Schlage ND50JD ATH 613 Grade 1 Entrance/Office Lock Athens Lever Schlage FSIC Prep Less Core Oil Rubbed Bronze Finish Non-Handed

Schlage

Write a Review
SKU:
ND50JD ATH 613
$545.74
UPC:
840067614372
$545.74

Descriptions

Walter Schlage invented the cylindrical lock in 1920. Since then, the Schlage Lock Company has consistently delivered innovation and continuous improvement. In that tradition, The ND Series Cylindrical Lockset is a proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application. The Schlage ND Series Locksets are commonly used in Healthcare, Education, Government, Office, Retail, and other commercial applications. The ND Series has been certified Grade 1; exceeding 3-million operating cycles without failure. This provides confidence that the lock will last within any type of facility. Finally, Schlage has incorporated wire-wireless capabilities that meet the access control and security needs of every facility owner.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Locks & Latches Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Allegion_2014_Commercial_Product_Catalogue_ND_Series_0114.pdf
ND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
installation-guideSchlage ND-Series Standard Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDSeriesStandInstallInstructionslocksmanafter8-15-2012.pdf
Schlage ND-Series Standard Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDStandInstallInstructionslocksmanubefore8-15-2012.pdf
installation-instructionsND Series Electrified Functions Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108353.PDF
ND Series Electrified Functions Installation Instructions (solenoid, mfg before 3-14-2016)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/111248.pdf
ND Series Hollow Metal Door Spacer Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/107544.pdf
ND170 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108996.pdf
ND170 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106121.pdf
ND25 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108995.pdf
ND25 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106122.pdf
Video: ND Series Lock Installationhttps://youtu.be/U6fUoLLH7Kw
keyway-diagramEverest 29 S Keyway Family Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/S-Family_Open_Keyway_Diagram.pdf
Everest Keyways Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Everest_Keyways.pdf
Observe Keyways for Classic Conventional Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Convetional_Observe_Keyways.pdf
Observe Keyways for Classic Primus XP Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Primus_Observe_Keyways.pdf
miscellaneousND Series Locks & Latches Warrantyhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/Schlage_ND_Series_Commercial_Warranty_December_2013.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
sell-sheetSchlage ND Series Electrified Cylindrical Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/Schlage_ND_Series_Data_Sheet_110875.pdf
Schlage ND Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106486NDsellsheet.pdf
service-manualSchlage ND Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/2021_Schlage_ND_Series_Service_Manual.pdf
templateND Series Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/Schlage_ND_Series_Template.pdf

Specifications

Brand:
Schlage
Function:
Office
Box Weight (lbs):
5 lbs
Latch Number:
13-247
Finish:
613/US10B
Commercial Residential:
Commercial
Country Of Origin:
Mexico
Specifications Bullet 5:
1-1/8" X 2-1/4" Dead Latch
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Rose/Escutcheon Design:
Not Applicable
Latch Dimensions:
1-1/8" X 2-1/4"
Specifications Bullet 11:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Door Range (Thickness):
1-5/8" - 2-1/8"
Box Height (in):
4-3/4"
Specifications Bullet 3:
LFIC Housing Less Core
Electronic:
No
Specifications Bullet 7:
3-5/16" Projection
Specifications Bullet 8:
3-7/16" Rose
Fire Rated:
3 Hours {A}
Maximum Door Thickness (in):
2-1/8"
Finish Description:
Oil Rubbed Bronze
Specifications Bullet 2:
Athens Lever
Interior/Exterior:
Interior/Exterior
Product Warranty:
10 Year Warranty
Number of Keys:
2
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Strike Description:
ASA Strike
Backset (in):
2-3/4"
Specifications Bullet 12:
10 Year Warranty
Specifications Bullet 9:
For Doors 1-5/8" - 2-1/8" Thick
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon:
Rose
Can Be Keyed:
Yes
Base Material:
Bronze
Parent Manufacturer:
Allegion
UOM:
1
Door Handing:
Non-handed
Latch Description:
Dead Latch
Keyway:
Less Core
Number of Pins:
6
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Grade:
Grade 1
Bore Hole Diameter (in):
2-1/8"
Box Width (in):
8-1/4"
Lever/Knob/Pull Design:
Athens
ADA:
Yes
Manufacturer:
Schlage
Lever/Knob/Pull:
Lever
Latch Throw (in):
1/2"
Rose/Escutcheon Dimensions (in):
3-7/16"
Series:
ND Series Lever Locks
UPC:
840067614372
Specifications Bullet 4:
2-3/4" Backset
Box Depth (in):
9-1/2"
Selling Quantity:
1
Strike Number:
10-025
Projection (in):
3-5/16"
Minimum Door Thickness (in):
1-5/8"
Cylinder Type:
LFIC Housing
Specifications Bullet 1:
Grade 1 Office Function Cylindrical Lockset
Includes Cylinder(s)?:
No
Uid:
SCH100ND50JDATH613
Url Title:
nd50jd-ath-613
Title:
ND50JD ATH 613 Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-28T07:33:53+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
795
Avg Lead Time:
26
Finish Family:
Dark Bronze
Popularity:
9
Pack Weight:
5
Pack Length:
9.5
Pack Width:
8.25
Pack Height:
4.75
Pack Volume:
372.28125
Ul Listing:
UL/cUL Listed
Ansi Code:
ANSI A156.2 Series 4000, Grade 1
Baa Qualified:
Yes
Limited Warranty:
10 Years
Accessible:
Yes
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
6
Vendor:
Allegion

Warranty Information

10 Year Warranty
