Sargent 28-6G05 OB 26D Grade 2 Entrance/Office Cylindrical Lock B Knob O Rose Conventional Cylinder Satin Chrome Finish Deadlatch Non-handed

Sargent

Write a Review
SKU:
28-6G05 OB 26D
$256.63
Sargent 28-6G05 OB 26D Grade 2 Entrance/Office Cylindrical Lock B Knob O Rose Conventional Cylinder Satin Chrome Finish Deadlatch Non-handed
$256.63

Descriptions

The 6 Line is a highly styled standard duty lock line incorporating a broad specturm of functions, designs and finishes. Ideally suited for fine homes, apartments, hotels and commercial buildings.
TypeTitleURL
brochure/sales-materialSargent Bored Lock Brochurehttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/SAR_Tzone_Generic_Brochure.pdf
catalog6-Line Bored Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Bored_Lock_6_Line_Knob_Lock_Catalog.pdf
installation-instructions6-Line Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A6286M.pdf
parts-list6-Line Knob/Lever Lock (6G05 Illustrated) Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/6.2-C.pdf
6-Line Lock Body Functions Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/6.1-C.pdf
6-Line Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/SARGENT_Bored_Lock_6_Line_Parts_List.pdf
template6-Line Bored Lock Templatehttps://dvwi9lnoau63q.cloudfront.net/sargent/templates/SARGENT_Bored_Lock_6_Line_Template_.pdf

Specifications

Brand:
Sargent
Lever/Knob/Pull:
Knob
Base Material:
Brass, Bronze
Door Handing:
Non-handed
Manufacturer:
Sargent
Latch Description:
Dead Latch
Fire Rated:
3 Hours {A}
Backset (in):
2-3/8"
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Can Be Keyed:
Yes
Rose/Escutcheon Design:
B
Bore Hole Diameter (in):
2-1/8"
Certification:
ANSI A156.2, Series 4000, Grade 2
Door Range (Thickness):
1-3/8" - 1-3/4"
Finish:
626/US26D
Finish Description:
Satin Chrome
Latch Throw (in):
1/2"
ADA:
Yes
Product Warranty:
1 Year Warranty
Keyway:
LA Keyway
Specifications Bullet 3:
Conventional LA Keyway
Maximum Door Thickness (in):
1-3/4"
Cylinder Type:
Conventional
Specifications Bullet 2:
O Knob
Specifications Bullet 1:
Grade 2 Entrance Office Function Cylindrical Lockset
Latch Dimensions:
1-1/8" x 2-1/4"
Includes Cylinder(s)?:
Yes
Specifications Bullet 9:
For Doors 1-3/8" - 1-3/4" Thick
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Strike Number:
808
Function:
Entrance Office
Specifications Bullet 8:
2-1/2" B Rose
Projection (in):
2-13/16"
Specifications Bullet 7:
2-13/16" Projection
Lever/Knob/Pull Design:
O
Specifications Bullet 4:
2-3/8" Backset
Grade:
Grade 2
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Latch Number:
06-5083
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 2
Rose/Escutcheon:
Rose
Strike Description:
ASA Strike
Minimum Door Thickness (in):
1-3/8"
Rose/Escutcheon Dimensions (in):
2-1/2"
Series:
6-Line Bored Knob Locks
Specifications Bullet 12:
1 Year Warranty
Parent Manufacturer:
Assa Abloy
Strike Dimensions:
1-1/4" x 4-7/8"
Uid:
SAR100286G05OB26D
Url Title:
28-6g05-ob-26d
Title:
Sargent 28-6G05 OB 26D Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-26T05:08:24+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Commercial Residential:
Commercial
Msrp:
358
Avg Lead Time:
12
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
4
Pack Length:
8.25
Pack Width:
7.125
Pack Height:
4.25
Pack Volume:
249.8203125
Ul Listing:
ANSI A156.2, Series 4000, Grade 2, UL Listed
Ansi Code:
F81
Country Of Origin:
United States
Limited Warranty:
1 Year Warranty
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
10
Vendor:
ASSA ABLOY
