Sargent 16-AD8413F LHR 32D Grade 1 Concealed Vertical Rod Exit Device Narrow Stile Pushpad 36 Device 120 Door Height Classroom Function Cylinder Dogging Cylinder Included Satin Stainless Steel Finish Left Hand Reverse

Sargent

Write a Review
SKU:
16-AD8413F LHR 32D
$2,566.33
$2,566.33

Descriptions

The Sargent 80 Series exit devices are ideal for environments that require strong and durable security solutions that will last the life of the building. Available in rim, mortise, surface vertical and concealed vertical rod configurations, these exit devices easily exceed ANSI/BHMA Grade 1 requirements for cycle and strength. With modular construction and few moving parts, the 80 Series devices are maintenance-free and provide unsurpassed security for any facility. Plus, options are available for unique applications including delayed egress, alarmed exit and electric latch retraction making these exit devices the go-to product in your building.
TypeTitleURL
brochure/sales-material80 Series Brochurehttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/90788_80_Series_Exit_Device_Brochure_FINAL.pdf
catalog80 Series Exit Device Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SAR_catalog_80-series_9-2022.pdf
installation-instructions16- 816 Cylinder Dogging Kit (80 Series Exit Device) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6848.pdf
43-Flush End Cap Rail Cutting Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7581B.pdf
55-Signal Switch for 80 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6808C.pdf
565 & 665 Metal End Cap Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6924B.pdf
57-Delayed Action 80 Series Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6810F_Sargent_57_Prefix_Instructions_5-5-2009.pdf
57-Delayed Egress for 80 Series Exit Devices to ElectroLynx Connector System Installationhttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7743E.pdf
59-Electroguard Delayed Egress for 80 Series Exit Devices Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7690G.pdf
AD-8400, MD-8400& 12-MD-8400Series Concealed Vertical Rod Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6697L.pdf
AL- Alarmed Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7224C.pdf
Electric Dogging for 80 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6835C_58-12-58-Electric_Dogging_11-24-08.pdf
Mounting 80 Series Exit Device with Glass Bead Shim Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6710B.pdf
literatureBasic Fundamentals - Exit Deviceshttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/web_90691_SAR_Exits_Tech_lo.pdf
parts-list816 Cylinder Dogging Kit Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/80-9-D.pdf
parts-manual80 Series Parts Manualhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/80_Series_Parts_Manual.pdf
sell-sheet56-Electric Latch Retraction Exit Device Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/90625_SAR_56_Sell_lo.pdf
Windstorm Solutions - Exit Deviceshttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/90737_Windstorm_Exits.pdf

Specifications

Brand:
Sargent
Box Width (in):
36"
Commercial Residential:
Commercial
Center Case Dimensions:
1-1/16" x 8-5/16"
Manufacturer:
Sargent
Certification:
ANSI A156.3, Grade 1, UL Listed
Base Material:
Stainless Steel
Country Of Origin:
USA
Parent Manufacturer:
Assa Abloy
Series:
8400 Series Narrow Concealed Vertical Rod Exit Devices
Backset (in):
2-3/4"
Door Handing:
Left Hand Reverse
Door Height (in):
84"
Dogging Type:
Cylinder Dogging
Dogging Option:
Yes
Door Material:
Aluminum
Door Width Minimum (in):
33"
Electronic:
No
Door Range (Thickness):
1-3/4" - 2-1/4"
Door Width Maximum (in):
36"
Cylinder Type:
Less Cylinder
Latch Description:
Top - Bottom Latchbolts
Finish:
630/US32D
End Cap Material:
Metal
Finish Description:
Satin Stainless Steel
Fire Rated:
No
Latch Throw (in):
3/4"
Keyway:
Not Applicable
Grade:
Grade 1
Function:
Classroom
Includes Cylinder(s)?:
No
Specifications Bullet 4:
1-3/4" Minimum Stile
Specifications Bullet 8:
For Doors 1-3/4" - 2-1/4" Thick
Specifications Bullet 7:
For Doors 33" - 36" Wide
Specifications Bullet 5:
2-3/4" Backset
Specifications Bullet 6:
1-1/16" x 8-5/16" Center Case Dimension
Specifications Bullet 9:
For Aluminum Doors
Specifications Bullet 3:
Less Cylinder
Specifications Bullet 10:
3" Full Extension
Specifications Bullet 1:
Concealed Vertical Rod Exit Device, Classroom
Specifications Bullet 2:
(16) Cylinder Dogging
Specifications Bullet 13:
Metal End Cap
Specifications Bullet 11:
3/4" Top - Bottom Latchbolts
Specifications Bullet 15:
ANSI A156.3, Grade 1, UL Listed
Minimum Door Thickness (in):
1-3/4"
Specifications Bullet 14:
Includes Machine Screws, Fasteners
Specifications Bullet 16:
5 Year Warranty
Maximum Door Thickness (in):
2-1/4"
Minimum Stile (in):
1-3/4"
Option 1:
(16) Cylinder Dogging
Specifications Bullet 12:
Cylinder Dogging
UOM:
1
Type:
Concealed Vertical Rod Exit Device
Product Warranty:
5 Year Warranty
Projection (in):
3"
Screw Pack:
Machine Screws, Fasteners
Selling Quantity:
1
Strike Description:
Latchbolt Strike
Strike Number:
640
Uid:
SAR100168413FLHR32D
Url Title:
16-8413f-lhr-32d
Title:
16-AD8413F LHR 32D Sargent Concealed Vertical Rod Exit Device
Type:
Exit Devices
Sub Type:
Concealed Vertical Rod Exit Devices
Last Modified:
2023-02-13T06:06:38+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
3733
Finish Family:
Matte Silver
Popularity:
5
Pack Weight:
15
Pack Length:
38
Pack Width:
7.5
Pack Height:
6
Pack Volume:
1710
Ul Listing:
UL10C & UL305
Ansi Code:
ANSI/BHMA A156.3
Restrictions:
None
Baa Qualified:
Yes
Limited Warranty:
5 Years
Accessible:
No
Unit Of Measure:
Each
Vendor:
Assa Abloy
Assembly Item:
1

Warranty Information

5 Year Warranty
