Schlage ND70JD ATH 625 Grade 1 Classroom Lock Athens Lever Schlage FSIC Prep Less Core Bright Chrome Finish Non-Handed

Schlage

Write a Review
SKU:
ND70JD ATH 625
$533.83
UPC:
840067615447
$533.83

Descriptions

Walter Schlage invented the cylindrical lock in 1920. Since then, the Schlage Lock Company has consistently delivered innovation and continuous improvement. In that tradition, The ND Series Cylindrical Lockset is a proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application. The Schlage ND Series Locksets are commonly used in Healthcare, Education, Government, Office, Retail, and other commercial applications. The ND Series has been certified Grade 1; exceeding 3-million operating cycles without failure. This provides confidence that the lock will last within any type of facility. Finally, Schlage has incorporated wire-wireless capabilities that meet the access control and security needs of every facility owner.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Locks & Latches Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Allegion_2014_Commercial_Product_Catalogue_ND_Series_0114.pdf
ND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
installation-guideSchlage ND-Series Standard Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDSeriesStandInstallInstructionslocksmanafter8-15-2012.pdf
Schlage ND-Series Standard Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDStandInstallInstructionslocksmanubefore8-15-2012.pdf
installation-instructionsND Series Electrified Functions Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108353.PDF
ND Series Electrified Functions Installation Instructions (solenoid, mfg before 3-14-2016)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/111248.pdf
ND Series Hollow Metal Door Spacer Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/107544.pdf
ND170 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108996.pdf
ND170 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106121.pdf
ND25 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108995.pdf
ND25 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106122.pdf
Video: ND Series Lock Installationhttps://youtu.be/U6fUoLLH7Kw
keyway-diagramEverest 29 S Keyway Family Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/S-Family_Open_Keyway_Diagram.pdf
Everest Keyways Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Everest_Keyways.pdf
Observe Keyways for Classic Conventional Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Convetional_Observe_Keyways.pdf
Observe Keyways for Classic Primus XP Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Primus_Observe_Keyways.pdf
miscellaneousND Series Locks & Latches Warrantyhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/Schlage_ND_Series_Commercial_Warranty_December_2013.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
sell-sheetSchlage ND Series Electrified Cylindrical Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/Schlage_ND_Series_Data_Sheet_110875.pdf
Schlage ND Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106486NDsellsheet.pdf
service-manualSchlage ND Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/2021_Schlage_ND_Series_Service_Manual.pdf
templateND Series Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/Schlage_ND_Series_Template.pdf

Specifications

Brand:
Schlage
Box Depth (in):
9-1/2"
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Strike Dimensions:
1-1/4" x 4-7/8"
Function:
Classroom
Maximum Door Thickness (in):
2-1/8"
Backset (in):
2-3/4"
Bore Hole Diameter (in):
2-1/8"
Can Be Keyed:
Yes
Finish:
625/US26
Series:
ND Series Lever Locks
Grade:
Grade 1
Latch Description:
Dead Latch
Electronic:
No
Base Material:
Brass Bronze
Box Width (in):
8-1/4"
Lever/Knob/Pull Design:
Athens
Finish Description:
Bright Chrome
Interior/Exterior:
Interior/Exterior
Number of Keys:
2
Specifications Bullet 1:
Grade 1 Classroom Function Cylindrical Lockset
Specifications Bullet 9:
For Doors 1-5/8" - 2-1/8" Thick
Door Range (Thickness):
1-5/8" - 2-1/8"
Commercial Residential:
Commercial
UOM:
1
Includes Cylinder(s)?:
No
Cylinder Type:
LFIC Housing
ADA:
Yes
Fire Rated:
3 Hours {A}
Specifications Bullet 11:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Rose/Escutcheon Design:
Not Applicable
Manufacturer:
Schlage
Specifications Bullet 3:
LFIC Housing Less Core
Box Weight (lbs):
5 lbs
Lever/Knob/Pull:
Lever
Door Handing:
Non-handed
Country Of Origin:
Mexico
Keyway:
Less Core
Selling Quantity:
1
Latch Dimensions:
1-1/8" X 2-1/4"
Box Height (in):
4-3/4"
Parent Manufacturer:
Allegion
Strike Description:
ASA Strike
Specifications Bullet 8:
3-7/16" Rose
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Specifications Bullet 12:
10 Year Warranty
Latch Throw (in):
1/2"
Specifications Bullet 7:
3-5/16" Projection
Specifications Bullet 2:
Athens Lever
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 5:
1-1/8" X 2-1/4" Dead Latch
Latch Number:
13-247
Rose/Escutcheon Dimensions (in):
3-7/16"
Projection (in):
3-5/16"
Rose/Escutcheon:
Rose
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Minimum Door Thickness (in):
1-5/8"
Number of Pins:
6
Strike Number:
10-025
UPC:
840067615447
Product Warranty:
10 Year Warranty
Uid:
SCH100ND70JDATH625
Url Title:
nd70jd-ath-625
Title:
ND70JD ATH 625 Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-28T07:51:12+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
777
Avg Lead Time:
14
Finish Family:
Polished Silver
Popularity:
9
Pack Weight:
5
Pack Length:
9.5
Pack Width:
8.25
Pack Height:
4.75
Pack Volume:
372.28125
Ul Listing:
UL/cUL Listed
Ansi Code:
ANSI A156.2 Series 4000, Grade 1
Baa Qualified:
Yes
Limited Warranty:
10 Years
Accessible:
Yes
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
6
Vendor:
Allegion

Warranty Information

10 Year Warranty
