Sargent 8205 LNB 26D Grade 1 Office or Entry Mortise Lock B - Lever LN - Rose Field Reversible Conventional Cylinder ASA Strike Satin Chrome

Sargent

Write a Review
SKU:
8205 LNB 26D
$884.31
Sargent 8205 LNB 26D Grade 1 Office or Entry Mortise Lock B - Lever LN - Rose Field Reversible Conventional Cylinder ASA Strike Satin Chrome
$884.31

Descriptions

When it comes to strength and durability, SARGENT continues to set standards with the 8200 Mortise lock. The 8200 far surpasses ANSI/BHMA A156.13 Series 1000 Grade 1 standards, making it the strongest and most durable mortise lock in the industry. SARGENT Mortise Locks are designed and constructed with high quality components to provide maximum security, performance and durability
TypeTitleURL
catalogSargent 7800/8200 Series Mortise Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Mortise_Lock_78008200_Series_Catalog.pdf
Sargent Healthcare Hardware Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Speciality_Hardware_Catalog.pdf
installation-instructions7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_Sectional_Trim__V_Series_Indicators.pdf
7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_VN1_Escutcheon_Trim__V_Series_Indicators_Installatio_Instructions.pdf
7800/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800Knob8200LeverMortiseLockEscutcheonRoseTrim.pdf
7900/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/8200installationA8202A.pdf
Video: 8200 Series Mortise Lock Installationhttps://youtu.be/DWRY72iLKN4
literatureSargent 8200 Series Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/sargent/literature/133.1_ASSA_ABLOY_mrEPD_Sargent8200SeriesMortiseElectrified.pdf
sell-sheetSargent 8200 Series Mortise Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/8200sellsheetv7.pdf

Specifications

Brand:
Sargent
Certification:
ANSI A156.13, Series 1000, Grade 1, A117.1, UL Listed
Backset (in):
2-3/4"
Electronic:
No
Cylinder Type:
Mortise Conventional
Parent Manufacturer:
Assa Abloy
Includes Cylinder(s)?:
Yes
Grade:
Grade 1
Specifications Bullet 1:
Grade 1 Entrance Thumbturn Function Mortise Lockset
Finish Description:
Satin Chrome
Rose/Escutcheon:
Rose
Specifications Bullet 5:
2-3/4" Backset
Door Handing:
Non-handed
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Pocket Dimensions:
6-5/8" x 4-1/2"
Latch Description:
Dead Latch
Keyway:
LA Keyway
Specifications Bullet 8:
2-1/8" Rose Dimension
Interior/Exterior:
Interior/Exterior
Specifications Bullet 7:
2-5/8" Projection
Lever/Knob/Pull Design:
B
Specifications Bullet 9:
3/4" Dead Latch
Base Material:
Brass Bronze
Latch Dimensions:
1-1/4" x 8"
Specifications Bullet 13:
ANSI A156.13, Series 1000, Grade 1, A117.1, UL Listed
Latch Throw (in):
3/4"
Specifications Bullet 3:
Mortise Conventional LA Keyway
Door Range (Thickness):
1-3/4" - 1-3/4"
Country Of Origin:
USA
Can Be Keyed:
Yes
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 11:
6-5/8" x 4-1/2" Pocket Dimension
Fire Rated:
2 Hours {B}
Specifications Bullet 12:
For Doors 1-3/4" Thick
Commercial/Residential:
Commercial
Specifications Bullet 4:
LN Rose
Selling Quantity:
1
Projection (in):
2-5/8"
Specifications Bullet 14:
10 Year Warranty
Rose/Escutcheon Dimensions (in):
2-1/8"
Function:
Entrance Thumbturn
ADA:
Yes
Deadbolt Throw (in):
Not Applicable
Product Warranty:
10 Year Warranty
Pocket Depth (in):
6-5/8" x 4-1/2"
Minimum Door Thickness (in):
1-3/4"
Strike Number:
82-0110
Lever/Knob/Pull:
Lever
Specifications Bullet 2:
B Lever
Specifications Bullet 10:
1-1/8" x 8" Faceplate Dimension
Finish:
626/US26D
Strike Description:
ASA Strike
Armor Front Dimensions:
1-1/4" x 8"
UOM:
1
Manufacturer:
Sargent
Series:
8200 Series
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon Design:
LN

Warranty Information

10 Year Warranty
