  • Sargent 42 RA 32D 1-1/4 Mortise Cylinder RA Keyway Satin Stainless Steel

Sargent 42 RA 32D 1-1/4 Mortise Cylinder RA Keyway Satin Stainless Steel

Sargent

Write a Review
SKU:
42 RA 32D
$78.10
Sargent 42 RA 32D 1-1/4 Mortise Cylinder RA Keyway Satin Stainless Steel
$78.10

Descriptions

Sargent mortise cylinders are made from solid brass and have a brass, bronze or stainless steel face cap avaialable in all architechtural finishes. They are furnished standard with number 97 rosette and compression spring. Optional collars and spacers are available and ordered separately. Sargent mortise cylinders are available in lengths ranging from 1-1/8" through 3", minimum length for 7-Pin is 1-1/4". They are provided standard with Sargent offset cam number 13-0664, other cams are available.

Specifications

Brand:
Sargent
Country Of Origin:
USA
Diameter (in):
1-5/32" Cylinder Diameter
Cylinder Type:
Conventional
Specifications Bullet 5:
1-5/32" Cylinder Diameter
Includes:
Rose and Compression Springs
Dimensions:
1-1/4"
CAM Description:
Standard Offset
Keyway:
42 RA Keyway
CAM Number:
13-0664
Finish Description:
Satin Stainless Steel
Keying Detail:
(KD) Keyed Different
Series:
Mortise Cylinders
Finish:
630/US32D
Base Material:
Stainless Steel
Number of Pins:
6-pin
Manufacturer:
Sargent
Number of Keys:
2
Specifications Bullet 1:
1-1/4" Mortise Cylinder
Specifications Bullet 4:
Includes 13-0664 Standard Offset CAM
Specifications Bullet 3:
Includes Rose and Compression Springs, 2 Keys
Specifications Bullet 2:
Conventional 6-pin 42 RA Keyway (KD) Keyed Different
Door Range (Thickness):
-
Parent Manufacturer:
Assa Abloy
Uid:
SAR10042RA32D
Url Title:
42-ra-32d
Title:
42 RA 32D Sargent Mortise Cylinder
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Cylinder
Last Modified:
2024-03-02T05:04:21+00:00
Last Pricing:
2024-03-01T00:00:00+00:00
Msrp:
125
Avg Lead Time:
26
Popularity:
3
Pack Weight:
0.54
Pack Length:
4.125
Pack Width:
2.375
Pack Height:
1.875
Pack Volume:
18.36914063
Baa Qualified:
Yes
Unit Of Measure:
Each
