Schlage ND10S ATH 625 Grade 1 Passage Latch Athens Lever Non-Keyed Bright Chrome Finish Non-Handed

Schlage

Write a Review
SKU:
ND10S ATH 625
$422.04
UPC:
810007502830
$422.04

Descriptions

Walter Schlage invented the cylindrical lock in 1920. Since then, the Schlage Lock Company has consistently delivered innovation and continuous improvement. In that tradition, The ND Series Cylindrical Lockset is a proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application. The Schlage ND Series Locksets are commonly used in Healthcare, Education, Government, Office, Retail, and other commercial applications. The ND Series has been certified Grade 1; exceeding 3-million operating cycles without failure. This provides confidence that the lock will last within any type of facility. Finally, Schlage has incorporated wire-wireless capabilities that meet the access control and security needs of every facility owner.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Locks & Latches Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Allegion_2014_Commercial_Product_Catalogue_ND_Series_0114.pdf
ND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
installation-guideSchlage ND-Series Standard Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDSeriesStandInstallInstructionslocksmanafter8-15-2012.pdf
Schlage ND-Series Standard Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDStandInstallInstructionslocksmanubefore8-15-2012.pdf
installation-instructionsND Series Electrified Functions Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108353.PDF
ND Series Electrified Functions Installation Instructions (solenoid, mfg before 3-14-2016)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/111248.pdf
ND Series Hollow Metal Door Spacer Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/107544.pdf
ND170 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108996.pdf
ND170 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106121.pdf
ND25 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108995.pdf
ND25 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106122.pdf
Video: ND Series Lock Installationhttps://youtu.be/U6fUoLLH7Kw
keyway-diagramEverest 29 S Keyway Family Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/S-Family_Open_Keyway_Diagram.pdf
Everest Keyways Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Everest_Keyways.pdf
Observe Keyways for Classic Conventional Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Convetional_Observe_Keyways.pdf
Observe Keyways for Classic Primus XP Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Primus_Observe_Keyways.pdf
miscellaneousND Series Locks & Latches Warrantyhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/Schlage_ND_Series_Commercial_Warranty_December_2013.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
sell-sheetSchlage ND Series Electrified Cylindrical Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/Schlage_ND_Series_Data_Sheet_110875.pdf
Schlage ND Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106486NDsellsheet.pdf
service-manualSchlage ND Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/2021_Schlage_ND_Series_Service_Manual.pdf
templateND Series Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/Schlage_ND_Series_Template.pdf

Specifications

Brand:
Schlage
Backset (in):
2-3/4"
ADA:
Yes
Box Height (in):
4-3/4"
Grade:
Grade 1
Latch Number:
13-248
Electronic:
No
Strike Description:
ASA Strike
Latch Description:
Spring Latch
Product Warranty:
10 Year Warranty
Latch Dimensions:
1-1/8" X 2-1/4"
Door Range (Thickness):
1-5/8" - 2-1/8"
Specifications Bullet 3:
2-3/4" Backset
Series:
ND Series Lever Locks
Fire Rated:
3 Hours {A}
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Number of Keys:
2
Cylinder Type:
Keyless
Includes Cylinder(s)?:
No
Finish:
625/US26
Can Be Keyed:
No
Specifications Bullet 4:
1-1/8" X 2-1/4" Spring Latch
Specifications Bullet 6:
3-5/16" Projection
Specifications Bullet 10:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Keyway:
Not Applicable
Interior/Exterior:
Interior/Exterior
Finish Description:
Bright Chrome
Rose/Escutcheon Dimensions (in):
3-7/16"
Latch Throw (in):
1/2"
Bore Hole Diameter (in):
2-1/8"
Specifications Bullet 2:
Athens Lever
Specifications Bullet 7:
3-7/16" Rose
Specifications Bullet 1:
Grade 1 Passage Function Cylindrical Lockset
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Lever/Knob/Pull:
Lever
Door Handing:
Non-handed
Function:
Passage
Specifications Bullet 8:
For Doors 1-5/8" - 2-1/8" Thick
Number of Pins:
6
Box Depth (in):
9-1/2"
Minimum Door Thickness (in):
1-5/8"
Specifications Bullet 11:
10 Year Warranty
Box Weight (lbs):
5 lbs
Country Of Origin:
Mexico
Commercial Residential:
Commercial
Base Material:
Brass Bronze
Specifications Bullet 9:
2-1/8" Bore Hole Diameter
Projection (in):
3-5/16"
Box Width (in):
8-1/4"
Lever/Knob/Pull Design:
Athens
Rose/Escutcheon:
Rose
Rose/Escutcheon Design:
Not Applicable
Maximum Door Thickness (in):
2-1/8"
Strike Dimensions:
1-1/4" x 4-7/8"
UPC:
810007502830
Strike Number:
10-025
Selling Quantity:
1
UOM:
1
Manufacturer:
Schlage
Parent Manufacturer:
Allegion

Warranty Information

10 Year Warranty
