Arrow RK01-BD-03 Grade 2 Passage Cylindrical Lock Ball Knob Non-Keyed Bright Brass Finish Non-handed

Arrow

Write a Review
SKU:
RK01-BD-03
$34.47
Arrow RK01-BD-03 Grade 2 Passage Cylindrical Lock Ball Knob Non-Keyed Bright Brass Finish Non-handed
UPC:
810007503561
$34.47

Descriptions

The RK Series has been enhanced to offer a wide variety of finishes and functions. The RK Series cylindrical locksets are an economical value for a variety of application. Perfect for multi-family housing markets, as well as light commercial applications.
TypeTitleURL
catalog2014 Arrow Full Line Cataloghttps://dvwi9lnoau63q.cloudfront.net/arrow/catalog/ARR_catalog_2014.pdf
cut-sheetRK Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/RKSeries.pdf
instructionsRK Series Instructionshttps://dvwi9lnoau63q.cloudfront.net/arrow/instructions/RK_Install_Inst.pdf
templateRK & RL Series Templatehttps://dvwi9lnoau63q.cloudfront.net/arrow/template/RK_RL_Template.pdf

Specifications

Brand:
Arrow
Series:
RK Series Grade 2 Cylindrical Knob Locks
Includes Cylinder(s)?:
No
Commercial Residential:
Commercial
Door Range (Thickness):
1-3/8" - 1-3/4"
ADA:
No
Function:
Passage
Grade:
Grade 2
Latch Throw (in):
1/2"
Cylinder Type:
Keyless
Specifications Bullet 1:
Grade 2 Passage Function Cylindrical Lockset
Backset (in):
2-3/8"
Latch Bore Diameter (in):
1"
Latch Dimensions:
1" x 2-1/4"
Can Be Keyed:
No
Latch Number:
R72
Lever/Knob/Pull Design:
Ball
Parent Manufacturer:
Assa Abloy
Rose/Escutcheon:
Rose
Finish Description:
Bright Brass
Specifications Bullet 10:
ANSI A156.2, Series 4000, Grade 2, UL Listed
Door Handing:
Non-handed
Specifications Bullet 6:
2-3/4" Projection
Product Warranty:
5 Year Warranty
Specifications Bullet 2:
Ball Knob
Electronic:
No
Projection (in):
2-3/4"
UOM:
1
UPC:
810007503561
Specifications Bullet 8:
For Doors 1-3/8" - 1-3/4" Thick
Specifications Bullet 7:
2-1/2" Rose
Latch Description:
Spring Latch
Strike Number:
R60
Finish:
605/US3
Bore Hole Diameter (in):
2-1/8"
Country Of Origin:
Taiwan
Base Material:
Brass
Rose/Escutcheon Dimensions (in):
2-1/2"
Lever/Knob/Pull:
Knob
Specifications Bullet 3:
2-3/8" Backset
Strike Dimensions:
1-1/8" x 2-3/4"
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 9:
2-1/8" Bore Hole Diameter
Fire Rated:
3 Hours {A}
Keyway:
Not Applicable
Minimum Door Thickness (in):
1-3/8"
Manufacturer:
Arrow
Certification:
ANSI A156.2, Series 4000, Grade 2, UL Listed
Selling Quantity:
1
Specifications Bullet 11:
5 Year Warranty
Strike Description:
T-Strike
Specifications Bullet 5:
1-1/8" x 2-3/4" T-Strike
Rose/Escutcheon Design:
Not Applicable
Specifications Bullet 4:
1" x 2-1/4" Spring Latch
Uid:
ARR100RK01BD3
Url Title:
rk01bd-3
Title:
Arrow RK01-BD-03 Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-26T06:57:16+00:00
Last Pricing:
2023-01-12T00:00:00+00:00
Msrp:
60
Avg Lead Time:
22
Finish Family:
Polished Brass
Popularity:
7
Pack Weight:
1.7
Pack Length:
7.875
Pack Width:
3.625
Pack Height:
3.25
Pack Volume:
92.77734375
Ul Listing:
ANSI A156.2 Series 4000, Grade 2, UL Listed
Ansi Code:
F75
Limited Warranty:
5 Year Warranty
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

5 Year Warranty
