  • LCN 4011-H RH 695 Hold Open Arm Door Closer Right Hand Dark Bronze

LCN 4011-H RH 695 Hold Open Arm Door Closer Right Hand Dark Bronze

LCN

Write a Review
SKU:
4011-H RH 695
$538.37
LCN 4011-H RH 695 Hold Open Arm Door Closer Right Hand Dark Bronze
UPC:
840067624029
$538.37

Descriptions

The 4010 is LCN's best performing heavy duty surface door closer designed for institutional and other high traffic applications.
TypeTitleURL
brochure/sales-materialLCN Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/lcn/miscellaneous/ALLEGION_finish-chart.pdf
catalogLCN 4000 Series Cataloghttps://dvwi9lnoau63q.cloudfront.net/lcn/catalog/LCN_catalog_4000-series.pdf
cut-sheetLCN 4010 Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/lcn/cutsheets/LCN-cutsheet_4010-series.pdf
installation-guideLCN 4010 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_instructions_4010-series.pdf
LCN 4010, 4010T, 4510, 4510T Drop Plate Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_instructions_4010_4010T_4510_4510T-drop-plate.pdf
LCN 4010, 4020 & 4110 Door Closer w/ Fusible Link Arm Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_4010_4020_4110_Series_Fusible_Link_Installation_Instructions_107134.pdf
LCN 4011 Closer Installation Videohttps://youtu.be/sNB_Z0BSpuY
LCN Closers & Auto Operators Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_Closers_and_Auto_Operators_Templates_and_Instructions_Index_111819.pdf
parts-manualLCN Closers & Automatic Operators Parts Manualhttps://dvwi9lnoau63q.cloudfront.net/lcn/product-guide/LCN_partsmanual_closers-auto-operators.pdf
sell-sheetLCN 4000 Series Metal Templates Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/lcn/product-guide/LCN4000SeriesMetalTemplatesProductGuide.pdf

Specifications

Brand:
LCN
Advanced Backcheck:
No
Specifications Bullet 3:
Friction Hold-Open
Commercial Residential:
Commercial
Specifications Bullet 5:
Pull Side Mount
Specifications Bullet 10:
1-1/2" Piston Diameter
Interior/Exterior:
Interior/Exterior
Degree Swing:
140 Degree Swing
Electronic:
No
Body Base Material:
Cast Iron
ADA:
Yes
Specifications Bullet 7:
140 Degree Swing
Hold Open:
Yes
Door Handing:
Right Hand
Country of Origin:
United States
Base Material:
VARIES
Specifications Bullet 1:
Grade 1 Surface Door Closer
Parent Manufacturer:
Allegion
Maximum Door Weight (lbs):
225 lbs Maximum Door Weight
Box Width (in):
4-3/8"
Size:
Size 1-5
Cover Type:
Full Body Cover
Specifications Bullet 11:
Includes Self-Reaming Tapping Screws
Door Range (Thickness):
-
All Weather Fluid:
Yes
Specifications Bullet 9:
Cast Iron Body
Grade:
Grade 1
Specifications Bullet 8:
Plastic Full Body Cover
Type:
Door Closers and Operators
Finish Description:
Dark Bronze Painted
Series:
4010 Series Surface Mounted Closers
Specifications Bullet 2:
Hold Open Arm
Specifications Bullet 12:
ANSI A156.4, Grade 1, UL 10C, ADA
Finish:
695
Hold Open Type:
Friction Hold-Open
Certification:
ANSI A156.4, Grade 1, UL 10C, ADA
Manufacturer:
LCN
Box Height (in):
4-3/8"
Specifications Bullet 4:
Size 1-5
Fire Rated:
Yes
Cover Material:
Plastic
Box Depth (in):
15-5/8"
Screw Pack Designation:
SRT
Mount:
Pull Side Mount
Arm Type:
Hold Open Arm
UOM:
1
Closing Speed Adjustment:
Yes
Box Weight (lbs):
12 lbs
Specifications Bullet 6:
Right Hand
Backcheck:
Yes
Specifications Bullet 13:
30 Year Warranty
Selling Quantity:
1
Piston Diameter (in):
1-1/2"
Latch Speed Adjustment:
Yes
Screw Pack:
Self-Reaming Tapping Screws
Product Warranty:
30 Year Warranty
UPC:
840067624029
Trademark Term:
SMOOTHIE
Uid:
LCN1004011HRHDKBRZ
Url Title:
4011-h-rh-dkbrz
Title:
4011-H RH DKBRZ LCN Surface Closers
Sub Type:
Surface Closers
Last Modified:
2023-02-28T05:07:29+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
734
Avg Lead Time:
43
Finish Family:
Dark Bronze
Popularity:
9
Pack Weight:
12
Baa Qualified:
Yes
Limited Warranty:
30 Years
Unit Of Measure:
Each
Vendor:
Allegion

Warranty Information

30 Year Warranty
