LCN 4111-SCUSH LH 695 Grade 1 Surface Door Closer Spring Cush-N-Stop Arm Push Side Parallel Arm Mounting 110 Deg Swing Size 1 to 5 Full Plastic Cover Dark Bronze Finish Left-Handed

LCN

Write a Review
SKU:
4111-SCUSH LH 695
$601.88
LCN 4111-SCUSH LH 695 Grade 1 Surface Door Closer Spring Cush-N-Stop Arm Push Side Parallel Arm Mounting 110 Deg Swing Size 1 to 5 Full Plastic Cover Dark Bronze Finish Left-Handed
UPC:
840067659519
$601.88

Descriptions

The 4110 is LCN's best performing parallel arm mounted heavy duty surface door closer designed for institutional and other high traffic applications.
TypeTitleURL
brochure/sales-materialLCN Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/lcn/miscellaneous/ALLEGION_finish-chart.pdf
catalogLCN 4000 Series Cataloghttps://dvwi9lnoau63q.cloudfront.net/lcn/catalog/LCN_catalog_4000-series.pdf
cut-sheetLCN 4110 Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/lcn/cutsheets/LCN_cutsheet_4110-series.pdf
installation-guideLCN 4010, 4020 & 4110 Door Closer w/ Fusible Link Arm Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_4010_4020_4110_Series_Fusible_Link_Installation_Instructions_107134.pdf
LCN 4110 Drop Plates Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_4110_4210_Series_Drop_Plate_Installation_Instructions_105801.pdf
LCN 4110 Peel-N-Stick CUSH Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_4110_Series_CUSH_Installation_Instructions_105802.pdf
LCN 4110 Peel-N-Stick Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_4110_Series_Installation_Instructions_107170.pdf
LCN Closers & Auto Operators Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_Closers_and_Auto_Operators_Templates_and_Instructions_Index_111819.pdf
LCN Drop Plates Installation Guide for 4110, 4110 CUSH, 4210, 4210 CUSH, 4110T, 4210Thttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCNDropPlateInstallationGuide.pdf
sell-sheetLCN 4000 Series Metal Templates Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/lcn/product-guide/LCN4000SeriesMetalTemplatesProductGuide.pdf

Specifications

Brand:
LCN
Screw Pack Designation:
SRT
Certification:
ANSI A156.4, Grade 1, UL 10C, ADA
Box Height (in):
4-1/2"
Door Range (Thickness):
-
Closing Speed Adjustment:
Yes
Specifications Bullet 4:
Push Side Mount
Cover Type:
Full Body Cover
Fire Rated:
Yes
Finish:
695
Advanced Backcheck:
No
Finish Description:
Dark Bronze Painted
Latch Speed Adjustment:
Yes
Maximum Door Weight (lbs):
225 lbs Maximum Door Weight
Base Material:
Varies
Hold Open Type:
Not Applicable
Cover Material:
Plastic
Backcheck:
Yes
Box Width (in):
6"
Arm Type:
Spring Stop Arm
Specifications Bullet 8:
Cast Iron Body
Commercial Residential:
Commercial
Degree Swing:
110 Degree Swing
ADA:
Yes
Body Base Material:
Cast Iron
Specifications Bullet 9:
1-1/2" Piston Diameter
Country of Origin:
United States
Box Depth (in):
16"
Interior/Exterior:
Interior/Exterior
All Weather Fluid:
Yes
Hold Open:
No
Specifications Bullet 10:
Includes Self-Reaming Tapping Screws
Specifications Bullet 3:
Size 1-6
Specifications Bullet 12:
30 Year Warranty
Series:
4110 Series Surface Mounted Closers
Screw Pack:
Self-Reaming Tapping Screws
Box Weight (lbs):
15 lbs
Grade:
Grade 1
Mount:
Push Side Mount
Door Handing:
Left Hand
Selling Quantity:
1
Size:
Size 1-6
Specifications Bullet 6:
110 Degree Swing
Electronic:
No
Type:
Door Closers and Operators
Specifications Bullet 7:
Plastic Full Body Cover
Specifications Bullet 5:
Left Hand
Specifications Bullet 2:
Spring Stop Arm
Piston Diameter (in):
1-1/2"
Specifications Bullet 11:
ANSI A156.4, Grade 1, UL 10C, ADA
Trademark Term:
SMOOTHIE
UOM:
1
UPC:
840067659519
Manufacturer:
LCN
Specifications Bullet 1:
Grade 1 Surface Door Closer
Parent Manufacturer:
Allegion
Product Warranty:
30 Year Warranty

Warranty Information

30 Year Warranty
