Arrow RK12-BD-03-CS Grade 2 Storeroom Cylindrical Lock Ball Knob Conventional Cylinder Schlage C Keyway Bright Brass Finish Non-handed

Arrow

Write a Review
SKU:
RK12-BD-03-CS
$57.89
Arrow RK12-BD-03-CS Grade 2 Storeroom Cylindrical Lock Ball Knob Conventional Cylinder Schlage C Keyway Bright Brass Finish Non-handed
UPC:
810007503677
$57.89

Descriptions

The RK Series has been enhanced to offer a wide variety of finishes and functions. The RK Series cylindrical locksets are an economical value for a variety of application. Perfect for multi-family housing markets, as well as light commercial applications.
TypeTitleURL
catalog2014 Arrow Full Line Cataloghttps://dvwi9lnoau63q.cloudfront.net/arrow/catalog/ARR_catalog_2014.pdf
cut-sheetRK Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/RKSeries.pdf
instructionsRK Series Instructionshttps://dvwi9lnoau63q.cloudfront.net/arrow/instructions/RK_Install_Inst.pdf
templateRK & RL Series Templatehttps://dvwi9lnoau63q.cloudfront.net/arrow/template/RK_RL_Template.pdf

Specifications

Brand:
Arrow
Electronic:
No
Latch Throw (in):
1/2"
Lever/Knob/Pull:
Knob
Finish:
605/US3
Strike Number:
R60
Latch Dimensions:
1" x 2-1/4"
Country Of Origin:
Taiwan
Specifications Bullet 6:
1-1/8" x 2-3/4" T-Strike
Grade:
Grade 2
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Specifications Bullet 5:
1" x 2-1/4" Dead Latch
Specifications Bullet 7:
2-3/4" Projection
Fire Rated:
3 Hours {A}
Door Handing:
Non-handed
Specifications Bullet 9:
For Doors 1-3/8" - 1-3/4" Thick
Specifications Bullet 4:
2-3/8" Backset
Maximum Door Thickness (in):
1-3/4"
UPC:
810007503677
Rose/Escutcheon Design:
Not Applicable
Specifications Bullet 3:
Conventional C Keyway
Latch Number:
R70
Keyway:
C Keyway
Selling Quantity:
1
Rose/Escutcheon:
Rose
Latch Description:
Dead Latch
Latch Bore Diameter (in):
1"
Strike Dimensions:
1-1/8" x 2-3/4"
Specifications Bullet 1:
Grade 2 Storeroom Function Cylindrical Lockset
Lever/Knob/Pull Design:
Ball
Function:
Storeroom
Product Warranty:
5 Year Warranty
Specifications Bullet 2:
Ball Knob
Cylinder Type:
Conventional
Finish Description:
Bright Brass
Commercial Residential:
Commercial
Minimum Door Thickness (in):
1-3/8"
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 2, UL Listed
Parent Manufacturer:
Assa Abloy
Projection (in):
2-3/4"
ADA:
No
Backset (in):
2-3/8"
Specifications Bullet 8:
2-1/2" Rose
Includes Cylinder(s)?:
Yes
Door Range (Thickness):
1-3/8" - 1-3/4"
Specifications Bullet 12:
5 Year Warranty
Bore Hole Diameter (in):
2-1/8"
Manufacturer:
Arrow
Rose/Escutcheon Dimensions (in):
2-1/2"
Strike Description:
T-Strike
Certification:
ANSI A156.2, Series 4000, Grade 2, UL Listed
UOM:
1
Base Material:
Brass
Can Be Keyed:
Yes
Series:
RK Series

Warranty Information

5 Year Warranty
