Norton 1601H 690 Grade 1 Tri Mount Surface Closer Pull Side Double Lever Arm Regular Friction Hold 90 to 180 Deg Swing Adjustable Size 1-6 Dark Bronze Painted Finish Non-Handed

Norton

Write a Review
SKU:
1601H 690
$159.00
Norton 1601H 690 Grade 1 Tri Mount Surface Closer Pull Side Double Lever Arm Regular Friction Hold 90 to 180 Deg Swing Adjustable Size 1-6 Dark Bronze Painted Finish Non-Handed
$159.00

Descriptions

The Norton 1600 Series Door Closers are designed to fit almost any application and are the choice of engineers worldwide. Ideal for use with aluminum storefront doors and frames, these closers have a history of proven quality and tradition. The 1600 Series Door Closers exceed 12 million cycles, have a rack and pinion design with a cast aluminum body and are non-handed.
TypeTitleURL
catalog1600 Surface Closerhttps://dvwi9lnoau63q.cloudfront.net/norton/catalogs/43048_Norton_1600BC-1601.pdf
installation1600 Delayed Action Adjustment Instruction Sheethttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9316-0605-020.pdf
1600BC Tri-Stylehttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9316-2502-020.pdf
1600BCH Tri-Stylehttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9316-2504-020.pdf
1600SS, Corrosion Resistant, Non-Hold Open Onlyhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9316-2525-020.pdf
CLP1600BC, CloserPlushttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9316-2530-020.pdf
PR1600BC, Parallel Rigid Arm, Non-Hold Open or Hold Openhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9316-2530-020.pdf
UNI1600BC, Unitrolhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9316-2514-020.pdf
UNIJ1600BC, Unitrolhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9316-2517-020.pdf
literature1600 Series Door Closer - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/norton/literature/149.1_ASSA_ABLOY_mrEPD_Door_Closer_Norton_1600_series.pdf
price-books2023 Norton Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/norton/pricebooks/NOR_RIX_pricebook_4-2023.pdf
product-bulletins1600 Closer Exceeds 12 Million Cycleshttps://dvwi9lnoau63q.cloudfront.net/norton/product-bulletins/43321_Norton_1600_Exceeds_12_Mil_Cycles.pdf
sell-sheetNorton Rixson 1600 Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/norton/sell-sheet/NOR_sellsheet_1600-series.pdf

Specifications

Brand:
Norton
Specifications Bullet 10:
1-3/8" Piston Diameter
Screw Pack:
Self Drilling Screws
Specifications Bullet 6:
Non-handed
Specifications Bullet 2:
Hold Open Arm
Specifications Bullet 4:
Size 1-6
Specifications Bullet 1:
Grade 1 Surface Door Closer
Closing Speed Adjustment:
Yes
Cover Material:
Not Applicable
Specifications Bullet 7:
85-110 Degree Swing
Interior/Exterior:
Interior/Exterior
Specifications Bullet 9:
Aluminum Body
Finish:
690/US20
Door Range (Thickness):
-
ADA:
Yes
Finish Description:
Dark Bronze Painted
Cover Type:
Less Cover
Backcheck:
Yes
Specifications Bullet 8:
Less Cover
Hold Open:
Yes
Specifications Bullet 12:
ANSI A156.4, Grade 1, ANSI A117.1, UL Listed
Fire Rated:
3 Hours {A}
Specifications Bullet 5:
Tri Mount
Base Material:
Varies
Latch Speed Adjustment:
Yes
Hold Open Type:
Friction Hold-Open
Advanced Backcheck:
No
Body Base Material:
Aluminum
Specifications Bullet 13:
15 Year Warranty
Grade:
Grade 1
Parent Manufacturer:
Assa Abloy
Door Handing:
Non-handed
Arm Type:
Hold Open Arm
Certification:
ANSI A156.4, Grade 1, ANSI A117.1, UL Listed
Commercial Residential:
Commercial
Manufacturer:
Norton
Degree Swing:
85-110 Degree Swing
Mount:
Tri Mount
All Weather Fluid:
Yes
Piston Diameter (in):
1-3/8"
Maximum Door Weight (lbs):
225 lbs Maximum Door Weight
Specifications Bullet 3:
Friction Hold-Open
Electronic:
No
Selling Quantity:
1
Size:
Size 1-6
Type:
Door Closers and Operators
UOM:
1
Series:
1601 Series Closers
Product Warranty:
15 Year Warranty
Specifications Bullet 11:
Includes Self Drilling Screws
Uid:
NOR3001601H690
Url Title:
1601h-690
Title:
1601H 690 Norton Surface Closer
Sub Type:
Surface Closers
Last Modified:
2023-02-13T06:00:49+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
377
Avg Lead Time:
69
Finish Family:
Dark Bronze
Popularity:
3
Pack Weight:
8
Pack Length:
12.5
Pack Width:
5
Pack Height:
3.5
Pack Volume:
218.75
Ul Listing:
UL10C
Ansi Code:
ANSI/BHMA A156.4, Grade 1 Certified
Limited Warranty:
15 Years
Accessible:
No
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
6
Vendor:
Assa Abloy

Warranty Information

15 Year Warranty
