Von Duprin 5100-3FP SP313 Electric Strike Field Selectable Fail Safe/Secure 12/24VDC 4-7/8 x 1-1/4 and 7-15/16 x 1-7/16 Faceplate For use with Cylindrical Locks on Single Doors Dark Bronze Painted Finish

Von Duprin

Write a Review
SKU:
5100-3FP SP313
$244.09
Von Duprin 5100-3FP SP313 Electric Strike Field Selectable Fail Safe/Secure 12/24VDC 4-7/8 x 1-1/4 and 7-15/16 x 1-7/16 Faceplate For use with Cylindrical Locks on Single Doors Dark Bronze Painted Finish
$244.09

Descriptions

The Von Duprin 5100 Series electric door strike has been designed to offer flexibility and convenience for locksmiths and security professionals alike. This easy-to-install electric strike was created for medium-duty applications, specifically to control traffic flow through interior and exterior openings in retail and commercial environments.
TypeTitleURL
brochure/sales-materialVon Duprin Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/vonduprin/miscellaneous/ALLEGION_finish-chart.pdf
installation-instructions5100 Electric Strike Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/107665.pdf
price-book2024 Von Duprin Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/vonduprin/pricebooks/VON_pricebook_3-2024.pdf
service-manual5100/6100/6200/6300 Series Electric Strikes Service Manualhttps://dvwi9lnoau63q.cloudfront.net/vonduprin/common-part-manuals/108727.pdf

Specifications

Brand:
Von Duprin
Certification:
ANSI A156.31, Grade 1, UL 1034, UL 10C
Box Width (in):
1-1/4"
Base Material:
Varies
Grade:
Grade 1
Parent Manufacturer:
Allegion
Door Handing:
Non-handed
Frame Material:
Metal/Wood
Box Depth (in):
1-11/16"
FS/FSE Mode:
Fail Safe / Fail Secure
Box Height (in):
4-7/8"
Interior/Exterior:
Interior/Exterior
Application:
For Cylindrical Locksets having 5/8" Throw
Commercial Residential:
Commercial
Door Range (Thickness):
-
Country Of Origin:
USA
Dimensions:
1-1/4" x 4-7/8"
Dynamic Impact Strength:
70 foot-pounds
Electronic:
No
Finish:
695
Specifications Bullet 5:
380mA @ 12 VDC, 190mA @ 24 VDC Current
Specifications Bullet 9:
ANSI A156.31, Grade 1, UL 1034, UL 10C
Specifications Bullet 2:
For Cylindrical Locksets having 5/8" Throw
Specifications Bullet 1:
12/24 VDC Voltage Electric Strike
Specifications Bullet 7:
1-1/4" x 4-7/8" Unit Dimension
Specifications Bullet 3:
Includes 3 Faceplates
Finish Description:
Dark Bronze Painted
Includes:
3 Faceplates
Current:
380mA @ 12 VDC, 190mA @ 24 VDC Current
Latch Throw (in):
5/8"
Product Warranty:
1 Year Warranty
Specifications Bullet 10:
1 Year Warranty
Specifications Bullet 6:
Fail Safe / Fail Secure
Manufacturer:
Von Duprin
Specifications Bullet 4:
1300 lbs Static Holding Strength
Fire Rated:
Yes
Resistance (Olm):
32 Ohms @ 12 VDC, 128 @ 24 VDC
Specifications Bullet 8:
Accepts 5/8" Latch Throw
Strike Dimensions:
1-1/4" x 4-7/8"
Selling Quantity:
1
Static Holding Strength (lbs):
1300
Series:
5100 Series Electric Strikes
Voltage:
12/24 VDC Voltage
UOM:
1
Uid:
VON10051003FPSP313
Url Title:
5100-3fp-sp313
Title:
5100-3FP SP313 Von Duprin Electric Strike
Type:
Electric Strikes, Bolts, Magnets
Sub Type:
Electric Strikes
Last Modified:
2024-02-03T05:15:21+00:00
Last Pricing:
2022-02-24T00:00:00+00:00
Msrp:
351
Avg Lead Time:
50
Finish Family:
Dark Bronze
Popularity:
3
Pack Weight:
1.7
Pack Length:
8.5
Pack Width:
3.5
Pack Height:
1.875
Pack Volume:
55.78125
Restrictions:
None
Baa Qualified:
No
Limited Warranty:
1 Year
Accessible:
No
Unit Of Measure:
Each
Vendor:
Allegion

Warranty Information

1 Year Warranty
