LCN 3033-REG LH 689 Regular Arm Door Closer Left Hand Aluminum

LCN

Write a Review
SKU:
3033-REG LH 689
$480.69
LCN 3033-REG LH 689 Regular Arm Door Closer Left Hand Aluminum
UPC:
840067660874
$480.69

Descriptions

The 3030 Series is a concealed door closer designed to mount in a 1-3/4 In. interior door. The double lever arm provides superior door control and the choice of finishes and arm functions meet virtually all architectural requirements.
TypeTitleURL
brochure/sales-materialLCN Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/lcn/miscellaneous/ALLEGION_finish-chart.pdf
catalogLCN Concealed Closers Cataloghttps://dvwi9lnoau63q.cloudfront.net/lcn/catalog/LCN_Concealed_Closers_Catalog_Section_109511.pdf
cross-reference-sheetOverhead Concealed Closer Cross-Reference Sheethttps://dvwi9lnoau63q.cloudfront.net/lcn/user-guide/web_Rix_OverheadConcealedCloserCrossReference_Instr_hi.pdf
installation-guideLCN 3030 Series Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN3030installationguide.pdf
LCN Closers & Auto Operators Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_Closers_and_Auto_Operators_Templates_and_Instructions_Index_111819.pdf

Specifications

Brand:
LCN
Specifications Bullet 1:
Grade 1 Concealed Door Closer
Specifications Bullet 10:
ANSI A156.4, Grade 1, UL 10C, ADA
Finish:
689/US28
Certification:
ANSI A156.4, Grade 1, UL 10C, ADA
Backcheck:
Yes
Degree Swing:
180 Degree Swing
Commercial Residential:
Commercial
Cover Material:
Not Applicable
Maximum Door Weight (lbs):
225 lbs Maximum Door Weight
Closing Speed Adjustment:
Yes
Electronic:
No
Finish Description:
Aluminum Painted
Hold Open Type:
Not Applicable
ADA:
Yes
Interior/Exterior:
Interior/Exterior
Screw Pack:
Wood/Machine Screws
Hold Open:
No
Specifications Bullet 4:
Door Mount
Specifications Bullet 7:
Cast Iron Body
Country of Origin:
United States
Specifications Bullet 11:
15 Year Limited Warranty
Specifications Bullet 3:
Size 3
Arm Type:
Regular Arm
Specifications Bullet 2:
Regular Arm
Parent Manufacturer:
Allegion
UPC:
840067660874
Fire Rated:
Yes
Specifications Bullet 6:
180 Degree Swing
Body Base Material:
Cast Iron
Base Material:
VARIES
All Weather Fluid:
Yes
Advanced Backcheck:
No
Type:
Door Closers and Operators
Latch Speed Adjustment:
Yes
Size:
Size 3
Selling Quantity:
1
Door Range (Thickness):
-
Door Handing:
Left Hand
Cover Type:
Not Applicable
Piston Diameter (in):
1-1/8"
Mount:
Door Mount
Screw Pack Designation:
WMS
Product Warranty:
15 Year Limited Warranty
Series:
3030 Series Concealed Closers
Specifications Bullet 5:
Left Hand
Specifications Bullet 9:
Includes Wood/Machine Screws
Grade:
Grade 1
Manufacturer:
LCN
Specifications Bullet 8:
1-1/8" Piston Diameter
UOM:
1
Uid:
LCN1003033REGLHAL
Url Title:
3033-reg-lh-al
Title:
3033-REG LH AL LCN Concealed-in-Door Closers
Sub Type:
Concealed-in-Door Closers
Last Modified:
2023-02-28T05:07:20+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
629
Avg Lead Time:
30
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
6
Baa Qualified:
Yes
Limited Warranty:
15 Years
Unit Of Measure:
Each
Vendor:
Allegion

Warranty Information

15 Year Limited Warranty
