Rubbed
Maximum Door Thickness (in):
2-1/8"
Specifications Bullet 11:
For Doors 1-5/8" - 2-1/8" Thick
Specifications Bullet 1:
Grade 1 Electrified Electronically Locked Storeroom Function Cylindrical Lockset
Grade:
Grade 1
Door Handing:
Non-handed
Strike Number:
10-025
Cylinder Type:
LFIC Housing
Rose/Escutcheon Dimensions (in):
3-7/16"
Country Of Origin:
Mexico
FS/FSE Mode:
Fail Safe
Base Material:
Bronze
Latch Description:
Dead Latch
Can Be Keyed:
Yes
Product Warranty:
1 Year Warranty
Bore Hole Diameter (in):
2-1/8"
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Specifications Bullet 14:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Specifications Bullet 9:
1/2" Latch Throw
Lever/Knob/Pull Design:
Athens
Keyway:
Less Core
Strike Description:
ASA Strike
Specifications Bullet 12:
2-1/8" Bore Hole Diameter
Electronic:
Yes
Series:
ND Series
Fire Rated:
Yes
Latch Number:
13-247
Strike Dimensions:
1-1/4" x 4-7/8"
Specifications Bullet 6:
12/24 VDC Voltage Fail Safe
UPC:
840067616475
UOM:
1
Screw Pack:
Wood/Metal Screws
Parent Manufacturer:
Allegion
Voltage:
12/24 VDC Voltage
Uid:
SCH100ND80JDELATH613
Url Title:
nd80jdel-ath-613
Title:
ND80JDEL ATH 613 Schlage Lock Electric Cylindrical Lock
Type:
Electric Locks
Sub Type:
Electric Cylindrical Lock
Series:
ND Series Electrified Lever Locks
Last Modified:
2021-04-08T06:46:05+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
1094
Avg Lead Time:
17
Popularity:
9
Pack Weight:
5
Baa Qualified:
Yes
Limited Warranty:
1 Year
Vendor:
Allegion

Warranty Information

1 Year Warranty
