Yale 2100-36 630 Grade 1 Rim Exit Bar for Wide Stile Doors Narrow Stile Pushpad 36 Device Exit Only Hex Key Dogging Satin Stainless Steel Non-Handed

Yale

Write a Review
SKU:
2100-36 630
$592.04
Yale 2100-36 630 Grade 1 Rim Exit Bar for Wide Stile Doors Narrow Stile Pushpad 36 Device Exit Only Hex Key Dogging Satin Stainless Steel Non-Handed
$592.04

Descriptions

Providing a higher standard of ANSI/BHMA Grade 1 performance, the 2100 Series Exit Device is the right choice for meeting the rigors of everyday use. This economy exit device is now available with the Yale SquareBolt rim latch for the toughest applications. In addition to traditional painted finishes, the 2100 Series is available in an attractive satin stainless steel finish for use where aesthetics are also important.
TypeTitleURL
brochure/sales-materialYale Commercial Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/yale/literature/YALE_finish-chart.pdf
catalog2100 Series Flatbar Exit Device Cataloghttps://dvwi9lnoau63q.cloudfront.net/yale/catalogs/Yale2100web_42135_YA_2100_Cat_lo.pdf
installation-instructions2100, 2150 SquareBolt, and 1800 Rim Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/yale/installationinstructions/yale2100seriesinstallation.pdf
2110, 2170, 1810 Surface Vertical Rod Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/yale/installationinstructions/2100seriesinstallation.pdf
Exit Devices with Electric Dogging (G) and/or Monitorshttps://dvwi9lnoau63q.cloudfront.net/yale/installationinstructions/80-9477-0780-00001-13GOptionforExits.pdf
Exit Devices with Electric Latch Retraction (P) and/or Monitorshttps://dvwi9lnoau63q.cloudfront.net/yale/installationinstructions/80-9477-0781-00101-13POptionforExits.pdf
price-books2023 Yale Commercial Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/yale/pricebooks/YAL_pricebook_comm_4-2023.pdf
2024 Yale Commercial Price Book (effective 3.1.2024)https://dvwi9lnoau63q.cloudfront.net/yale/pricebooks/YALE_pricebook_commercial_2024.pdf

Specifications

Brand:
Yale
Commercial Residential:
Commercial
Specifications Bullet 9:
3/4" Dead Latch
Latch Description:
Dead Latch
Door Width Minimum (in):
30"
Specifications Bullet 5:
For Doors 30" - 36" Wide
Specifications Bullet 1:
Surface Exit Device, Exit Only
Specifications Bullet 14:
3 Year Warranty
Parent Manufacturer:
Assa Abloy
Specifications Bullet 2:
4-1/2" Minimum Stile
Cylinder Type:
Keyless
Dogging Type:
Hex Key Dogging
Door Handing:
Non-handed
Certification:
ANSI A156.3, Grade 1, UL Listed
Finish:
630/US32D
Door Height (in):
Not Applicable
Grade:
Grade 1
Specifications Bullet 6:
For Doors 1-3/4" Thick
Includes Cylinder(s)?:
No
Keyway:
Not Applicable
Backset (in):
2-3/4"
End Cap Material:
Metal
Specifications Bullet 4:
1-1/2" x 8" Center Case Dimension
Door Material:
Metal/Wood
Door Width Maximum (in):
36"
Specifications Bullet 3:
2-3/4" Backset
Finish Description:
Satin Stainless Steel
Dogging Option:
Yes
Function:
Exit Only
Fire Rated:
No
Specifications Bullet 10:
Hex Key Dogging
Center Case Dimensions:
1-1/2" x 8"
Door Range (Thickness):
1-3/4" - 1-3/4"
Specifications Bullet 8:
2-1/2" Full Extension
Screw Pack:
Wood/Machine Screws
Product Warranty:
3 Year Warranty
Electronic:
No
Base Material:
Stainless Steel
Product Width (in):
36"
Specifications Bullet 13:
ANSI A156.3, Grade 1, UL Listed
Latch Throw (in):
3/4"
Specifications Bullet 7:
For Metal/Wood Doors
Strike Description:
Roller Strike
Specifications Bullet 12:
Includes Wood/Machine Screws
Minimum Door Thickness (in):
1-3/4"
Specifications Bullet 11:
Metal End Cap
Selling Quantity:
1
Maximum Door Thickness (in):
1-3/4"
Projection (in):
2-1/2"
Series:
Yale 2100 Series Exit Devices
Manufacturer:
Yale
UOM:
1
Type:
Surface Exit Device
Strike Number:
757
Minimum Stile (in):
4-1/2"
Uid:
YAL200210036630
Url Title:
2100-36-630
Title:
2100-36 630 Yale Exit Device
Type:
Exit Devices
Sub Type:
Rim Exit Devices
Last Modified:
2023-02-26T05:07:20+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
822
Avg Lead Time:
58
Finish Family:
Matte Silver
Popularity:
3
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

3 Year Warranty
