Descriptions
Features
Handing: Non-handed, except DL3017, which is handed and field reversible.
Door Thickness: Standard - 1-3/4" (44mm) - 2-1/4" (57mm). Optional door thicknesses available; see Quick Codes.
Backset: Standard - 2-3/4" (70mm); Optional - 2-3/8" (60mm)
Front: Standard - wrought brass or bronze, 2-1/4" (57mm) x 1-1/8" (29mm). Accommodates flat doors and doors beveled 1/8" (3mm) in 2" (51mm).
Deadbolt: Zinc diecast hardened steel insert. 1" (25mm) throw, 5/8" (16mm) wide x 3/4" (19mm) high.
Strike: Standard - 2-3/4" (70mm) x 1-1/8" (29mm). Optional strikes and wrought boxes available
Cylinder: Brass, 6-pin, L4 keyway, 0-bitted. Security cylinders optional; see Quick Codes.
Keys: Two nickel silver standard.
Keying Features Available; Master keying; Construction master keying; 7-pin (FC) conventional; Interchangeable core (IC); Security; Security (IC); Visual key control; Concealed key control; Pyramid (FC); Pyramid (IC)
Warranty: One-year limited.
| Type | Title | URL |
|---|---|---|
| catalog | Alarm Lock Product Catalog | https://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/ALA112U-Alarm-Lock-2019.pdf |
| Padlocks and Deadlocks Catalog | https://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/45012.pdf | |
| ec-listings | EC Declaration of Conformity for the DL3000 Series Cylindrical Lock | https://dvwi9lnoau63q.cloudfront.net/corbin/eclistings/EC_DL3000_Series.PDF |
| installation-instructions | DL3000 Installation Instructions | https://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/fm35d.pdf |
| misellaneous | DL3000 Parts List With Exploded View | https://dvwi9lnoau63q.cloudfront.net/corbin/miscellaneous/DL3000_WI993_PARTS.pdf |
| DL3000WP Parts List With Exploded View | https://dvwi9lnoau63q.cloudfront.net/corbin/miscellaneous/DL3000WP_WI993_PARTS.pdf | |
| DL3000WP Wiring Instructions | https://dvwi9lnoau63q.cloudfront.net/corbin/miscellaneous/OI245.pdf | |
| price-book | 2023 Corbin Price Book (updated 10.2023) | https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf |
