LCN 1450-Hw/PA 689 Grade 1 Cast Aluminum Surface Mount Closer Size 1-6 Adjustable Friction Hold Open Double Lever Arm with Parallel Bracket Non-Handed Slim Plastic Cover Aluminum Painted Finish

LCN

Write a Review
SKU:
1450-Hw/PA 689
$240.20
UPC:
840067623381
$240.20

Descriptions

The LCN Cast Aluminum Series closers were specially designed to deliver consistent, dependable, long lasting performance while offering high quality, effective solutions. This series of closers features a cast aluminum body, full compliment bearing, peel-n-stick templates and are offered in six standard finishes, as well as custom colors. The 1450 Series Medium Duty Closer is designed for frequent use and low abusive traffic areas, ideal for aluminum storefronts and interior offices.
TypeTitleURL
brochure/sales-materialLCN Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/lcn/miscellaneous/ALLEGION_finish-chart.pdf
catalog1000 Series Cataloghttps://dvwi9lnoau63q.cloudfront.net/lcn/catalog/LCN_1000_Series_Surface_Mounted_Closers_Catalog_Section_109508_1.pdf
LCN 1450T Cataloghttps://dvwi9lnoau63q.cloudfront.net/lcn/catalog/LCN_1450T_Catalog_Pages_111926.pdf
cut-sheet1450 Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/lcn/cutsheets/LCN_cutsheet_1450-series.pdf
installation-guideLCN 1250, 1450 & 4050 Flush Panel Adapter Bracket Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_1250_1450_and_4050_Series_419_Flush_Adapter_Installation_Instructions_110989.pdf
LCN 1450 & 1450DA Pull/Jamb/PA Mount Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_1450_Series_Pull_Top_Jamb_PA_Mount_IS_Installation_Instructions_110813.pdf
LCN 1450 Drop Plate Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_1450_Series_Drop_Plate_Installation_Instructions_110984.pdf
LCN 1450/1450DA CUSH/SCUSH Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_1450_Series_CUSH_SCUSH_Installation_Instructions_110982.pdf
LCN 1450/1450DA Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_1450_Series_EDA_Installation_Instructions_110981.pdf
LCN Closers & Auto Operators Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_Closers_and_Auto_Operators_Templates_and_Instructions_Index_111819.pdf
product-guideLCN 1000 Series Surface Mounted Closers Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/product-guide/LCN_1000_Series_Surface_Mounted_Closers_Catalog_Section_109508.pdf
LCN 1450 Series Data Sheethttps://dvwi9lnoau63q.cloudfront.net/lcn/product-guide/LCN1450SeriesDataSheet.pdf

Specifications

Brand:
LCN
Degree Swing:
180 Degree Swing
Hold Open:
Yes
Box Weight (lbs):
11 lbs
Specifications Bullet 7:
180 Degree Swing
Base Material:
Varies
Specifications Bullet 9:
Aluminum Body
Closing Speed Adjustment:
Yes
Specifications Bullet 3:
Friction Hold-Open
Specifications Bullet 5:
Tri Mount
Arm Type:
Hold Open Arm with PA Bracket
Specifications Bullet 10:
1-1/4" Piston Diameter
Door Handing:
Non-handed
Hold Open Type:
Friction Hold-Open
Advanced Backcheck:
No
Body Base Material:
Aluminum
Cover Type:
Slim Profile Cover
Parent Manufacturer:
Allegion
All Weather Fluid:
Yes
Selling Quantity:
1
Grade:
Grade 1
Backcheck:
Yes
Finish Description:
Aluminum Painted
Fire Rated:
Yes
Type:
Door Closers and Operators
Specifications Bullet 12:
ANSI A156.4, Grade 1, UL 10C, ADA
Box Width (in):
4-3/8"
Box Height (in):
4-3/8"
Electronic:
No
Latch Speed Adjustment:
Yes
Manufacturer:
LCN
Box Depth (in):
15-5/8"
Commercial Residential:
Commercial
Door Range (Thickness):
-
Specifications Bullet 1:
Grade 1 Surface Door Closer
Specifications Bullet 2:
Hold Open Arm with PA Bracket
Certification:
ANSI A156.4, Grade 1, UL 10C, ADA
Specifications Bullet 4:
Size 1-3
Specifications Bullet 6:
Non-handed
Finish:
689/US28
Maximum Door Weight (lbs):
225 lbs Maximum Door Weight
Product Warranty:
25 Year Warranty
Specifications Bullet 11:
Includes Self-Reaming Tapping Screws
Country Of Origin:
USA
Screw Pack Designation:
SRT
Mount:
Tri Mount
Specifications Bullet 8:
Plastic Slim Profile Cover
UPC:
840067623381
UOM:
1
Size:
Size 1-3
Cover Material:
Plastic
Specifications Bullet 13:
25 Year Warranty
Screw Pack:
Self-Reaming Tapping Screws
Piston Diameter (in):
1-1/4"
ADA:
Yes
Series:
1450 Series
Uid:
LCN1001450HWPAAL
Url Title:
1450-hw-pa-al
Title:
1450-HW/PA AL LCN Surface Closers
Sub Type:
Surface Closers
Series:
1450 Series Surface Mounted Closers
Last Modified:
2023-02-28T05:07:20+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
414
Avg Lead Time:
19
Finish Family:
Matte Silver
Popularity:
9
Pack Weight:
11
Ul Listing:
10C
Ansi Code:
A156.4
Baa Qualified:
Yes
Limited Warranty:
25 Years
Accessible:
Yes
Unit Of Measure:
Each
Vendor:
Allegion
Assembly Item:
1

Warranty Information

25 Year Warranty
