Sargent 281-P10 TB EB Surface Door Closer Heavy Duty Parallel Arm Thru Bolts Sprayed Dark Bronze Enamel

Sargent

Write a Review
SKU:
281-P10 TB EB
$578.37
Sargent 281-P10 TB EB Surface Door Closer Heavy Duty Parallel Arm Thru Bolts Sprayed Dark Bronze Enamel
$578.37

Descriptions

The 281 Powerglide Series of cast iron surface door closers have been engineered to meet the high demands of architects and building owners. The 281 Series is a complete line of closers for interior and exterior doors with quality and flexibility to meet virtually every application.
TypeTitleURL
catalog281 Series Door Closer Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Door_Closer_281_Series_Powerglide_Door_Closer_Catalog.pdf
installation-instructions281 Door Closers with O10/H10/SSO Arms Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7921C.pdf
281 Series Door Closer (with 'F'/FZ/FZA/PF9 Fusible Link Arms) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7312B_low_res.pdf
281 Series Door Closer with P10 & PH10 Arms Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7314.pdf
281 Series Door Closers (with 'H'/UH/HZ/HZA/PH9/UH Holder Arms) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7313C.pdf
281 Series Door Closers (with Regular Arms 'O'/UO/OZ/OZA/P9) w/ out H Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7278E.pdf
281 Series Door Closers w/CPS & CPSH Arms Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7319E.pdf
281 Series Door Closers w/OD/ODB/HD/HDB Arms Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7422A.pdf
281 Series Door Closers w/OT/OTB/HTB Arms Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7318D.pdf
281 Series Door Closers w/PS & PSH Arms Instructions for Installationhttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7315F.pdf
281 Series Powerglide Door Closers (PSSPT Security Track) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7293B_low_res.pdf
281 Series Powerglide Door Closers (SSPT Security Track) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7317D_low_res.pdf
281 Series Powerglide Door Closers (with POT/POTB/PHT/PHTB Arms) Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/A7316D_low_res.pdf
literature281 Series Door Closer - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/sargent/literature/Sargent_281_EPD_2015_-_UL_Certified.pdf
parts-list25-CPS Heavy Duty Parallel Arm (with Compression Stop) Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25CPS.9-A.pdf
25-CPSH Heavy Duty Parallel Arm (with Hold Open & Compression Stop) Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25CPSH.10-A.pdf
25-F9 Fusible Link Arm Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25PF9.7-A.pdf
25-H Holder Arm Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/PART_LIST_25-H.pdf
25-HD Track Type Arm with Hold Open, Double Egress Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25-HD.pdf
25-HDB Arm and Track Assembly Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/Parts_list_25-HD.pdf
25-HDS Arm and Track Assembly Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/351.27-A.pdf
25-HDSB Arm and Track Assembly Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/351.28-A.pdf
25-HT Track Type Arm with Hold Open, Pull Side Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25-HT.pdf
25-HTB Track Type Arm, Hold Open with Bumper, Pull Side Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25-HDTD.pdf
25-O/OZ/OZA Regular Arm Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/PARTS_LIST_25-0_CLOSER_ARM.pdf
25-OD Track Type Arm, Double Egress Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25OD.21.pdf
25-ODB Track Type Arm with Bumper, Double Egress Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25ODB.22-A.pdf
25-ODS Arm and Track Assembly Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/351.25-A.pdf
25-ODSB Arm and Track Assembly Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/351.26-A.pdf
25-OT Track Type Arm, Pull Side Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/PARTS_LIST_25OT_PAGE_13.pdf
25-OTB Track Type Arm with Bumper, Pull Side Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25_ot.pdf
25-OTP Pocket Application Arm & Track Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/351.29-A.pdf
25-OTP Pocket Arm Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/351.30-A.pdf
25-P10/SP10 Heavy Duty Parallel Arm Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25P10.8.pdf
25-P9 Parallel Arm Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/PARTS_LIST_25-P9_CLOSER_ARM.pdf
25-PHT Track Type Arm with Hold Open, Push Side Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25-PHT.pdf
25-PHTB Track Type Arm Hold Open with Bumper, Push Side Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25-PHTB.pdf
25-POT Track Type Arm, Push Side Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25POT.pdf
25-POTB Track Type Arm with Bumper, Push Side Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25-POT.pdf
25-PS Heavy Duty Parallel Arm (with Stop) Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25PS.11-A.pdf
25-PSH Heavy Duty Parallel Arm (with Hold Open & Stop) Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/25PSH.12-A.pdf
281 Series Door Closer Body Assembly & Cover Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-list/281.1-A.pdf
281, 351 and 1431 Series Parts Listhttps://dvwi9lnoau63q.cloudfront.net/sargent/parts-manual/SARGENT_Door_Closer_1431351281_Series_Parts_List.pdf

Specifications

Brand:
Sargent
Base Material:
VARIES
Manufacturer:
Sargent
Parent Manufacturer:
Assa Abloy
Advanced Backcheck:
No
ADA:
Yes
Arm Type:
Heavy Duty Parallel Arm
Backcheck:
Yes
Series:
281 Surface Door Closers
Body Base Material:
Cast Iron
All Weather Fluid:
Yes
Door Range (Thickness):
-
Electronic:
No
Degree Swing:
180 Degree Swing
Certification:
ANSI A156.4, Grade 1, UL Listed
Commercial Residential:
Commercial
Closing Speed Adjustment:
Yes
Cover Type:
Full Body Cover
Door Handing:
Non-handed
Finish:
695
Cover Material:
Plastic
Interior/Exterior:
Interior/Exterior
Fire Rated:
3 Hours {A}
Specifications Bullet 1:
Grade 1 Surface Door Closer
Specifications Bullet 3:
Size 1-6
Specifications Bullet 2:
Heavy Duty Parallel Arm
Finish Description:
Dark Bronze Painted
Grade:
Grade 1
Hold Open:
No
Hold Open Type:
Not Applicable
Latch Speed Adjustment:
Yes
Maximum Door Weight (lbs):
225 lbs Maximum Door Weight
Specifications Bullet 11:
ANSI A156.4, Grade 1, UL Listed
Specifications Bullet 4:
Push Side Mount
Specifications Bullet 12:
25 Year Warranty
Specifications Bullet 8:
Cast Iron Body
Specifications Bullet 9:
1-1/2" Piston Diameter
Specifications Bullet 10:
Includes Thrubolt, Machine and Self Tappng Screws
Specifications Bullet 5:
Non-handed
Specifications Bullet 6:
180 Degree Swing
Specifications Bullet 7:
Plastic Full Body Cover
Type:
Door Closers and Operators
Trademark Term:
Powerglide
Size:
Size 1-6
UOM:
1
Mount:
Push Side Mount
Product Warranty:
25 Year Warranty
Screw Pack:
Thrubolt, Machine and Self Tappng Screws
Piston Diameter (in):
1-1/2"
Selling Quantity:
1
Uid:
SAR100281P10TBEB
Url Title:
281-p10-tb-eb
Title:
281-P10 TB EB Sargent Surface Closers
Sub Type:
Surface Closers
Last Modified:
2023-02-13T07:29:25+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
811
Avg Lead Time:
49
Finish Family:
Dark Bronze
Popularity:
8
Pack Weight:
14.1
Pack Length:
15
Pack Width:
5
Pack Height:
4.25
Pack Volume:
318.75
Limited Warranty:
25 Years
Unit Of Measure:
Each
Vendor:
Assa Abloy
Assembly Item:
1

Warranty Information

25 Year Warranty
