Von Duprin QEL9947EO 3 US28 Grade 1 Concealed Vertical Rod Exit Bar Wide Stile Pushpad 36 Device 80 to 100 Door Height Exit Only Motorized Latch Retraction Less Dogging Satin Aluminum Clear Anodized Finish Field Reversible

Von Duprin

Write a Review
SKU:
QEL9947EO 3 US28
$2,793.47
Von Duprin QEL9947EO 3 US28 Grade 1 Concealed Vertical Rod Exit Bar Wide Stile Pushpad 36 Device 80 to 100 Door Height Exit Only Motorized Latch Retraction Less Dogging Satin Aluminum Clear Anodized Finish Field Reversible
$2,793.47

Descriptions

9847/9947 Concealed vertical rod device for use on single or double metal doors, UL listed for panic exit hardware. The 9847 device has a smooth mechanism case and the 9947 device has a grooved case.
TypeTitleURL
brochure/sales-materialVon Duprin Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/vonduprin/miscellaneous/ALLEGION_finish-chart.pdf
catalogVon Duprin 98/99 Series Cataloghttps://dvwi9lnoau63q.cloudfront.net/vonduprin/catalogs/Von_Duprin_98.99_Series_Catalog_106590.pdf
data-sheetChexit (CX) Data Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/Von_Duprin_Chexit_Data_Sheet_110102.pdf
QEL Data Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/106586.pdf
installation-instructionsCX98/9947WDC Installations Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/109254.pdf
QEL 98/99 Baseplate Conversion Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/110746.pdf
QEL Conversion Kit for 98/99 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/110745.pdf
Von Duprin 33/35 and 98/99 ALK Alarm Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/107710.pdf
Von Duprin 33/35 and 98/99 End Cap Retrofit Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/109265.pdf
Von Duprin 33/99 LD Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/109278.PDF
Von Duprin Pneumatic Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/107614.pdf
miscellaneousQuiet Electric Latch FAQhttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/110624.pdf
price-book2024 Von Duprin Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/vonduprin/pricebooks/VON_pricebook_3-2024.pdf
sell-sheetQEL Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/103226.pdf
Von Duprin Exit Alarm Kit Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/105255.pdf
service-manual98/9947 Service Manualhttps://dvwi9lnoau63q.cloudfront.net/vonduprin/common-part-manuals/105675.pdf
template283 Strike Application for 98/9947-WDC, 33/3547-WDC, & 33/3547A-WDC Wood Door Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/wood-templates/109341.pdf
98/9947F and 98/9948F Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/templates/VD_98_9947-F_98_9948-F_Concealed_Vertical_Rod_Template.pdf
CX98/9947 and CX98/9948 Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/templates/VD_CX98_9947-F_CX98_9948-F_Concealed_Vertical_Rod_Template.pdf
STD & CX98/9947WDC Series Wood Door Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/wood-templates/108741.pdf
STD & CX98/9947WDC-F-LBR Series Wood Door Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/wood-templates/109340.pdf
video10 Things You Need to Know About the Von Duprin Chexithttps://youtu.be/JAhF99eIAMg

Specifications

Brand:
Von Duprin
Specifications Bullet 1:
Electrified Concealed Vertical Rod Exit Device
Manufacturer:
Von Duprin
Dogging Type:
Electronic Dogging
Door Material:
Metal
Can Be Keyed:
No
Function:
Exit Only
Specifications Bullet 11:
Includes Metal/Wood Screws
Base Material:
Aluminum
Grade:
Grade 1
Country Of Origin:
USA
Latch Description:
Deadlocking
Latch Throw (in):
5/8"
Specifications Bullet 13:
1 Year Warranty
Electronic:
Yes
Center Case Dimensions:
8" x 2-3/4" x 2-3/8"
Commercial Residential:
Commercial
Specifications Bullet 12:
ANSI A156.3-2014, Grade 1
Finish:
628/US28
Specifications Bullet 2:
(QEL) Quiet Electronic Latch Retraction
Specifications Bullet 10:
Electronic Dogging
Selling Quantity:
1
Includes Cylinder(s)?:
No
Door Width Minimum (in):
28"
End Cap Material:
Cast Zinc
Finish Description:
Satin Aluminum Clear Anodized
Door Width Maximum (in):
36"
Specifications Bullet 8:
For Doors 1-3/4" - 2-1/8" Thick
Voltage:
24 VDC Voltage
Certification:
ANSI A156.3-2014, Grade 1
Current:
1A Inrush, 140mA Holding Current
Door Range (Thickness):
1-3/4" - 2-1/8"
Dogging Option:
Yes
UOM:
1
Cylinder Type:
Not Applicable
Keyway:
Not Applicable
Minimum Door Thickness (in):
1-3/4"
Door Handing:
Non-handed
Maximum Door Thickness (in):
2-1/8"
Specifications Bullet 5:
For Doors 28" - 36" Wide
Specifications Bullet 7:
3-13/16" Projection
Door Height (in):
84"
Specifications Bullet 9:
5/8" Latch Throw
Option 1:
(QEL) Quiet Electronic Latch Retraction
Strike Number:
338/385A
Specifications Bullet 3:
24 VDC Voltage
Product Warranty:
1 Year Warranty
Specifications Bullet 6:
4-3/4" Minimum Stile
Screw Pack:
Metal/Wood Screws
Series:
9947 Series Concealed Vertical Rod Exit Device
Fire Rated:
No
Specifications Bullet 4:
1A Inrush, 140mA Holding Current
Projection (in):
3-13/16"
Product Width (in):
36"
Minimum Stile (in):
4-3/4"
Type:
Concealed Vertical Rod Exit Device
Parent Manufacturer:
Allegion
Uid:
VON100QEL9947EO3US28
Url Title:
qel9947eo-3-us28
Title:
QEL9947EO 3 US28 Von Duprin Concealed Vertical Rod Exit Devices
Type:
Exit Devices
Sub Type:
Concealed Vertical Rod Exit Devices
Last Modified:
2023-02-28T07:15:18+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
3795
Avg Lead Time:
49
Finish Family:
Matte Silver
Popularity:
9
Pack Weight:
17
Pack Length:
37
Pack Width:
5
Pack Height:
10.5
Pack Volume:
1942.5
Ul Listing:
UL 305
Ansi Code:
A156.3
Restrictions:
None
Baa Qualified:
Yes
Limited Warranty:
1 Year
Accessible:
No
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
3
Vendor:
Allegion
Assembly Item:
1

Warranty Information

1 Year Warranty
