Sargent 268-H EN LH Overhead Concealed Door Closer Concealed Track Hold Open Arm Left Hand Sprayed Aluminum Enamel

Sargent

Write a Review
SKU:
268-H EN LH
$742.84
Sargent 268-H EN LH Overhead Concealed Door Closer Concealed Track Hold Open Arm Left Hand Sprayed Aluminum Enamel
$742.84

Descriptions

The 268 Series is a complete line of overhead concealed closers for interior and exterior doors with quality and flexibility to meet virtually every application. When security is required, the concealed design of the 268 Series Closer provides a high degree of resistance to abuse. The arm, trach and closer are completely concealed when the door is closed.
TypeTitleURL
catalog268/269/278 Series Concealed Door Closers Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/web_90118_SAR_268269278_Cat_lo.pdf
cross-reference-sheetOverhead Concealed Closer Cross-Reference Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/crossreference/web_Rix_OverheadConcealedCloserCrossReference_Instr_hi.pdf
installation-instructions268 Series Concealed Door Closers (w/ 'CSP' Concealed Security Package) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7325B_low_res.pdf
268 Series Concealed Door Closers Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7320B_Sargent_268_Powerglide_Series_12162008.pdf
268/269 Series Concealed Door Closers (w/ 'CSPS/CSPD' Door Position) Installation Instructionhttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7326C.pdf
parts-list268/269 Case Assembly Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/268_PAGES_1-5.pdf
268/269 O Arm Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/268_PAGES_6-9.pdf
268/269 Security Arm Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/268_269_Page_10_Parts_List.pdf

Specifications

Brand:
Sargent
Manufacturer:
Sargent
Parent Manufacturer:
Assa Abloy
Advanced Backcheck:
No
Series:
268 Series Door Closers
ADA:
Yes
Body Base Material:
Cast Iron
Arm Type:
Hold Open Track Arm
Base Material:
Varies
All Weather Fluid:
Yes
Backcheck:
Yes
Cover Material:
Not Applicable
Commercial Residential:
Commercial
Certification:
ANSI A156.4, Grade 1, UL Listed
Country of Origin:
United States
Closing Speed Adjustment:
Yes
Door Range (Thickness):
-
Degree Swing:
110 Degree Swing
Electronic:
No
Cover Type:
Not Applicable
Door Handing:
Left Hand
Hold Open:
Yes
Finish:
689/US28
Fire Rated:
Yes
Finish Description:
Aluminum Painted
Grade:
Grade 1
Specifications Bullet 2:
Hold Open Track Arm
Interior/Exterior:
Interior/Exterior
Hold Open Type:
Friction Hold-Open
Specifications Bullet 1:
Grade 1 Concealed Door Closer
Latch Speed Adjustment:
Yes
Specifications Bullet 5:
Frame Mount
Specifications Bullet 7:
110 Degree Swing
Specifications Bullet 3:
Friction Hold-Open
Specifications Bullet 4:
Size 2-4
Specifications Bullet 6:
Left Hand
Uid:
SAR100268HENLH
Url Title:
268-h-en-lh
Title:
268-H EN LH Sargent Concealed Overhead Closers
Type:
Door Closers and Operators
Sub Type:
Concealed Overhead Closers
Last Modified:
2024-02-03T05:08:06+00:00
Last Pricing:
2023-04-17T00:00:00+00:00
Msrp:
1101
Avg Lead Time:
42
Finish Family:
Matte Silver
Popularity:
8
Pack Weight:
14.7
Pack Length:
23.75
Pack Width:
5.25
Pack Height:
5.75
Pack Volume:
716.953125
Limited Warranty:
10 Years
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

10 Year Warranty
